Frigidaire FAS183K2A1 Factory Parts Catalog

Frigidaire FAS183K2A1 Factory Parts Catalog

Room air conditioner
Hide thumbs

Advertisement

Quick Links

Download this manual
PRODUCT NO.
FAS183K2A1
WIRING DIAGRAM - # 309107701
OWNER'S GUIDE - # 309000823
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG
BASE MODEL NO.
BTU-COOLING
FAS183K2A
18000BTU
Publication No.
5995348579
-EN/SERVICE /DJH

ROOM AIR CONDITIONER

ROOM AIR CONDITIONER
010117
345
©2001 White Consolidated Industries, Inc.
All rights reserved
Model No.
FAS183K2A1

Advertisement

loading

Related Manuals for Frigidaire FAS183K2A1

Summary of Contents for Frigidaire FAS183K2A1

  • Page 1: Room Air Conditioner

    PRODUCT NO. BASE MODEL NO. FAS183K2A1 FAS183K2A WIRING DIAGRAM - # 309107701 OWNER’S GUIDE - # 309000823 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER BTU-COOLING 18000BTU ROOM AIR CONDITIONER FAS183K2A1 Publication No.
