2020
FW, FW HT and FW HTX
Fifth Wheel Towables
Owner's Manual
0283662.2020

Advertisement

Table of Contents
loading

Related Manuals for Jayco EAGLE FW 2020

Summary of Contents for Jayco EAGLE FW 2020

  • Page 1 2020 FW, FW HT and FW HTX Fifth Wheel Towables Owner’s Manual 0283662.2020...
  • Page 3 44,683 people. We’re proud of our results, and we know those numbers show that a little initiative can go a long way. The Jayco EcoAdvantage is our way of making sure endless generations can enjoy the Great Outdoors.

  • Page 5: Table Of Contents

    Table of Contents Section 1: Warranty & Service Factory Tours Options and Equipment Dealer Responsibility Customer Relations To Contact Us About This Manual Warranty Packet Safety Alerts Reporting Safety Defects Customer Responsibility Change Of Address/Ownership Suggestions For Obtaining Service Obtaining Service For Separately Warranted Items Obtaining Service At Our Customer Service Facility Parts and Accessories Section 2: Occupant Safety...
  • Page 6 Table of Contents Factory Installed Hitch Reciever (if so equipped) Entrance Door Step(s) Stowable Entrance Door Step (if so equipped) Entrance Door Rear Backup Camera Prep Campsite Hook-Up LCI 3.0 Leveling System (if so equipped) Auto Leveling Touch Pad OneControl Touch Panel OneControl Touch Panel Linc Remote Control Linc Remote...
  • Page 7 Table of Contents Section 6: Electrical System The Electrical System In Case Of An Electrical Fire Command Center Command Center Panel Command Center Panel w/Switch Modules GFCI Receptacle LCI One Control® System 5-Way and 8-Way Power Remote (if so equipped) Testing the Campsite Power Connection Connecting the Power Cord Inverter (if so equipped)
  • Page 8 Table of Contents Calculating Propane Gas Usage Traveling With Propane Installing Propane Cylinder(s) Refueling Warning Label Single Cylinder Main Supply Hose Double Cylinder Two Propane Cylinders Section 8: Plumbing System Plumbing System Plumbing System Maintenance Monitor Panel Operation Monitor Panel Fresh Water System Command Center Water Pressure Regulator (customer supplied)
  • Page 9 Table of Contents Section 9: Heating & Cooling Air Conditioner Roof Mount (if so equipped) Wall Mount (if so equipped) Heat Pump Operation (if so equipped) Power Roof Vent (if so equipped) Attic Fan Control Ceiling Fan (if so equipped) Furnace Fireplace (if so equipped) Section 10: Appliances...
  • Page 10 Jack Knife Sofa Trifold Sofa Cube Sofa Booth Dinette (if so equipped) Free-Standing Table and Chairs (if so equipped) Pantry or Hutch (if so equipped) Countertops Laminate Countertops (if so equipped) Solid Surface Countertops (if so equipped) Flooring Carpet Vinyl Flooring Murphy Bed (if so equipped) Bed Storage Prop Rod (if so equipped)
  • Page 11 WARNING: Read all instructions in this manual and component manufac- turer supplied information before using your RV. This manual has been provided by your recreational vehicle manufacturer for the sole pur- pose of providing instructions concerning the operation and maintenance of this recreational vehicle.

  • Page 13: Section 1: Warranty & Service

    Canada may differ to conform to Canadian Codes. Dealer Responsibility At the time of sale of the new recreation vehicle, your Jayco dealer is expected to: Deliver your recreation vehicle in the best condition possible. Your recreation ve- hicle must pass the dealer’s pre-delivery inspection (PDI), including all systems...
  • Page 14 (or any effect of the alterations) to any of the parts, components, systems or assemblies installed by Jayco. Jayco is not responsible for the safety or quality of design features, materials or workmanship of any alterations by such suppliers.

  • Page 15: To Contact Us

    Canada. In addition, the club offers a variety of local and regional activities throughout the year. By belonging to the Jayco Travel Club, you will find new ways to enjoy your RV and make friends all across the country.

  • Page 16: Warranty Packet

    Section 1: Warranty & Service Warranty Packet There are components that are excluded from the vehicle warranty, or are warranted sepa- rately by their own individual manufacturer’s limited warranty. The Warranty Packet con- tains these component manufacturer supplied manuals or information sheets, warranty cards and/or registrations.

  • Page 17: Reporting Safety Defects

    Section 1: Warranty & Service  Indicates a potentially hazardous situation that, if not avoided, may result in death or serious injury. Reporting Safety Defects In the United States: If you believe that your recreation vehicle has an alleged defect which could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA), in addition to notifying our Cus- tomer Service Department.

  • Page 18: Customer Responsibility

    Section 1: Warranty & Service Customer Responsibility It is important you read and understand all instructions and precautions before operating the recreation vehicle. Even if you are an experienced RV’er we encourage you to thoroughly read this Owner’s Manual, as well as the information contained in your Warranty Packet and Chassis Guide (motorized only).

  • Page 19: Obtaining Service For Separately Warranted Items

    Section 1: Warranty & Service Please be aware that all service shops require notification of any issues with their repairs within a specified time limit. Make sure you are familiar with their repair policies. Obtaining Service For Separately Warranted Items Your selling dealer is responsible for servicing your recreational vehicle before delivery, and has an interest in your continued satisfaction.
  • Page 20 If a substantial defect in material or workmanship, attributable to Jayco, is found to exist and is reported to Jayco or an authorized servicing dealer during the appli- cable warranty period, it will be repaired or replaced, at Jayco’s option, without charge to the RV owner, in accordance with the terms, conditions and limitations of this limited warranty.
  • Page 21 RV is delivered to the first retail purchaser by an independent, authorized dealer of Jayco, or, if the dealer places the vehicle in service before retail sale, on the date the RV is first placed in such service.
  • Page 22 RV not attributable to Jayco; • items that are added or changed after the RV leaves the possession of Jayco; • additional equipment or accessories installed at any dealership, or other place of busi- ness, or by any other party, other than Jayco;...
  • Page 23 Certain things completely discharge Jayco from any obligation under this warranty and void it. By way of example, the following shall discharge Jayco from any express or implied warranty obligation to repair or replace any defect that results from: any rental or other busi-...
  • Page 24 In addition, this warranty is not intended to extend to future performance, and nothing in this warranty, or any action of Jayco, or any agent of Jayco, shall be interpreted as an extension of the warranty period or this limitation period.

  • Page 25: Secondary Means Of Escape (Exit Window)

    Section 2: Occupant Safety Secondary Means of Escape (Exit Window) Your recreation vehicle has been equipped with a window(s) that serves as a secondary means of escape. The window(s) will allow a quick exit from the vehicle during an emer- gency if access to the main entrance door is not available.

  • Page 26: Fire Safety

    Section 2: Occupant Safety Lever style latch Remove the screen by pulling the red tab (upper right arrow). Pull the lever out from the sash clamps. Swing the lever out so it is positioned straight out from the window. Push the lever (and window) out to open and exit the vehicle. Fire Safety If a fire does start, follow these basic safety rules: Call 911 and evacuate the vehicle immediately.

  • Page 27: Smoke Alarm

    Section 2: Occupant Safety  Do not check the pressure, test or practice using the fire extinguisher by squeezing the trigger, even briefly. The fire extinguisher is not rechargeable or refillable. Once used, it will gradually lose pressure and will not be fully charged for use in an emergency.

  • Page 28: Combination Carbon Monoxide /Propane Alarm

    Section 2: Occupant Safety When the battery is removed from the alarm, the battery flag will pop up; the alarm cannot be installed to the mounting bracket without a battery. To test, stand at arm’s length from the smoke alarm as the alarm horn is loud and may be harmful to your hear- ing.
  • Page 29 Section 2: Occupant Safety The alarm is directly wired to the 12-volt electrical system, with continuous power being supplied by the recreational vehicle batteries. There is no 9-volt battery power supply. As a result, the alarm is always drawing a small amount of current from the recreation vehicle batteries.
  • Page 30 Section 2: Occupant Safety What you should do if the alarm sounds  Actuation of this detector indicates the presence of carbon monoxide which can kill you. Never turn the 12-volt battery disconnect control to the off position and disconnect the battery cable to silence an alarm. The alarm will auto- matically sense when the level of carbon monoxide in the air reaches below dangerous levels.

  • Page 31: Formaldehyde

    Section 2: Occupant Safety Testing the combination carbon monoxide/propane alarm  Test the alarm operation after the RV has been in storage, before each trip and at least once per week during use. The TEST/RESET button tests all ELECTRICAL functions of the alarm. The TEST/Mute switch is located on the front of the alarm.

  • Page 32: Cold Weather Usage

    Section 2: Occupant Safety  Continuous or permanent living in your recreation vehicle may affect your warranty coverage and may void the “Limited Warranty” applicable to your vehicle. Cold Weather Usage When used in freezing or below freezing temperatures, the precautions should be taken: Fresh water and drainage systems - preparations to avoid freeze-ups.

  • Page 33: Tow Vehicle

    Section 3: Pre-Travel Information Tow Vehicle If you plan to tow your recreation vehicle with a tow vehicle you already own, or if you plan to purchase a new one, make sure the Gross Vehicle Weight Rating (GVWR) or your recreation vehicle does not exceed your tow vehicles towing rating.

  • Page 34: Occc Label (Yellow)

    Section 3: Pre-Travel Information OCCC Label (Occupant and Cargo Carrying Capacity The upper portion of this yellow label is feder- ally required and includes the maximum Occu- pant and Cargo Carrying Capacity that may be placed in or on the trailer as it was manufac- tured and weighed before leaving the factory.

  • Page 35: Loading Your Recreation Vehicle

    Section 3: Pre-Travel Information Loading Your Recreation Vehicle  Never load the RV in excess of the GAWR for either axle. Overload- ing your RV may result in adverse handling characteristics and dam- age to the RV. DO NOT EXCEED YOUR GVWR! This means you should weigh your RV as loaded for your normal travel to determine the actual weight.

  • Page 36: Rear Bumper

    Section 3: Pre-Travel Information Rear Bumper The rear bumper of your RV is not designed to carry cargo. Items that extend beyond the bumper OR weigh over 100 lbs. (45kg) will place undo strain on the bumper. The 100 lb. bumper capacity includes the weight of the spare tire (if so equipped).

  • Page 37: Fifth Wheel Pin Box

    Section 3: Pre-Travel Information Your recreation vehicle manufacturer cannot be responsible for the suspension system of any tow vehicle. There are a variety of tow vehicle suspension systems available that will affect the pin box height, stability and levelness of a hooked up RV. Make sure your dealer is aware of the tow vehicle you are using so a compatible hookup is achieved.

  • Page 38: Wire Harness/Connector Plug

    Section 3: Pre-Travel Information Wire Harness/Connector Plug A 7-way wire harness/connector plug is wired into your trailer to connect electrical power from the tow vehicle for travel. This supplies power to the RV brakes, taillights, clearance lights, turn signals, brake lights, etc. Wiring to operate your brakes must be the same size in both the tow vehicle and RV (the RV brake wiring is 12-gauge wire).
  • Page 39 Section 3: Pre-Travel Information To weigh your tow vehicle and RV  Total weight of your tow vehicle and RV must not exceed the GCWR. Do not assume that you can tow a RV that happens to be within the ca- pacity of the tow vehicle hitch.
  • Page 40 Section 3: Pre-Travel Information Notes:...

  • Page 41: Section 4: Vehicle Operation

    Section 4: Vehicle Operation Towing  Your RV braking system is rated for operation at GVWR not GCWR. Whenever possible, do not travel with waste in the holding tanks. Liquid or debris in the holding tank(s) may affect the towing characteristics and may result in property damage or personal injury.

  • Page 42: Electric Brakes

    Section 4: Vehicle Operation Electric Brakes  Failure to maintain the brakes in proper working condition as specified in the operator’s manual supplied by the axle OEM will cause property damage, personal injury and possibly death. Consult with your dealer for assistance. The electric brakes are designed to work with the tow vehicle brakes.

  • Page 43: Hydraulic Brakes (If So Equipped)

    If you do not have a Jayco factory installed hitch receiver, towing items behind your Jayco RV, or overloading the rear, will void the warranty and may result in: damage to the RV or add-on items, towing difficulties, property dam- age and/or personal injury.

  • Page 44: Factory Installed Hitch Reciever (If So Equipped)

    Factory Installed Hitch Reciever (if so equipped)  If you do not have a Jayco factory installed hitch receiver, towing items behind your Jayco RV, overloading the rear, or failure to adhere to the specified weight capacities will void the warranty and may result in: damage to the RV or add-on items, towing difficulties, property dam- age and/or personal injury.
  • Page 45 Section 4: Vehicle Operation These labels have been placed on the hitch receiver and on the rear bumper of your RV. Be sure to read, understand and follow the information on them. Second Trailer Hitching Procedure The following procedure will help to assist you in securely hooking up the second trailer to your RV.

  • Page 46: Entrance Door Step(S)

    Section 4: Vehicle Operation Entrance Door Step(s) Make sure your entrance step is fully extended before exiting the vehicle, and retracted prior to towing. Lubricating the step mechanism Carefully clean the area around the pivot points (the rivets involved in the motion of the mechanism). Lubricate these pivot points with an automotive grade, non-staining lubricant every 30 to 60 days.

  • Page 47: Entrance Door

    Section 4: Vehicle Operation Step operation Open the entrance/screen door all the way. Twist the locking handle to release the steps from the locked position on the door frame (A). Lower the step assembly to the ground (B). Adjust the feet to stabilize the steps (C). Step storage Fold the handrail at the door out of the way or re- move the optional step handrail (if so equipped).

  • Page 48: Rear Backup Camera Prep

    Section 4: Vehicle Operation Rear Backup Camera Prep Your recreation vehicle has been pre-wired to allow for installation of a (customer supplied and customer installed) rear backup camera and a customer installed (or dealer installed) camera ON/OFF switch so the backup camera can be used as an observation/security cam- era.
  • Page 49 Section 4: Vehicle Operation  Failure to act in accordance with the following warnings may result in serious personal injury or death! Never use the auto leveling system to lift the RV off the ground. Lift- ing the RV so the wheels are not touching the ground will create an un- stable and unsafe condition.

  • Page 50: Auto Leveling Touch Pad

    Section 4: Vehicle Operation NOTE: Refer to the Lippert Ground Control 3.0 manual included in our warranty packet for complete instructions on the following procedures. Auto Leveling Touch Pad Unhitching the RV Before unhitching from the tow vehicle, ensure the RV is parked on a level surface and tires are chocked.

  • Page 51: Onecontrol Touch Panel

    Section 4: Vehicle Operation OneControl Touch Panel Press the button at the bottom of the touch panel to power up the display. Select MyRV Control Panel from the menu list- ing on the screen. Then select the Leveler icon. The following functions can be operated using the OneControl Touch Panel inside the RV.

  • Page 52: Onecontrol Touch Panel

    Section 4: Vehicle Operation Linc Remote Control Configuring the remote to sync with the OneControl Touch panel: Press the chrome button on the bottom of the remote to turn it on. Enter the PIN (default is 0,0,0,0). The PIN can be changed after entering the default PIN.

  • Page 53: Stabilizer Jacks

    Section 4: Vehicle Operation Stabilizer Jacks  DO NOT USE THE STABILIZER JACKS TO LEVEL THE RV. It is important to remember that the stabilizer jacks are to be used only for support while occupying and moving around the RV. They are not designed to support the weight of the RV.

  • Page 54: Emergency Stopping

    Section 4: Vehicle Operation Emergency Stopping Always carry road flares or reflective warning signs. Pull off the roadway as far as possible for emergency stopping. Turn ON your vehicle hazard warning flashers. If traveling at night, use three red warning indicators such as flares, reflectors or lanterns as required by the Uniform Vehicle Code and Model Traffic Ordinance as follows: Place the first warning indicator on the traffic side of the recreation vehicle, directed at the nearest approaching traffic.

  • Page 55: Wheel Lugs

    Section 4: Vehicle Operation Wheel Lugs After your first trip, check the wheel lug torque periodically for safety. Check the wheel lugs after winter storage, after a wheel removal, before starting a trip or following extensive braking: Use the correct star pattern sequence to attach the recreation vehicle wheels. Start all nuts by hand to prevent cross threading.

  • Page 56: Wheel Lug Nut Torque Values

    Section 4: Vehicle Operation Wheel Lug Nut Torque Values Prior to travel and after excessive braking, wheel lug nuts should be checked for torque. Torque readings must fall within the Final Torque Values in chart above. Torque specifications should be checked using a proper torque wrench. If the torque falls below the Final Torque Values, additional torque is required.

  • Page 57: Tires

    Section 4: Vehicle Operation Torque Wrench Usage Tools should be maintained, in good condition, and stored appropriately. • Avoid dropping or sliding a torque wrench. Dropping it can cause the instrument to lose reliable calibration. • Damaged tools must not be used and must be removed from service for evaluation and either reported and re-calibrated or replaced.
  • Page 58 Section 4: Vehicle Operation  Tire wear should be checked frequently. Once a wear pattern becomes firmly established in a tire it is difficult to stop, even if the underlying cause is cor- rected. Tire Pressure  Failure to follow proper inflation guidelines may result in tire failure, which, under certain circumstances can cause loss of vehicle control or accidents that may result in property damage, bodily injury and/or death.

  • Page 59: Changing A Tire

    Section 4: Vehicle Operation NOTE: Cold tire inflation pressure is defined as a tire that has not been used for three or more hours, or has been driven less than one mile. Tire inflation pressure of a hot tire may show an increase of as much as 6 psi over a cold tire.

  • Page 60: Spare Tire Carrier (If So Equipped)

    Section 4: Vehicle Operation Keep the recreational vehicle attached to the tow vehicle. Block the tire on the opposite side of the recreational vehicle from the tire you are changing. Loosen the wheel lug on the tire you are changing before jacking up the vehicle. DO NOT remove the lug nuts;...

  • Page 61: Bumper Mount

    Section 4: Vehicle Operation NOTE:If the manual crank access port is located in a slideout, the slideout room must be in the travel position to allow the crank to reach the mechanism used to raise or lower the tire. Crank Access Port Securing the spare tire To secure the spare tire in the travel position, put the steel hoist lift support located on the end of the cable through the rim of the tire.

  • Page 62: Setting Up Your Recreation Vehicle

    Section 4: Vehicle Operation Vinyl Tire Cover (if so equipped) Your tires are manufactured with components that cause “bleeding” onto the tire cover. To prevent this, it is recommended to use a separator (garbage bag, paper, cloth, etc.) between the tire and the cover. Setting Up Your Recreation Vehicle Position the RV as desired.

  • Page 63: Awning Care

    Section 4: Vehicle Operation Awning Care Keep your awnings clean and in good condition to prevent costly repairs. Periodically check that the fasteners are tight. Tighten if necessary. Keep the awning fabric clean. For detailed cleaning information, refer to the manufacturer’s owner information.
  • Page 64 Section 4: Vehicle Operation Notes:...

  • Page 65: Electric Slide Room(S) (If So Equipped)

    Section 5: Slideout Systems Electric Slide Room(s) (if so equipped) The mechanical components of the slide out are gear driven. Electric powered slideout room systems have a manual override to allow you to extend or retract the slideout room(s) in case of a power loss.

  • Page 66: Slideout Overlap-Outside

    Section 5: Slideout Systems Operating the switch after the room is fully extended or retracted may damage the switch and motor. After the slideout is extended, visually inspect the slideout and the surrounding area to make sure the slideout has extended properly and has adequate clearance from any outside obstructions.
  • Page 67 Section 5: Slideout Systems NOTE: For long-term storage it is recommend the room be closed (retracted). Trouble shooting the flush floor slideout Refer to the general troubleshooting check list before proceeding. Electric Operation NOTE: Install transit bars (if so equipped) on the slideout room during storage and transportation.

  • Page 68: Schwintek In-Wall Slideout System

    Section 5: Slideout Systems Schwintek In-Wall Slideout System The in-wall slideout system requires no maintenance or adjustments. This system has two vertical columns with a drive motor located at the top of each column. The right and left motors are synchronized by a circuit board. Schwintek slideouts are typically used on both towables and motorhomes.
  • Page 69 Section 5: Slideout Systems This slideout system requires very little maintenance. It contains a pre-lubed bearing that is lubricated when the room is moved in and out. Do not spray oil or grease on the rails while the room is extended. Trouble shooting the in-wall slideout system Checking Fuses: The in-wall slide requires a minimum 30-amp fuse.
  • Page 70 Section 5: Slideout Systems The red and green LED’s will flash indicating you are in override mode. Release the mode button. Using either a wall or command center panel switch, press and hold the switch toward the word IN or RETRACT until the unit comes in completely. This will allow you to get the recreation vehicle to a service center to have the slideout malfunction diagnosed.

  • Page 71: Error Codes

    Section 5: Slideout Systems The room must be travel locked to keep the room in place for road travel.  DO NOT MOVE THE RV UNLESS THE MOTORS ARE PLUGGED IN TO THE CONTROLLER AND THERE IS BATTERY POWER TO THE RV.

  • Page 72: Norco Slideout Manual Operation

    Section 5: Slideout Systems Norco Slideout Manual Operation Locate the included flexible shaft in your own- er’s packet. Attach flexible shaft to the 1/4” hex fitting on the end of the motor. Attach 1/4” socket & ratchet, or drill to the other end, and turn in the proper direction to move the room.
  • Page 73 Section 5: Slideout Systems  When the motor brake is disengaged the slideout room WILL NOT lock into place and will not be sealed. When the room has been manually retracted, be sure to install transit bars (if so equipped) and return the motor brake lever to its normal engaged position in order to seal and lock the room into position.

  • Page 74: Power Gear Slim Rack Slideout System

    Section 5: Slideout Systems 10. Install the transit bars (if so equipped) to the slideout room and take the unit to an authorized dealer for service. Refer to the Power Gear® Electric Slideout Operation Manual for detailed operation, safety and troubleshooting information. Power Gear Slim Rack Slideout System The Power Gear®...
  • Page 75 Section 5: Slideout Systems Release the OUT button when the room is fully extended or the IN button when fully retracted, and stops moving. Turn OFF the on/off switch or key. Fault Diagnostics / Troubleshooting:

The control has the ability to detect and display several faults.
  • Page 76 Section 5: Slideout Systems Check 2-pin power con- Supply voltage to con- nector at control box. If Minor trol box is 17 0 V DC or the voltage is 17. VDC or greater higher, contact O.E.M for power and ground supplies -Set parking brake (if ap- -Parking brake not set plicable)
  • Page 77 Section 5: Slideout Systems Emergency Retract Mode Use this procedure when there is NO loss of power or electrical problem with the system. Remove the touchpad (Fig 4) from the wall. Prior to clearing the MAJOR fault, record the number of RED &...

  • Page 78: Power Gear Ram Slideout System

    Section 5: Slideout Systems NOTE: One person on each side of the room with a ratchet and socket will expedite the process. Room moves ¼ inch for every 30 to 40 degree turn of the wrench. Secure the room in place by either: Re-installing the motors (making sure the end of the retaining screw is re-hooked to the motor spring clip (Fig 10A).
  • Page 79 Section 5: Slideout Systems Use the following steps to mechanically operate the room: Locate the ABS motor access cover for the slideout. This cover will be located inside one of the storage compart- ments under the slide room up at the top of the compart- ment.
  • Page 80 Section 5: Slideout Systems 12. Return the brake release lever back to the “engaged” position (parallel to the spring lock lever). Pressing the bent end of the spring lock lever will allow the brake lever to be moved. 13. Plug the motor connector back in again. 14.

  • Page 81: Section 6: Electrical System

    Section 6: Electrical System The Electrical System The RV electrical system is comprised of two independent electrical systems. One operates off of 12-volt DC power and the other off of 120-volt 60hz AC power. All installations have been made in compliance with industry standards applicable on the date of manufacture. Because the electrical equipment and associated circuitry are engineered into a dedicated system specific to your RV, do not make unauthorized changes or add fixed appliances to it.

  • Page 82: Command Center

    Section 6: Electrical System Command Center The command center is typically located inside the entrance door or in the living area of the RV, and contains switches and controls for various electrical functions. Command center applications, con- figurations and components will vary by model. Command Center Panel or Command Center Panel with Switch Modules Items found on these panels may include:...

  • Page 83: Gfci Receptacle

    Section 6: Electrical System GFCI Receptacle There is a ground fault current interrupter (GFCI) engineered into the electrical system. It is designed to reduce the possible injury caused by electric shock. The GFCI will not protect against short circuits or circuit overloads. Test all GFCI receptacles monthly: Push in the GFCI “TEST”...
  • Page 84 Section 6: Electrical System NOTE: If a device does not appear on your touchscreen then that particular system is not installed on your RV. Awning Operation: Select the AWNING icon; the screen opens showing the awnings (Fig 5). If there are multiple awnings, there will be a selection for each awning at the left of the screen.

  • Page 85: 5-Way And 8-Way Power Remote (If So Equipped)

    Section 6: Electrical System DSI FLT - Direct Spark Ignition Fault (if so equipped): This light above the GAS water heater switch on the Command Center panel indicates a problem with the LP portion of the water heater. When the GAS switch is turned on, the light will blink quickly 3 times and the water heater will ignite.
  • Page 86 Section 6: Electrical System Reset the handheld remote PIN code Press the silver “HOME” button to turn the remote ON. Press and release the “HOME” button five times. The button with a picture of a key changes to the word “CONFIG”. Press the “CONFIG”...
  • Page 87 Section 6: Electrical System Important remote control operating information Never attempt to operate a slide-out, awning, stabilizer jack, landing gear, etc from the handheld remote and a corresponding switch (at the command center) at the same time. Doing so can blow one or more fuses on the multi-function receiver.
  • Page 88 Section 6: Electrical System Batteries The remote is equipped with rechargeable batteries along with a charger. There are no user replaceable batteries.

  • Page 89: Testing The Campsite Power Connection

    Section 6: Electrical System Testing the Campsite Power Connection The campsite 120-volt power receptacle(s) should always be tested for proper function- ality prior to plugging the recreation vehicle shore power cord into it. Campsite 120-volt power receptacles can be tested using a digital multimeter or a dedicated circuit analyzer.

  • Page 90: Inverter (If So Equipped)

    Section 6: Electrical System Turn “off” the load center main 120-volt circuit breaker. Carefully extend the entire length of the power cord (approximately 25’-35’) from the electric cable hatch to the external power source. Plug the power cord into the receptacle. Be sure all the power cord prongs are properly plugged into the receptacle.

  • Page 91: Power Converter

    Section 6: Electrical System The STATUS and DISPLAY indicators indicate the inverter status: • STATUS & DISPLAY LEDS - both GREEN - Unit is plugged into shore power. The panel is in Bypass Mode and will display battery voltage in DC volts. •...
  • Page 92 Section 6: Electrical System • Reverse polarity fuse provides protection for the converter when a battery is used. If the battery is connected backwards to the fuse board this fuse would blow pre- venting damage to the converter. If your lights are dimming or flickering that usually indicates an overloaded con- •...

  • Page 93: Converter With Charge Wizard (If So Equipped)

    Section 6: Electrical System Converter with Charge Wizard (if so equipped) Some converters may be equipped with a charge wiz- ard There are (3) possible charging modes; NORMAL, BOOST and STORAGE. The charge wizard will auto- matically select the best mode to charge your battery. A green LED next to the wizard mode button will indicate by flashes, which mode is currently being used.

  • Page 94: Auxiliary Battery (Customer Supplied)

    Section 6: Electrical System Replacing a Fuse Before replacing a fuse, always turn off the electrical components protected by it. Disconnect the shore power cord. Turn “off” the inverter (if so equipped). Disconnect the house or auxiliary batteries main negative battery cable. Remove the fuse panel cover to check fuses.

  • Page 95: Dry Camping

    Section 6: Electrical System Dry Camping The auxiliary battery should be fully charged prior to dry camping. If the auxiliary battery is not being recharged and power is being drawn from it, it will eventually discharge. A battery will discharge at a faster rate as its energy level becomes depleted. Plan your electrical us- age accordingly.

  • Page 96: Load Center

    Section 6: Electrical System Rotating Dial Disconnect Switch When this switch is ON, there will be a green area showing a “1” along the top of the switch. To turn the switch OFF, turn it counter-clockwise until you see the red area along the left side of the switch showing a “0”...
  • Page 97 Section 6: Electrical System NOTE: Load Centers may not always include a main circuit breaker.  Circuit breakers and fuses will not offer complete protection of the electrical system in the event of power surge or voltage spike. Replacement Only replace circuit breakers with those of the same specified type, voltage, and current rat- ing.

  • Page 98: Approximate Electrical Load Ratings

    Section 6: Electrical System Approximate Electrical Load Ratings 12 VOLT SYSTEM Exterior Entertainment Center 5-7 AMPS 1.5 AMPS Furnace 12.0 AMPS Generator Start 95.0 AMPS* Illuminated Switch .125 AMP Inverter variable Leveling System 95.0 AMPS* LP Detector .125 AMP Light; Halogen 1.7 AMPS Light;...

  • Page 99: 120-Volt (30 Amp) Ac System (If So Equipped)

    Section 6: Electrical System 120-Volt (30 AMP) AC System (if so equipped) The 30 amp 120-volt 60hz AC electrical system.is designed to operate on 1 leg of 120-volt power at a maximum current flow of 30 amperes. Exposure to voltages higher or lower than a nominal 120-volts will damage or shorten the service life of the electrical system and appliances.

  • Page 100: 120-Volt (50 Amp) Ac System (If So Equipped)

    Section 6: Electrical System Always test the external power source (i.e., the campsite power receptacle or electrical box) with a ground monitor before connecting your power cord to it. If the ground monitor indi- cates ‘reverse polarity’ or an ‘open ground’ DO NOT connect the power cord. Regularly inspect the shore power cord for cuts, cracks, worn insulation and other damage.

  • Page 101: 50-Amp Power Cord (If So Equipped)

    Section 6: Electrical System 50-AMP Power Cord (if so equipped)  Do not hook up the power cord to any receptacle until you have verified proper polarity and grounding. Polarity indicators can be purchased in most electrical and hardware stores. Do not use any cheater plug, adapter or extension cord to reconfigure incoming AC power or break the continuity of the circuit connected to the grounding pin.

  • Page 102: Solar Prep (If So Equipped)

    Section 6: Electrical System Solar Prep (if so equipped) Your recreation vehicle may be wired with a (exterior) plug in that will allow the batteries to be trickle charged using a free standing solar panel. In most models, the solar panel kit is a customer purchased and installed option.

  • Page 103: Section 7: Fuel & Propane System

    Section 7: Fuel & Propane System Exhaust Gas Fumes  Avoid inhaling exhaust gases as they contain carbon monoxide, which is a potentially toxic gas that is colorless and odorless. If you are in a recreation vehicle with either a nearby tow vehicle engine running or the generator (if so equipped) running there is a potential for exhaust fumes to filter back into the recreation vehicle.

  • Page 104: Propane Gas Container

    Section 7: Fuel & Propane System Continued periodic checks of the propane system at 5,000 miles of travel (or at least once a year), by a qualified propane service representative as part of your normal maintenance is recommended. Hand tighten the LP gas system valves only, do not use a wrench or pliers as over tightening may damage the valve seals and cause them to leak.

  • Page 105: Servicing Or Filling

    Section 7: Fuel & Propane System Be sure to securely re-install DOT cylinder(s) after they have been removed for filling or replacement. Always close the service valve and install a dust cap or plug when transporting or storing disconnected containers whether full or empty. ASME tanks are permanently mounted to the RV and are commonly used on RV mo- torhomes.

  • Page 106: Do Not Fill To More Than 80%" Label

    Section 7: Fuel & Propane System The position of the propane container(s) and the hoses are critical to proper operation and propane flow. Follow these instructions to make sure your propane container(s) are con- nected properly. LP Gas Container Overfill Never allow your propane tank to be filled above the maximum safe level as indicated by the fixed liquid level gauge.

  • Page 107: Propane Regulator

    Section 7: Fuel & Propane System It also has a left-handed thread, which means that it is turned clockwise to remove, and counter-clockwise to tighten. The P.O.L. fitting has been designed to help restrict the flow of LP gas in the event of a regulator failure or hose malfunction. Propane Regulator ...

  • Page 108: Propane Use And Safety

    Section 7: Fuel & Propane System Propane Use and Safety Propane is a colorless and odorless gas that, in the liq- uefied state, resembles water. An odorant (usually a sulfur compound) is added as a warning agent. If you smell propane within the vehicle, quickly and carefully perform the procedure listed on the propane system la- bel.

  • Page 109: Cooking With Propane Gas

    Section 7: Fuel & Propane System If you have double cylinders on your recreation vehicle, use only one at a time. Otherwise, the propane supply will be drawn equally from both cylinders until the supply has been total- ly exhausted. Using one cylinder until it is empty, then using the second cylinder will allow you to fill the empty cylinder at your convenience without running totally out of propane.

  • Page 110: Traveling With Propane

    Section 7: Fuel & Propane System NOTE: Some states prohibit propane appliances to be operat- ed during travel, especially in underground tunnels. Make sure you know the laws for the areas where you travel. Traveling With Propane Use care when fueling your motor fuel tanks and/or propane containers.

  • Page 111: Main Supply Hose

    Section 7: Fuel & Propane System Double Cylinder Mounted On A-Frame (if so equipped) When a second cylinder is installed, a tee check valve is used to replace the 90° elbow at the top of the regulator and another 1/4” inverted flare x 24” Type 1 pigtail is added.
  • Page 112 Section 7: Fuel & Propane System...

  • Page 113: Section 8: Plumbing System

    Section 8: Plumbing System Plumbing System There are two different water systems in your recreation vehicle: The fresh water system consists of the fresh water holding tank, faucets and con- nections, water pump, outside shower assembly (if so equipped), water heater, tub/ shower, and water purification system (if so equipped).

  • Page 114: Fresh Water System

    Section 8: Plumbing System NOTE: When using shore power all 4 LEDs will light. If disconnected from shore power, 3 LEDs will light to indicate a full charge (4th LED may blink). The LEDs on the panel indicate the following: C = Charge at 12.7 volts G = Good at 12.1 volts F = Fair at 11.6 volts...

  • Page 115: Water Pressure Regulator (Customer Supplied)

    Section 8: Plumbing System Water Pressure Regulator (customer supplied) Excessive pressure from the water supply source may be encountered in some parks, espe-  A water pressure regulator is recommended to prevent damage to the plumb- ing system or components. To prevent damage when using the city water connection, a 45 lb.

  • Page 116: Draining The Fresh Water System

    Section 8: Plumbing System NOTE: In some models the water pump switch will be a black rocker switch located near the sink cabinet The water pump switch should be in the OFF position when the RV is left unattended for any amount of time. If something would happen to the water system, this may help limit water damage to a smaller area.

  • Page 117: Utility Center - 2 Valves (6 In 1)

    Section 8: Plumbing System Utility Center – 2 Valves (6 In 1) Your RV may be equipped with a small lockable en- closed docking station, which provides convenient ac- cess to certain plumbing system functions at one central location. The 6 in 1 utility center contains the following features: City water / tank fill valve Lighted white switch (switch itself acts as a light for the panel)
  • Page 118 Section 8: Plumbing System Fresh Water Connection Inlet The fresh water connection should be unplugged (i.e., the non-toxic drinking water hose disconnected) when the recreation vehicle is unattended for any amount of time. If something would happen to the water system, this may help limit water damage to a smaller area.
  • Page 119 Section 8: Plumbing System PRESSURE FILL WATER TANK: This setting will fill the water tank from a pressurized water source attached to the utility center panel. Set the blue CITY WATER / TANK FILL valve at the utility center to the TANK FILL position (horizontal) pointing to the left (as shown).
  • Page 120 Section 8: Plumbing System Place the clear suction hose into a container of sanitizer solution. Turn the pump switch ON and sanitizer will be drawn into fresh water tank. NOTE: Make sure you have sufficient 12V power and all drain valves are closed to create a siphon.

  • Page 121: Sanitizing The Plumbing System

    Section 8: Plumbing System the water heater. Bypass Mode operation diverts the flow of water around the water heater keeping water out of the water heater. Hot water bypass valve (B) should point away from water heat- er and inline with the hot water output. Cold water bypass valve (A) should point away from the water heater and inline with the cold water supply.
  • Page 122 Section 8: Plumbing System Put the sanitizer solution in the fresh water tank. Place the end of the clear plastic tub- ing (found inside the basement access panel or at the water pump) into a container of chlorine solution. Turn the black valve (at the pump) so it is pointing to the clear siphon hose. Turn the white valve (at the pump) so it is pointing to the left toward the water tank line (as shown in Sanitize Tank &...
  • Page 123 Section 8: Plumbing System 16. Pressure fill the fresh water tank (refer to Step 9). Set the 2 valve water heater bypass to NORMAL allowing water into the water heater. Refer to the 2-Valve Water Heater Bypass section. 17. Water valves at the water pump should be in the NORMAL position to allow water into the RV lines.

  • Page 124: Winterizing (With Utility Center)

    Section 8: Plumbing System 12. Remove full system canister, insert the filter, and re-attach canister to the mount. For 2-Valve Bypass (if so equipped), set the water heater bypass valves to the NORMAL position. 13. Refill the fresh water system with clean water. Use pressure fill or siphon fill method explained previously.

  • Page 125: Air Pressure Method

    Section 8: Plumbing System The preferred method to winterize your recreation vehicle is by using RV antifreeze in the plumbing system. Air Pressure Method  If the recreation vehicle is going to be stored in a non-temperature controlled environment with a risk of temperatures reaching 32°F (0°C) or lower, the air pressure method is not adequate, winterizing with RV antifreeze must be used in the plumbing system.

  • Page 126: Winterizing With Antifreeze Method

    Section 8: Plumbing System NOTE: Filters should be replaced at the beginning of the camping season or if they have come into contact with contaminated water or antifreeze. Run the water pump until it is dry (approximately 15 to 20 seconds). Operating the pump longer than that with no water in it can damage the pump.
  • Page 127 Section 8: Plumbing System NOTE: Antifreeze should never enter the hot water heater or the water filter. Turn power to the water heater OFF (both electric and LP gas switches. Level the recreation vehicle and drain the fresh water plumbing system. See Draining the Fresh Water System.

  • Page 128: Nautilus P2.5 Uni-Dock Utility Center

    Section 8: Plumbing System Drain the hose by holding it at a sloped angle to remove excess water, return hose to the stored location. As an added safety measure, drain the macerator bypass valve. De-winterize the macerator system: Emptying the black tanks in the spring will flush antifreeze out of the macerator system.
  • Page 129 Section 8: Plumbing System Rinse the black tank to help control odors and prevent waste buildup Connect up to (3) coax lines with SAT, CABLE and AUX • SAT input is wired only to the wall plate for the satellite receiver. •...
  • Page 130 Section 8: Plumbing System “POWER FILL TANK” (Pressurized fresh water source) Connect the fresh water hose to the City water connection inlet on the utility center. Set the color coded valves to POWER FILL TANK setting: Green handle pointing left Blue handle pointing down Water heater bypass lever - NORMAL Connect the other end of the hose to a pressurized fresh water source...
  • Page 131 Section 8: Plumbing System “SANITIZE” (or Siphon Fill) the Fresh Water Tank via Pump NOTE: Refer to the Sanitizing Plumbing System section for complete instructions on how to sanitize the water lines. “WINTERIZE” (plumbing lines and fixtures via pump) NOTE: Refer to the Winterizing Plumbing System section for complete instructions on how to winterize the water lines and fixtures.
  • Page 132 Section 8: Plumbing System Prepare a chlorine solution using 1/4 cup of household bleach (sodium hypochlorite solution) to one gallon (3.785 liters) of water in a container. Prepare one gallon of solution for every 15 gallons of tank capacity. This will result in a residual chlorine concentration of 50 ppm in the water system.
  • Page 133 Section 8: Plumbing System 12. Set the valves to the DRY CAMPING setting. Green valve points down Blue valve points to the right Water Heater Bypass valve is still set to BYPASS. 13. Turn the water pump ON and sanitized water will flow into the water lines from the water tank (when a fixture is opened).
  • Page 134 Section 8: Plumbing System Run water through all faucets (hot and cold, including outside shower and outside kitchen) until chlorine smell is gone. Turn all faucets and outside shower off, turn pump OFF. Drain the fresh water system again. If the RV has the full system canister water filter, remove the canister, reinstall the filter, and reattach the canister.

  • Page 135: Winterizing The Plumbing System

    Section 8: Plumbing System Open faucets and check that the chlorine smell is gone. 10. Drain the system one more time. 11. Replace the water filter: Canister filter: Turn off water valves at the canister filter. Remove canister lid, put filter back into canister, and replace the canister lid.

  • Page 136: Winterize With Air Pressure

    Section 8: Plumbing System The preferred method to winterize your recreation vehicle is by using RV antifreeze in the plumbing system. It may be easier to winterize the RV with another person to assist you.  If the recreation vehicle is going to be stored in a non-temperature controlled environment with a risk of temperatures reaching 32°F (0°C) or lower, the plumbing system must be winterized with RV antifreeze.

  • Page 137: Winterize The Black Tank Flush

    Section 8: Plumbing System Your RV may have one of two types of filters: Full System Canister Filter: Remove the canister lid, take out the filter and then re- attach the lid on the empty canister. Cartridge Water Filter: Remove the cartridge filter and replace it with a bypass hose (supplied with your RV).

  • Page 138: Draining The Spray Port

    Section 8: Plumbing System NOTE: If the RV has a macerator system, you need to open the bypass valve for the macerator under the RV. This will allow the black tank to drain through the 4” sewer hose. Attach a garden hose to the TANK FLUSH inlet at the utility center. Attach the other end of the hose to a pressurized water source.
  • Page 139 Section 8: Plumbing System Turn water heater power OFF. The Gas and Electric switches inside the RV at the Command Center should be OFF. The water heater should never be drained when HOT or under pressure. Level the RV and drain the fresh water plumbing system. Refer to Draining the Fresh Water System.
  • Page 140 Section 8: Plumbing System 15. Wipe any RV antifreeze out of the sinks, shower (or tub), toilet, washing machine tub, and dishwasher tub with a soft, dry cloth. Contact your dealer if you require further assistance.  Water can accumulate in the flexible hose and dump connector of the macera- tor system.

  • Page 141: Water Heater

    Section 8: Plumbing System Water Heater  Hydrogen gas may result if you have not used the water heater for two weeks or more. HYDROGEN GAS IS EXTREMELY FLAMMA- BLE. To reduce the risk of injury under these conditions, open the hot water faucet for several minutes at the kitchen sink before you use any electrical appliance connected to the hot water system.

  • Page 142: Anode Rod Replacement Chart

    Section 8: Plumbing System automatically attempt two more tries for ignition before lock-out occurs. NOTE: Each ignition cycle will have a 15 second purge before spark cycle if the system is a three try system. If lock-out occurs before the main burner lights, turn the water heater control switch to OFF, wait five seconds and turn the switch to the ON position.
  • Page 143 Section 8: Plumbing System To prevent a water leak when replacing the anode rod, a pipe thread sealant approved for potable water (such as Teflon tape) must be applied to the threads of the anode rod. Proper application of a thread sealant will not interfere with the anode’s function. High altitude deration Operation of the water heater at high altitudes may require derating.
  • Page 144 Section 8: Plumbing System Maintenance Do not allow the burner to burn with a yellow flame, or continue to operate the water heater with an improper burner flame. Periodically, inspect the water heater vent for soot. Soot is a sign of incomplete combustion and must be corrected before operating the water heater.

  • Page 145: Outside Shower (If So Equipped)

    Section 8: Plumbing System Open hot water faucet to a medium water flow. It may take a few seconds for the water to travel from the water heater to the faucet. To reduce temperature: ○ Turn GMC dial “counter-clockwise”. ○ Increase hot water flow.

  • Page 146: Faucets

    Section 8: Plumbing System Turn ON the hot and cold faucet knobs, and adjust the water temperature as desired. To activate the handheld shower turn ON the sprayer head attachment (some models). To turn off the water, always close the hot/cold control (faucet) knobs. The lever on the shower head will not completely stop the flow of water;...

  • Page 147: Black/Grey Water System And Tanks

    Section 8: Plumbing System Maintenance Refer the manufacturer’s user guide or label instructions for detailed cleaning information. The tub/shower walls are made of ABS plastic material. Use a mild detergent soap and warm water to clean. Do not use gritty or abrasive particle soaps or scouring compound to clean ABS plastic.

  • Page 148: Black And Grey Tank Drains

    Section 8: Plumbing System Some models are equipped with a side vent system. On these models this label will be next to the termination valve.This label should not be removed from your recreation vehicle. Black/Grey Water Holding Tanks Dump the gray and black water holding tanks before traveling to avoid carrying unnecessary weight.

  • Page 149: Macerator Pump System (If So Equipped)

    Section 8: Plumbing System To make drainage easier, level the RV. Remove the sewer hose housing dust cap, and at- tach the sewer hose (customer supplied). Place the end of the sewer hose into the approved dump station. Open the black tank dump valve (depending on Black/Grey Tank Drain and Valves your model the valve may be located under the RV, or on the utility center).
  • Page 150 Section 8: Plumbing System  Before operating the macerator pump, make sure the external dump hose is properly attached at the RV and at the dump station. The hose is under pres- sure and therefore waste is discharged under pressure. Failure to follow in- structions can lead to possible injury or property damage.

  • Page 151: Black Tank Flush (If So Equipped)

    Section 8: Plumbing System NOTE: The bypass valve also doubles as an emergency cutoff in the event of a problem with the flex hose or dump connector. Closing the valve stops waste flow out of the macerator pump and up to the flex hose, but will divert waste to the main dump connector under the RV.

  • Page 152: Black Tank Flush (If So Equipped)

    Section 8: Plumbing System  The black tank drain valve must be OPEN any time there is a hose (water supply) connected to the black tank flush. Do not leave any hose (water supply) connected to the black tank flush when it is not in use.

  • Page 153: Tank Heaters (If So Equipped)

    Section 8: Plumbing System  Do not use the same hose to fill your fresh (potable) water tank that is used for the black tank flush. Tank Heaters (if so equipped) Your recreation vehicle may be equipped with heaters for the fresh, gray, black water tanks and the water lines or drain lines.

  • Page 154: Toilet

    Section 8: Plumbing System No maintenance on the heaters is required, only a periodic inspection for loose wires, dam- age, etc. For additional detailed information, refer to the tank heater manufacturer’s user guide. Toilet The toilet is efficient and easy to operate. Prior to using the sanitation system, it is strongly recommended to flush the toilet several times to release sufficient water into the holding tank.

  • Page 155: Spray Port (If So Equipped)

    Section 8: Plumbing System Spray Port (if so equipped) Your RV may include a Spray Port on the exterior door side of the trailer. This Spray Port provides a way to rinse items off outside the RV or can be used to extinguish a campfire. There are no fau- cets to control (cold only) water flow.
  • Page 156 Section 8: Plumbing System Notes:...

  • Page 157: Section 9: Heating & Cooling

    Section 9: Heating & Cooling Air Conditioner The air conditioning system is controlled by a thermostat. Cooled air enters the RV through the grill. Make sure you have sufficient power available before operating the air conditioner. Do not operate the air conditioner without the return air filter. Operating the system without the filter allows the lint and dirt that is normally stopped by the filter to accumulate on the cooling coil of the air conditioner.

  • Page 158: Ceiling Fan (If So Equipped)

    Section 9: Heating & Cooling Ceiling Fan (if so equipped)  Be careful to avoid placing any object in the path of the ceiling fan blades! Turn the ceiling fan ON/OFF using an interior wall switch. The 3-speed ceiling fan is controlled by the pull chain switch.

  • Page 159: Fireplace (If So Equipped)

    Section 9: Heating & Cooling  The furnace should be inspected periodically (monthly during the heat- ing season) for presence of soot on the vent. Soot is formed whenever combustion is incomplete. This is a visual warning that the furnace is op- erating in an unsafe manner.
  • Page 160 Section 9: Heating & Cooling Notes:...

  • Page 161: Section 10: Appliances

    Section 10: Appliances Microwave  To prevent damage, remove the turntable from the microwave when trav- eling. Make sure you are connected to a 120-volt power source.  Never use the microwave cavity for storage. The microwave cavity should always be empty when not in use. For details on operation, cleaning and safety information, refer to the manufacturer’s user guide.

  • Page 162: Cooktops: Range And Oven (If So Equipped)

    Section 10: Appliances Cooking with Propane (if so equipped) See the Propane System Section for important safety instructions. Refer to the manufactur- er’s owner’s manual for detailed operating and safety instructions for all propane appliances. Cooktops: Range and Oven (if so equipped) For detailed operating and safety information, refer to the manufacturer’s user guide.

  • Page 163: Gas Drop-In Cooktops (If So Equipped)

    Section 10: Appliances  Do not use aluminum foil on the electric range cooktop, as this material will damage the cooktop surface if it melts. Do not use aluminum foil under any circumstances on the electric range cooktop. Gas Drop-In Cooktops (if so equipped) Depending on your model, it may be equipped with either a 2 burner or 3 burner cooktop.

  • Page 164: Gas Bbq Grill (If So Equipped)

    Section 10: Appliances Gas BBQ Grill (if so equipped)  Be sure to read, understand and follow all information supplied with your recreation vehicle concerning the use of propane before operating the BBQ grill. The propane hose must be correctly connected before lighting the grill.

  • Page 165: Gas Grill And Mounting

    Section 10: Appliances Rail Mount (if so equipped) Hang the grill bracket on the aluminum mount- ing strip located on the side of the recreation vehicle. Open the (2) folding arms on the bracket mak- ing sure they lock in position. Slide the grill onto the (2) arms against the stops.

  • Page 166: Range Hood (If So Equipped)

    Section 10: Appliances Range Hood (if so equipped) If your recreational vehicle is equipped with a range hood, it will be connected to an exterior vent. The vent has an inner flap with two snaps. This flap can be snapped shut when the vehicle is in motion, or during storage to keep insects, debris, snow, rain, etc.

  • Page 167: Cleaning The Interior

    Section 10: Appliances  The ice maker (if so equipped) should be turned off and the ice tray emptied when power to your recreation vehicle has been shut off. With no power, the ice will melt and water may “pool” in the refrigerator door. When power is restored, the vibration may cause this water to run out of the door and on to the vehicle floor.

  • Page 168: Cleaning The Exterior

    Section 10: Appliances If you need to clean the condenser: Remove the base grille. Use a vacuum cleaner with a soft brush to clean the grille, the open areas behind the grille and the front surface area of the condenser. Replace the base grille when finished.

  • Page 169: Water Heater - See Plumbing Section Outside Kitchen (If So Equipped)

    Section 10: Appliances Central Vacuum System The following is an overview of the central vacuum system operation. For detailed operat- ing and safety instructions, refer to the manufacturer’s user guide. The central vacuum system installed cleans virtually any surface with no electric cords and has a variety of attachments for many cleaning needs.

  • Page 170: Exterior Refrigerator

    Section 10: Appliances Disconnect the propane couple before stowing the outside kitchen unit. Make sure the kitchen unit is properly stowed and secured, and that the outside kitchen door is securely in place and locked before traveling. Attaching the “quick coupler” connection The “quick coupler”...
  • Page 171 Section 10: Appliances The drip pan attaches to tabs underneath the grill at each end. A handle is mounted in the middle of the drip pan to dump the contents. Refer to the grill user manual for further information. This grill is only available on certain RV models. ...
  • Page 172 Section 10: Appliances Notes:...

  • Page 173: Hdtv Antenna/Satellite System(S)

    Section 11: Electronics HDTV Antenna/Satellite System(s) HDTV Antenna (if so equipped) Your recreation vehicle is equipped with an exterior fixed height high definition TV antenna. This antenna rotates 360° and is capable of receiving any over-the-air (OTA) high definition television signals being broadcast in your receiving area.
  • Page 174 Section 11: Electronics Notes:...

  • Page 175: Cleaning The Interior

    Section 12: Interior Cleaning The Interior To keep the value of your recreation vehicle, perform regular maintenance using the proper materials and procedures. Using the wrong cleaner may result in damage to the surfaces in your vehicle. Check with the manufacturer’s information for the recommended cleaning agent.

  • Page 176: Cabinetry And Tables

    Section 12: Interior Mini Blinds: A simple dry rag may do the trick. If they are especially dirty, you can use cold or warm water to clean them; never use hot water. Fill a spray bottle with water and a tiny amount of soap. Then spray a lint-free towel with the mixture and use the towel to wipe down each slat.

  • Page 177: Abs Plastics

    Section 12: Interior NOTE: Oil based soaps and cleaners are not recommended. No abrasive cleaners or alcohol cleansers should be used. If other cleaner solutions are used, we recommend trying a spot in an incon- spicuous area. ABS Plastics Dust and wipe clean with soft, damp cloth or chamois, wiping gently. Do not use gritty or abrasive particle soaps or scouring compound to clean ABS plastic.

  • Page 178: Cube Sofa

    Section 12: Interior Cube Sofa The Cube Sofa functions similar to a residential futon. The slanted back pillows offer nu- merous options as a sofa, along with the ability to extend the cushions for additional sleeping space. Booth Dinette (if so equipped) The dinette is designed to seat up to four adults.

  • Page 179: Pantry Or Hutch (If So Equipped)

    Section 12: Interior Pantry or Hutch (if so equipped) Your recreation vehicle may have a pantry or hutch that you can use for storage. Make sure all items stored in the pantry or hutch are secured to prevent shifting during travel. This cabinetry has been designed to accommodate the normal camping items which may be bulky but not necessarily heavy.

  • Page 180: Flooring

    Section 12: Interior Run cold water when pouring hot/boiling water into the sink. Solid surface sink maintenance Occasionally, clean the solid surface sink by filling one-quarter full with a 50/50 water/ bleach solution. Let soak for 15 minutes, and then wash sides and bottom of sink as solu- tion drains.
  • Page 181 Section 12: Interior  The slide out must be fully extended before putting the Murphy bed in the sleeping position. The Murphy bed must be in the stored position before the slide out can be moved to the in (travel) position. Failure to do so may result in injury or property damage.
  • Page 182 Section 12: Interior  Snap hooks (if present) must be attached to the steel rings on the sofa arms before using the bed. Failure to attach these snap hooks to the steel loops on the sofa can result in serious injury or property damage. MAKE SURE THE SAFETY STRAPS AT EACH SIDE OF THE FOOTBOARD ARE ATTACHED TO THE STEEL LOOPS ON THE SOFA ARMS BEFORE PUT-...

  • Page 183: Bed Storage

    Section 12: Interior  Keep hands and fingers away from the collapsing footboard and struts when pushing the bed back in to the storage position. Secure the two “D” bolts on each side of the bed. Flip the sofa back up into the seated position: •...

  • Page 184: Gas Struts (If So Equipped)

    Section 12: Interior  Before lifting, be sure there is nothing on the bed that will restrict its movement or add extra weight. Use caution when opening or closing the bed to keep hands and fin- gers at the end ledge provided (not on the side or farther back than necessary).

  • Page 185: Bunk Beds (If So Equipped)

    Section 12: Interior Bunk Beds (if so equipped) Your recreational vehicle may be equipped with bunk style beds. Bunk bed weight ratings will vary depending on the style of bunk bed. Refer to the warnings for bunk beds below. Bunk Bed Ladder (if so equipped) Your recreational vehicle may be equipped with a ladder to access the upper bunk.
  • Page 186 Section 12: Interior  Exercise extreme care when entering or exiting the bunk beds and using the ladder (if so equipped). Do not allow more than one person on the top bunk. Do not allow children under 6 years of age to use the upper bunk. Do not allow horseplay on or under the bed and prohibit jumping on the bed.

  • Page 187: Cleaning The Exterior

    Section 13: Exterior Cleaning the Exterior To protect your recreation vehicle’s exterior finish, wash it often and thoroughly. For recreation vehicles with painted exterior graphics: If desired you may wash and wax your vehicle 60 days after purchase. The exterior paint does need time to cure before any wax is applied to the exterior surface.
  • Page 188 Section 13: Exterior Drying the recreation vehicle is just as important as washing your vehicle. Tap and well water contain many chemicals that could water stain your vehicle’s finish. We suggest using a damp natural or synthetic chamois. There are other drying products such as lint-free micro-fiber towels that work just as well.

  • Page 189: Frame

    Section 13: Exterior Polishing your recreation vehicle If painted surfaces have been severely damaged and have lost their original luster and color tone, polish the surface lightly with a fine polishing compound. Avoid limiting your polish- ing to the damaged surface only; polish a somewhat wider area, moving the polishing cloth in one direction.

  • Page 190: Exterior Roof And Sidewall Vents

    Section 13: Exterior Exterior Roof and Sidewall Vents Inspect the roof vents (including sealants) for cracks and keep them clean. Inspect the re- frigerator and holding tank vents for blockages from bird nests, spider webs, leaves, etc. All exterior access doors and vents need to be kept clean and free of obstructions (i.e., insect nests, mud daubers, etc.) while the appliances are in use.

  • Page 191: Sealants

    Section 13: Exterior  LADDER CAPACITY MAXIMUM 300 LBS (136 KG) DO NOT exceed the ladder maximum weight rating. The maximum rating includes the person’s weight PLUS weight of items carried. When climbing: ○ Always face the ladder. ○ Climb slowly with weight centered between side rails. ○...

  • Page 192: Fifth Wheels - Sealant Diagram

    Section 13: Exterior If you notice water inside the recreation vehicle, immediately have the dealer check for the source of the leak. Failure to correct the leak may result in serious damage to your recreation vehicle; this damage may not be warrantable. Although the following diagrams may not accurately reflect the exact model of your recre- ation vehicle, make sure you inspect all sealants as indicated in the text.

  • Page 193: Travel Checklist

    Section 14: Travel/Camping/Storage Checklists Travel Checklist Following is a preliminary list of items that need to be checked before leaving your home or campsite. This is a general list, which you may want to customize as you determine your own needs. Safety Make sure you follow all safety precautions noted in this owner’s manual and in any manufacturer’s operators manual when preparing to travel.

  • Page 194: Rv Storage

    Section 14: Travel/Camping/Storage Checklists Before leaving the campsite Check the area under the RV after overnight parking and look for water or other fluid leaks. If leaks are detected, find the cause and correct it immediately. Turn off propane tanks. Empty black and gray holding tanks, rinse as needed (if so equipped).
  • Page 195 Section 14: Travel/Camping/Storage Checklists Close the propane cylinder valve(s). We recommend using a propane cylinder cover, and to make sure the propane regulator is covered. If is equipped with a gas/ electric DSI range, light a range gas burner to consume any gas remaining in the lines.
  • Page 196 Section 14: Travel/Camping/Storage Checklists Notes:...

  • Page 197: Featured Components Quick Reference Chart

    Your recreation vehicle may be equipped with some of the items listed below. This is a partial listing and it is not intended to cover all components. All information is the latest available at the time of publication. Jayco reserves the right to change any of the following information without notice.
  • Page 198 Section 15: Additional Information Thermostat Coleman Mach www.airxcel.com/coleman-mach Toilet Thetford Corp. www.thetford.com See manufacturers’ user guide Winegard Company www.winegard.com TV Antenna King Jack www.kingconnect.com Water Heater, Tank DSI Atwood Greenbrier www.atwoodmobile.com Girard Systems www.greenrvproducts.com Water Heater, Tankless Truma AquaGo www.truma.com Shurflo East www.shurflo.com Water Pump, 12V...

  • Page 199: Vehicle Maintenance Record

    Section 15: Additional Information Vehicle Maintenance Record Make: Model: Model Year: Vehicle Serial#: Service Performed Mileage Work Performed Notes Date...

  • Page 200: Ownership Notification

    Section 15: Additional Information Jayco Ownership Notification Fax Form To: (800) 825-7876 ATTENTION! Federal record keeping laws require that we maintain a file of owners of our product. Your cooperation in filling out this from will be appreciated. □ □...
  • Page 201 Section 15: Additional Information Notes:...

This manual is also suitable for:

Eagle fw ht 2020Eagle fw htx 2020

Table of Contents
