PRODUCT NO.
BASE MODEL NO.
FAS186L2A1
FAS186L2A
MARKET
USA
WIRING DIAGRAM - # 309343701
OWNER'S GUIDE - # 309000825
ENERGY GUIDE - # 309367449
ELECTROLUX HOME PRODUCTS, INC
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
SERIES
VOLTS
Gallery
230
Publication No.
5995368478
020316
©2002 Electrolux Home Products, Inc.
-EN/SERVICE /BLT
All rights reserved
345
BTU-COOLING
17500 BTU
ROOM AIR CONDITIONER
Model No.
FAS186L2A1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FAS186L2A1
Summary of Contents for Frigidaire FAS186L2A1
-
Page 1: Room Air Conditioner
PRODUCT NO. BASE MODEL NO. FAS186L2A1 FAS186L2A MARKET WIRING DIAGRAM - # 309343701 OWNER’S GUIDE - # 309000825 ENERGY GUIDE - # 309367449 ELECTROLUX HOME PRODUCTS, INC P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER SERIES VOLTS... -
Page 2: Cabinet Front And Wrapper
Publication No. FAS186L2A1 5995368478 CABINET FRONT AND WRAPPER 03/02... - Page 3 Filter,air ,molded plastic 309633205 Front Assembly,w/7,8,9,12,43 309341002 Overlay,Frig Gallery 309321401 Door,vent ,with actuator 309330404 Handle,vent ,gray 309330202 Detent,vent 3015312 Screw,8-18AB x 0.500 309630904 Panel,cabinet front 309342401 Enclosure,elec control mt 309350502 Remote Control,transmitter ,with batteries 309367449 Energy Guide,FAS186L2A1 Publication No. 5995368478 03/02...
- Page 4 Publication No. FAS186L2A1 5995368478 CONTROLS 03/02...
- Page 5 POS. NO 13 # 17 # 71 # 72 # # = Fast-moving Parts * = Non-Illustrated Parts FAS186L2A1 CONTROLS PART NO DESCRIPTION 309630403 Control Box 5303015427 Screw,truss head ,8-18AB x 0.47 309623602 Bulkhead,control system 309111201 Grommet,wire protector 5304413782 Holder,thermistor ,w/seal...
-
Page 6: Air Handling Parts
Publication No. FAS186L2A1 5995368478 AIR HANDLING PARTS 03/02... - Page 7 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAS186L2A1 AIR HANDLING PARTS PART NO DESCRIPTION 5303311048 Fan Blade,with clamp 3202975 Screw,10-16AB x 0.72 ,square drive 309623201 Shroud,cond fan motor 5303212504 Seal,sleeve/shroud ,23.72" x 1.25" ,bottom 5303015311 Seal,fan housing ,19.56" x 0.50" ,lower 5303015427 Screw,truss head ,8-18AB x 0.47...
-
Page 8: Compressor Parts
Publication No. FAS186L2A1 5995368478 COMPRESSOR PARTS 03/02... - Page 9 POS. NO 11 # 12 # 16 # 17 # 03/02 COMPRESSOR PARTS PART NO DESCRIPTION 309603112 Compressor 5303283877 Grommet,compressor mtg ,(3) 5308006948 Nut,compressor mtg ,(3) 5303291330 Gasket,terminal cover 5304416126 Cover,elec terminal ,compressor 5304414111 Overload Protector,MRA 12044-386 5303294292 Nut,terminal cover 309634201 Evaporator 5303306719...
- Page 10 Publication No. FAS186L2A1 5995368478 WINDOW MOUNTING PARTS 03/02...
- Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAS186L2A1 WINDOW MOUNTING PARTS PART NO DESCRIPTION 5304407729 Seal,window stuffer 5303211056 Bracket,sash lock 5304419163 Extension,sliding frame ,LH cab front ,w/closure panel 5304409250 Seal,top rail/cab 5304414933 Retainer,accordian 5304414105 Bracket,support ,RH 3001815 Bracket,sill/unit sprt.
-
Page 12: Wiring Diagram
Publication No. FAS186L2A1 5995368478 WIRING DIAGRAM 03/02...
