PRODUCT NO.
FAS185J2A2
WIRING DIAGRAM - # 309343701
OWNER'S GUIDE - # 309000825
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG
BASE MODEL NO.
BTU-COOLING
FAS185J2A
18000BTU
Publication No.
5995348611
-EN/SERVICE /DJH

ROOM AIR CONDITIONER

ROOM AIR CONDITIONER
010118
345
©2001 White Consolidated Industries, Inc.
All rights reserved
Model No.
FAS185J2A2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FAS185J2A2 and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FAS185J2A2

Summary of Contents for Frigidaire FAS185J2A2

  • Page 1: Room Air Conditioner

    PRODUCT NO. BASE MODEL NO. FAS185J2A2 FAS185J2A WIRING DIAGRAM - # 309343701 OWNER’S GUIDE - # 309000825 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER BTU-COOLING 18000BTU ROOM AIR CONDITIONER FAS185J2A2 Publication No.

  • Page 2: Cabinet Front And Wrapper

    Publication No. FAS185J2A2 5995348611 CABINET FRONT AND WRAPPER 08/01...
  • Page 3 POS. NO 26A* # = Fast-moving Parts * = Non-Illustrated Parts FAS185J2A2 CABINET FRONT AND WRAPPER PART NO DESCRIPTION 309632704 Cabinet,sleeve ,top louvers 309632804 Grille,rear ,with rail 309631104 Link,vertical louver 309630804 Louver,horizontal 309633305 Louver Assy,horizontal 309631004 Louver 309631404 Filter-air,molded plastic...
  • Page 4 Publication No. FAS185J2A2 5995348611 CONTROLS 08/01...
  • Page 5 POS. NO 13 # 70 # 71 # 72 # # = Fast-moving Parts * = Non-Illustrated Parts FAS185J2A2 CONTROLS PART NO DESCRIPTION 309630403 Control Box 309623601 Bulkhead,control system 5303317228 Capacitor,370 V ,30+6 3015312 Screw,8-18AB x 0.500 5303303077 Strap-capacitor 309343112...

  • Page 6: Air Handling Parts

    Publication No. FAS185J2A2 5995348611 AIR HANDLING PARTS 08/01...
  • Page 7 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAS185J2A2 AIR HANDLING PARTS PART NO DESCRIPTION 5303311048 Fan Blade,with clamp 3202975 Screw,10-16 x 0.72 ,square drive 309623201 Shroud-condenser,one piece 5303015311 Seal,fan housing ,lower 309630603 Motor-fan,GE 3sp ,48/fr ,230/60 309623401...

  • Page 8: Compressor Parts

    Publication No. FAS185J2A2 5995348611 COMPRESSOR PARTS 08/01...
  • Page 9 POS. NO 11 # 12 # 16 # # = Fast-moving Parts * = Non-Illustrated Parts FAS185J2A2 COMPRESSOR PARTS PART NO DESCRIPTION 5304403268 Compressor 5303286606 Grommet,compressor mtg ,(3) 5308006948 Nut,compressor mtg ,(3) 5303002069 Wire-Bale,terminal cover 5303002068 Gasket,terminal cover 5303002067 Cover,compr terminal...
  • Page 10 Publication No. 5995348611 08/01 FAS185J2A2 WINDOW MOUNTING PARTS POS. NO PART NO 5304407729 5304414928 5304409250 5304414933 5304414105 5304414106 5304414929 5304414930 5304414116 5303212504 309313204 309313303 5304409248 5304409249 DESCRIPTION Seal-window frame,stuffer Frame,LH Seal-top rail Retainer,accordian Bracket-support,RH Bracket-support,LH Frame,RH Closure,accordian type ,window mount...

  • Page 11: Wiring Diagram

    FAS185J2A2 Publication No. 5995348611 WIRING DIAGRAM # = Fast-moving Parts 08/01 * = Non-Illustrated Parts...
