Jumper Settings - Congatec conga-SKIT Quick Start Manual

1.6

Jumper Settings

1 2 3
X16 - LAN LEDs
Pin Configuration
1-2 Standby powered
2-3 Main powered
X22 - LCD0 VDD
Pin Configuration
1-2 3.3 V panel power
2-3 5 V panel power
X24 - LCD0 BKLT_EN
Pin Configuration
1-2 Non-inverted
2-3 Inverted
X25 - LCD0 BKLT
Pin Configuration
1-2 Backlight power 12 V
2-3 Backlight power 5 V
X27 - LCD1 Panel Power
Pin Configuration
1-2 3.3 V
2-3 5 V
X28 - LCD1 BKLT1
Pin Configuration
1-2 12 V
2-3 5 V
Copyright © 2017 congatec AG
X29 - LCD1 BKLT_EN1
Pin Configuration
1-2 Non-inverted
2-3 Inverted
X34 - HDMI/DP1 *1
Pin Configuration
1-2 DP1 @ USB Type-C
2-3 HDMI
X35 - DP1 AUX_SEL
*1
Pin Configuration
1-2 Pull-down
2-3 Pull-up
X40 - GPIO [0:7]
Pin Configuration
1-2 Enabled
2-3 Disabled
X43 - FAN Power
Pin Configuration
1-2 12V
2-3 5V
X44 - TEST#
Pin Configuration
1-2 Normal operation
2-3 Test mode
X45 - FORCE_RECOV#
Pin Configuration
1-2 Normal operation
2-3 Force recovery mode
X47 - CAN0 Term
Pin Configuration
1-2 Enabled
2-3 Disabled
X49 - CAN1 Term
Pin Configuration
1-2 Enabled
2-3 Disabled
X52 - SBM3
Pin Configuration
1-2 Present
2-3 Not present
X53 - ATX PSON#
Pin Configuration
1-2 ATX Mode
2-3 AT Mode / Always ON
X54 - ATX Control
Pin Configuration
1-2 CARRIER_SBY#
2-3 CARRIER_PWRON
X55 - SBY Control
Pin Configuration
1-2 CARRIER_PWRON
2-3 Always ON
X56 - Postcode
Pin Configuration
1-2 Enabled
2-3 Disabled
SKIT_q12
X57 - RTC Battery
Pin Configuration
1-2 Normal operation
2-3 RTC battery disconnected
X59 - Module Power
Pin Configuration
1-2 3.3 V
2-3 5 V
X60 - VIN PWRBAD#
Pin Configuration
1-2 ATX_PG (only for debug)
3-4 AT_CARRIER PG
5-6 +3.3V_ATX PG
7-8 AT_SMARC PG
2-4 No VIN PWRBAD# control
X61 - Power Path
Pin Configuration
1-2 Automatic* 2
2-3 AT_SMARC
*1 Only for modules with support
for DP++ at HDMI0/DP1.
*2 Every time +V3.3A gets
enabled, the status of
+AT_SMARC is used to select
the power path (AT vs. 3.3 V / 5
V). This means once activated,
the AT_SMARC path is kept
active until a full power cycle is
performed.
For more information, refer
to the conga-SA5 and conga-
SEVAL User's Guide or contact
congatec technical support.
