2016 JAY FEATHER
TOWABLES
Generations of family fun.
PRINTED ON RECYCLED PAPER
0195624.2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2016 Jay Feather and is the answer not in the manual?

Questions and answers

Related Manuals for Jayco 2016 Jay Feather

Summary of Contents for Jayco 2016 Jay Feather

  • Page 1 2016 JAY FEATHER TOWABLES Generations of family fun. PRINTED ON RECYCLED PAPER 0195624.2016...
  • Page 3 44,683 people. We're proud of our results, and we know those numbers show that a little initiative can go a long way. The Jayco EcoAdvantage is our way of making sure endless generations can enjoy the Great Outdoors..
  • Page 5 Nothing in this manual creates any warranty, either expressed or implied. The only warranty offered by Jayco, Inc. is as set forth in the limited warranty applicable to this vehicle.

  • Page 6: Table Of Contents

    About This Manual ......................1-1 Customer Relations ......................1-5 Customer Responsibility ....................1-3 Dealer Responsibility ......................1-4 Jayco Customer First Emergency Roadside Assistance ............ 1-6 JayPlus™ Extended Service Contract ................1-6 Jayco Travel Club ......................1-6 Manufacturing Process ...................... 1-3 Jayco Towable Rental Limited Warranty ................
  • Page 7 Jay Feather Travel Trailer Table of Contents 4: T & S ECTION OWING Brake System ........................4-3 Breakaway Switch-Travel Trailer ..................4-4 Campsite Hook-up ......................4-8 Changing A Tire ......................4-12 Emergency Stopping ......................4-9 Emergency Towing ......................4-9 Entrance Door ........................4-4 Keyless Entry (If So Equipped) ..................
  • Page 8 Table of Contents Jay Feather Travel Trailers Propane Gas Container ..................... 7-2 Propane Gas System ......................7-1 Propane Leak Test ......................7-1 Propane Regulator ......................7-8 Propane Safety Procedures....................7-2 Traveling With Propane ....................7-11 Using The Propane System ....................7-8 8: P ECTION LUMBING...
  • Page 9 Jay Feather Travel Trailer Table of Contents 11: E ECTION LECTRONICS Television Power Supply .................... 11-1 Television Roof Antenna ....................11-1 12: I ECTION NTERIOR ABS Plastics ........................12-5 Booth Dinette (If So Equipped) ..................12-2 Cabinetry & Tables ......................12-3 Cleaning The Interior ....................
  • Page 10 Table of Contents Jay Feather Travel Trailers NTENTIONALLY LANK...

  • Page 11: About This Manual

    Thank you for selecting a Jayco Recreation Vehicle. We are excited to welcome you to our growing RV family. Jayco is the largest privately held manufacturer of recreation vehicles in the world. We are committed to being the most respected name in RVs.
  • Page 12 However, NHTSA cannot become involved in individual problems between you, your dealer or Jayco. For additional information, please refer to the NHTSA website at www.safercar.gov.

  • Page 13: Customer Responsibility

    If you believe your RV has an alleged safety defect, you should contact Transport Canada and Jayco. Transport Canada prefers to be called instead of posted mail or email as it enables their investigators to confirm that your information is correct, and to answer your questions accurately.

  • Page 14: Dealer Responsibility

    ONTACT NFORMATION Please notify Jayco Customer Service as soon as possible of a change of address by writing or calling us. For notification of a change of ownership, please fill out the appropriate form located in this manual and mail it to Jayco Customer Service along with documentation showing proof of ownership.
  • Page 15 (or any effect of the alterations) to any of the parts, components, systems or assemblies installed by Jayco. Jayco is not responsible for the safety or quality of design features, materials or workmanship of any alterations by such suppliers.

  • Page 16: Obtaining Emergency Warranty Repair

    Canada. In addition, the club offers a variety of local and regional activities throughout the year. By belonging to the Jayco Travel Club, you will find new ways to enjoy your RV and make friends all across the country.

  • Page 17: Obtaining Service At Jayco

    ERVICE AT AYCO Should your RV be in need of service, and your dealer recommend that the repairs be made at the Jayco Factory Service Center, your RV may be returned to us with the following guidelines*:  You or your dealer must make a confirmed appointment a minimum of 60 days prior to dropping off your RV at the Jayco Factory Service Center.

  • Page 18: Parts & Accessories

    Jayco’s limited warranty only covers substantial defects in materials, components, or parts of the RV attributable to Jayco. It does not replace, modify, or apply to the warranties provided by the manufacturers that supply the products used by Jayco to assemble the RV, like the frame.
  • Page 19 Jayco makes no warranty of any nature beyond that contained in this limited warranty. Jayco does not authorize any person to create any other obligation or liability for it regarding this RV, and Jayco is not responsible for any representation, promise or warranty made by any dealer or other person beyond what is expressly stated in this limited warranty, and no one has the authority to enlarge, amend or modify this limited warranty.
  • Page 20 Jayco; any RV used for rental or other commercial purposes (Note: It shall be concluded that the RV has been used for commercial and/or business purposes if the RV owner or user files a tax form claiming any business or commercial tax benefit related to the RV, or if the RV is purchased, registered or titled in a business name);...
  • Page 21 Jayco product warranty registration form. That form must be returned to Jayco within ten (10) days of your taking delivery of the RV. Your Jayco warranty will not be registered unless this warranty registration is completed and received by Jayco. Failure...

  • Page 22: Towable Limited Tent Warranty

    Bunk Ends with Tents, Only) WHAT AND WHO IS COVERED The Jayco limited tent warranty covers the tents on the bunk ends of the slide rooms of this travel trailer, when the RV is used only for its intended purpose of recreational travel and camping.
  • Page 23 Towable Limited Warranty will not apply to this RV. The Towable Limited Rental Warranty applies in that situation. If, on the other hand, the Jayco dealer sells this RV to a retail customer then the rental warranty would not be applicable. The rental warranty does not apply to retail consumers.
  • Page 24 Jayco reserves the right to make changes in the design or material or its products without incurring any obligation to incorporate such changes in any product previously manufactured.
  • Page 25 Pay any freight or transportation costs, import duties, fees and all incidental expenses associated with obtaining warranty service. If you need assistance you may contact Jayco, at 903 S. Main Street, P. O. Box 460, Middlebury, Indiana, 46540, Attn: Customer Service (574) 825-5861, (800) 283-8267 or www.jayco.com.
  • Page 26 Jayco. If you find any such defect or damage you must notify Jayco within three (3) days of delivery of the RV to you to have these items covered by this limited warranty and to have work performed on the items covered by this limited warranty.
  • Page 27 SECTION 1–WARRANTY & SERVICE JAYCO TOWABLE THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE. JAYCO, INC. 903 S. Main Street * P.O. Box 460 * Middlebury, IN 46540...
  • Page 28 JAYCO TOWABLE SECTION 1–WARRANTY & SERVICE HIS PAGE LEFT INTENTIONALLY BLANK 1-18...
  • Page 29 SECTION 2-OCCUPANT SAFETY JAYCO TOWABLE ECONDARY EANS OF SCAPE INDOW Your recreation vehicle has been equipped with a window(s) that serves as a secondary means of escape. The window(s) will allow a quick exit from the vehicle during an emergency if access to the main entrance door is not available. Its red latches and label easily identify it.

  • Page 30: Safety

    JAYCO TOWABLE SECTION 2-OCCUPANT SAFETY AFETY If a fire does start, follow these basic safety rules: Have everyone evacuate the vehicle immediately. After everyone is clear and accounted for, check the fire to see if you can attempt to put it out.
  • Page 31 SECTION 2-OCCUPANT SAFETY JAYCO TOWABLE MOKE LARM Some of the most common fire safety issues are burning candles, smoking in bed, leaving children unattended and cleaning with flammable fluids. The smoke detector is intended to help reduce those risks. Your vehicle is equipped with a smoke alarm that is listed for use in Recreation Vehicles.

  • Page 32: Combination Carbon Monoxide/Propane Alarm

    JAYCO TOWABLE SECTION 2-OCCUPANT SAFETY OMBINATION ARBON ONOXIDE ROPANE LARM Your RV is equipped with a combination carbon monoxide (CO)/propane alarm that is listed for use in recreation vehicles. The combination carbon monoxide/ propane alarm will only work if it is operational and maintained.
  • Page 33 SECTION 2-OCCUPANT SAFETY JAYCO TOWABLE This carbon monoxide alarm is designed to detect carbon monoxide gas from ANY source of combustion. It is not designed to detect smoke, fire or any other gas. Please note that there are hazards against which carbon monoxide detection may not be effective, such as natural gas leaks or explosions.
  • Page 34 JAYCO TOWABLE SECTION 2-OCCUPANT SAFETY Alarm Signals  Normal Operation: The LED will maintain a steady green light, indicating that the alarm is powered.  CO alarm condition: The red LED light will remain steady and the alarm will sound 4 “BEEPS”...

  • Page 35: Cold Weather Usage

    SECTION 2-OCCUPANT SAFETY JAYCO TOWABLE The following label is located inside the vehicle near the entry door. The label should be left permanently affixed to the recreation vehicle: XTENDED SAGE Your new recreation vehicle has been built for enjoyment in a recreational manner. It is not intended for use as full-time quarters or a permanent residence.
  • Page 36 JAYCO TOWABLE SECTION 2-OCCUPANT SAFETY To reduce condensation Proper ventilation and, if needed, the use of a dehumidifier (customer supplied) will assist in controlling condensation. Many RV and marine dealers carry small dehumidifiers sized for RV use. Other suggestions are: ...

  • Page 37: Section 3-Pre-Travel Information

    The factory-installed weight labels are specific to the recreation vehicle for which they are supplied and are not interchangeable. Do not remove these labels from your If labels are missing, contact your dealer or Jayco Customer Service for replacements. EIGHT ERMS GAWR - GROSS AXLE WEIGHT RATING –...
  • Page 38 RV tires is (9,000 – 1,200) which equals 7,800 lbs. which is within the weight rating of the tires. If you have further questions, please contact your dealer or Jayco Customer Service. Federal Certification Label: The Federal Certification Label is required by...

  • Page 39: Cargo Carrying Accessory Receiver (If So Equipped)

    SECTION 3-PRE-TRAVEL INFORMATION JAYCO TOWABLE OADING WARNING Never load the RV in excess of the GAWR for either axle. Overloading your RV may result in adverse handling characteristics and damage to the chassis. WARNING Your recreation vehicle’s load capacity is designated by weight, not by volume, so you cannot necessarily use all available space when loading the vehicle.

  • Page 40: Rear Bumper

    RV’s GVWR and the hitch weight. CAUTION Using an oversized or undersized hitch can cause damage to the RV frame. Jayco cannot be responsible for the tow vehicle suspension system. The final ball height after the tow vehicle/travel trailer combination is completely hooked up is a factor that must be considered.
  • Page 41 SECTION 3-PRE-TRAVEL INFORMATION JAYCO TOWABLE Make sure your dealer is aware of the tow vehicle you are using so a compatible hookup is achieved. Travel trailer hitch weight Maintain the proper tongue weight of the trailer. Stay within the target range of 10%-15% of the overall gross weight (travel trailer weight plus contents).
  • Page 42 JAYCO TOWABLE SECTION 3-PRE-TRAVEL INFORMATION Crisscross the left safety chain under the coupler and attach to the right mounting slot in the trailer hitch; repeat with the right safety chain. Slack for each length should be the same but not more than necessary to permit the vehicle to turn at its minimum radius.
  • Page 43 SECTION 3-PRE-TRAVEL INFORMATION JAYCO TOWABLE Remove the dolly wheel or platform and retract the tongue jack to its maximum height. Attach the breakaway switch cable to the tow vehicle. 10. Attach the safety chains. 11. Plug in your wire harness/connector plug from the tow vehicle to the travel trailer.
  • Page 44 JAYCO TOWABLE SECTION 3-PRE-TRAVEL INFORMATION WARNING If you exceed the GVWR, you MUST remove items from the RV, or drain liquids, then re-weigh the vehicle to ensure you have achieved a safe weight. Weight labels are posted inside your recreation vehicle so you can make a decision before you buy about how much cargo capacity is important for you personally.
  • Page 45 SECTION 4-TOWING & SET-UP JAYCO TOWABLE OWING WARNING Your RV braking system is rated for operation at GVWR not GCWR. WARNING Whenever possible, do not travel with waste in the holding tanks. Liquid or debris in the holding tank(s) may affect the towing characteristics and may result in property damage or personal injury.
  • Page 46 If you do not have a Jayco factory installed hitch receiver, towing items behind your Jayco RV, or overloading the rear, will void the warranty and may result in: damage to the RV or add-on items, towing difficulties, property damage and/or personal injury.

  • Page 47: Wire Harness/Connector Plug

    SECTION 4-TOWING & SET-UP JAYCO TOWABLE RAKE YSTEM WARNING Failure to maintain the brakes in proper working condition as specified in the operator’s manual supplied by the axle OEM will cause property damage, personal injury and possibly death. Consult with your dealer for assistance The electric brakes are designed to work with the tow vehicle brakes.
  • Page 48 JAYCO TOWABLE SECTION 4-TOWING & SET-UP RAVEL RAILER REAKAWAY WITCH CAUTION NEVER use the breakaway switch and trailer brake system as a parking brake. Doing so would create a high amp draw on the battery and converter. This can cause damage to wiring, connectors and the breakaway switch.
  • Page 49 SECTION 4-TOWING & SET-UP JAYCO TOWABLE NOTE: Locks on entrance and baggage doors need biannual lubrication using a light coat of silicone spray. Conditions such as rain, salt, dust and pollution may increase the maintenance needs. EYLESS NTRY IF SO EQUIPPED If your RV is equipped with a keyless entry system, it is a battery operated system.
  • Page 50 JAYCO TOWABLE SECTION 4-TOWING & SET-UP The lock will cycle up to 10 more times once the low battery indication occurs. After this the final electric function in a low battery condition will be unlock and will not lock until the batteries have been replaced.
  • Page 51 SECTION 4-TOWING & SET-UP JAYCO TOWABLE Trouble shooting After installation the touch pad does not work  Batteries are dead  Batteries are not installed properly  Plug not engaged properly  Dead Bolt not engaging into Door Frame ...

  • Page 52: Leveling The Rv

    JAYCO TOWABLE SECTION 4-TOWING & SET-UP AMPSITE  Refer to Electrical System section before connecting the shore line power cord (when using full hook-up) OR before starting the generator (if so equipped) or operating the vehicle on 12-volt power when dry camping.
  • Page 53 SECTION 4-TOWING & SET-UP JAYCO TOWABLE WARNING DO NOT USE THE STABILIZER JACKS TO LEVEL THE RV. It is important to remember that the stabilizer jacks are to be used only for support while occupying and moving around the RV. They are not designed to support the weight of the RV.

  • Page 54: Tires

    JAYCO TOWABLE SECTION 4-TOWING & SET-UP  NOTE: The proper method of tightening wheel lug nuts is with a properly calibrated torque wrench and socket, not with an impact wrench or by hand. Do not use a 4-way lug wrench or any other type of wrench that does not measure the actual pressure applied to the lug nut.
  • Page 55 SECTION 4-TOWING & SET-UP JAYCO TOWABLE DANGER Failure to follow proper inflation guidelines may result in tire failure, which, under certain circumstances can cause loss of vehicle control or accidents that may result in property damage, bodily injury and/or death.
  • Page 56 JAYCO TOWABLE SECTION 4-TOWING & SET-UP CAUTION Tire wear should be checked frequently. Once a wear pattern becomes firmly established in a tire it is difficult to stop, even if the underlying cause is corrected. When you are using your vehicle, check inflation pressure weekly to insure maximum tire life and travel wear.
  • Page 57 Any service or warranty coverage on tires is to be handled by the tire store representing the brand installed on your RV. They are not to be returned to your dealer or Jayco. WARNING When replacing a tire make sure to replace it with a tire of the same size and specifications (refer to the Federal Certification label.)
  • Page 58 JAYCO TOWABLE SECTION 4-TOWING & SET-UP To secure the spare tire in the travel position: Put the steel hoist lift support located on the end of the cable through the rim of the tire. The hoist lift support clips need to seat inside the center hole of the tire rim. The valve stem of the tire MUST be pointed in the up position or toward the bottom of the trailer.
  • Page 59 SECTION 4-TOWING & SET-UP JAYCO TOWABLE RAVEL RAILER Position the RV as desired. Level the RV (side-to-side). Block the wheels securely to prevent the RV from moving. Unhook the wire harness/connector plug, safety chains and breakaway switch lanyard. Install the dolly wheel or platform.
  • Page 60 JAYCO TOWABLE SECTION 4-TOWING & SET-UP Well in advance of your first trip, set up your new RV. Use a garden hose and thoroughly soak the tent with a light spray of water (do not spray directly on the tent with a high pressure hose).
  • Page 61 SECTION 4-TOWING & SET-UP JAYCO TOWABLE Tent canvas, exterior side view (rear) From the interior, place the C-shaped end of the bed bow brace onto the bed bow connector (Fig. A). Push the bed bow brace outward and upward while pressing the second button from the curved end of the bed bow brace.
  • Page 62 JAYCO TOWABLE SECTION 4-TOWING & SET-UP Closing the beds NOTE: The front bed mat will be the easiest place to store the side and rear bed bow braces. Starting with the front bed will enable you to take the bed bow braces off of the rear and side and immediately store them.
  • Page 63 SECTION 4-TOWING & SET-UP JAYCO TOWABLE From the exterior, latch the other side of the door. NOTE: If the bed does not close easily, inspect the bed cushion from the sides looking for obstructions. Once the obstruction is located, lower the bed board, correct the obstruction and try again.
  • Page 64 JAYCO TOWABLE SECTION 4-TOWING & SET-UP HIS PAGE IS INTENTIONALLY BLANK 4-20...

  • Page 65: Section 5-Slideout Systems

    SECTION 5-SLIDEOUT SYSTEMS JAYCO TOWABLE lectric Slide Room System (If So Equipped) WARNING Make sure the interior slideout room path and the slideout room itself is clear of people and objects before operating. Keep away from the slide rails and gear assembly when the room is in motion.
  • Page 66 JAYCO TOWABLE SECTION 5-SLIDEOUT SYSTEMS Most slideout switches are located on the monitor panel or on the wall. To move the room out, press the OUT section of the switch and hold it until the motor stops (travel time is approx. 25 seconds). Operating the switch after the room is fully extended will damage the switch and motor.

  • Page 67: Troubleshooting The Slideout

    SECTION 5-SLIDEOUT SYSTEMS JAYCO TOWABLE ROUBLESHOOTING LIDEOUT If the slideout does not move when the slideout switch is depressed, follow these steps.  Check the auxiliary battery (customer supplied) for a full charge and good wire connections.  Check the 12-volt fuse or circuit breaker.
  • Page 68 JAYCO TOWABLE SECTION 5-SLIDEOUT SYSTEMS The following decal should remain permanently affixed to your RV. If you have any questions regarding the rear wall slideout system, please contact your dealer or our customer service department. Rear bed slideout label M-Tec sofa slideout override In the event of a power failure or low battery, the slide-out room may be operated manually with a 5/8”...
  • Page 69 SECTION 6-ELECTRICAL SYSTEMS JAYCO TOWABLE he Electrical System The RV electrical system is comprised of two independent electrical systems. One operates off of 12-volt DC power and the other off of 120-volt 60hz AC power. All installations have been made in compliance with industry standards applicable on the date of manufacture.
  • Page 70 JAYCO TOWABLE SECTION 6-ELECTRICAL SYSTEMS FCI R ECEPTACLE Grounding is your personal protection from electrical shock. Each recreation vehicle has a ground fault current interrupter (GFCI) engineered into the electrical system. This device has been designed to reduce the possible injury caused by electric shock. The GFCI will not protect against short circuits or circuit overloads.
  • Page 71 SECTION 6-ELECTRICAL SYSTEMS JAYCO TOWABLE onnecting The Power Cord WARNING Plugging the shoreline power cord into an incorrectly wired power source could damage the recreation vehicle electrical system and result in severe or fatal injury. Always test the external power source (i.e., the campsite power receptacle or electrical box) with a ground monitor before connecting your power cord to it.
  • Page 72 JAYCO TOWABLE SECTION 6-ELECTRICAL SYSTEMS Charge Wizard Operation Wizard The built in Charge Wizard will automatically determine the best mode to charge your battery. It will select between 3 possible modes of battery charging; NORMAL, BOOST or STORAGE. A Green LED (next to the Wizard Mode Button) will...

  • Page 73: 12-Volt Dc Outlet (If So Equipped)

    SECTION 6-ELECTRICAL SYSTEMS JAYCO TOWABLE VOLT ANEL The 12-volt fuses are located in the Load Center. They are labeled to indicate fuse sizes, positions and the components powered. At the beginning of camping season, inspect all the 12-volt fuses in the Load Center and replace as needed.
  • Page 74 JAYCO TOWABLE SECTION 6-ELECTRICAL SYSTEMS WARNING Keep the protective dust cap on the 12-volt DC outlet when not in use to prevent ingestion of foreign material and potential short circuit conditions. uxiliary Battery (Customer Supplied) Your recreation vehicle has many 12-volt DC loads. When combined, their total is more than the converter can produce.

  • Page 75: Battery Disconnect Switch (If So Equipped)

    SECTION 6-ELECTRICAL SYSTEMS JAYCO TOWABLE ATTERY ISCONNECT WITCH QUIPPED The Battery Disconnect switch is located in an enclosed exterior compartment at the front of the recreation vehicle. This switch shuts off all 12VDC power to the main 12V fuse panel, and the interior of the vehicle.
  • Page 76 JAYCO TOWABLE SECTION 6-ELECTRICAL SYSTEMS PPROXIMATE LECTRICAL ATINGS 12 Volt System Aisle Lights 1.0 AMP Baggage Compartment Lights 1.4 AMPS Decorative Wall Lights 1.5 AMPS Dinette Light 4.5 AMPS Exterior Entertainment Center 5-7 AMPS Fantastic Fan 1.5 AMPS Fluorescent Double Lights -12”...

  • Page 77: Replacing Light Bulbs

    SECTION 6-ELECTRICAL SYSTEMS JAYCO TOWABLE EPLACING IGHT ULBS Before replacing a bulb, be sure the light is off. Do not touch the glass part of the new bulb with your bare fingers. The skin oil left on the glass will evaporate when the bulb gets hot, the vapor will condense on the reflector and it will dim the surface.
  • Page 78 JAYCO TOWABLE SECTION 6-ELECTRICAL SYSTEMS The 30 amp external utility power cord is commonly referred to as the “shore” power cord. It is designed to mate and properly function with 30 amp “shore” power receptacles available at most campgrounds. The shore power cord is designed to continuously carry the 30 amp current flow required to power each leg of the electrical system.

  • Page 79: Systems

    SECTION 7-PROPANE SYSTEMS JAYCO TOWABLE ROPANE YSTEM Propane or LP (liquefied petroleum) gas is a clean and efficient form of energy when proper handling and safety precautions are observed. The propane system in your recreation vehicle furnishes the fuel for cooking, heating and hot water. Propane can also...

  • Page 80: Propane Safety Procedures

    JAYCO TOWABLE SECTION 7-PROPANE SYSTEMS ROPANE AFETY ROCEDURE Propane is a colorless and odorless gas that, in the liquefied state, resembles water. An odorant (usually a sulfur compound) is added as a warning agent. If you smell propane within the vehicle, quickly and carefully perform the procedure listed on the label below.
  • Page 81 SECTION 7-PROPANE SYSTEMS JAYCO TOWABLE Be sure to securely re-install DOT cylinder(s) to the recreation vehicle after they have been removed for filling or replacement. Always close the service valve and install a dust cap or plug when transporting or storing disconnected containers whether full or empty.
  • Page 82 WARNING If you suspect your propane container has been overfilled, contact your independent Jayco dealer or a qualified propane technician for assistance immediately. Do not attempt to service a propane container overfill yourself.
  • Page 83 SECTION 7-PROPANE SYSTEMS JAYCO TOWABLE The following label should be kept permanently affixed to your RV. “Do not fill to more than 80%” label (Label appearance may not be exact) Refer to your Warranty Packet for more information on the LP gas system components.
  • Page 84 JAYCO TOWABLE SECTION 7-PROPANE SYSTEMS Double Cylinder Mounted On A-Frame (if so equipped) When a second cylinder is installed, a tee check valve is used to replace the 90° elbow at the top of the regulator and another 1/4" inverted flare x 24" Type 1 pigtail is added. The regulator stays in the original position.
  • Page 85 SECTION 7-PROPANE SYSTEMS JAYCO TOWABLE Several things to remember each time the propane container is removed: Check that ALL fittings are tight. Check that ALL connections are tested with a propane leak detector (or soapy water) solution. Open the main valve slowly to avoid a fast rush of propane to the excess flow valve causing propane freeze up.
  • Page 86 JAYCO TOWABLE SECTION 7-PROPANE SYSTEMS It also has a left-handed thread, which means that it is turned clockwise to remove, and counter-clockwise to tighten. The P.O.L. fitting has been designed to help restrict the flow of LP gas in the event of a regulator failure or hose malfunction.

  • Page 87: Calculating Propane Usage

    SECTION 7-PROPANE SYSTEMS JAYCO TOWABLE Light the appliances as needed and directed in the appropriate appliance manufacturer’s owner manual located in the Warranty Packet. Keep the propane container valves closed at all times unless you are using the propane gas system or are having the propane container filled.

  • Page 88: Cooking With Propane Gas

    JAYCO TOWABLE SECTION 7-PROPANE SYSTEMS OOKING ROPANE WARNING Do not turn gas range burner controls to ON and allow gas to escape before WARNING Do not use portable fuel burning equipment (i.e., wood and charcoal grills or stoves) inside the recreation vehicle.

  • Page 89: Traveling With Propane

    SECTION 7-PROPANE SYSTEMS JAYCO TOWABLE raveling with Propane Use care when fueling your tow vehicle. Make certain your propane container is properly fastened in place. Some states prohibit propane appliances to be operated during travel, especially in underground tunnels. Make sure you know the laws for the areas where you travel.
  • Page 90 JAYCO TOWABLE SECTION 7-PROPANE SYSTEMS his page left intentionally blank 7-12...

  • Page 91: Section 8: Plumbing System

    SECTION 8-PLUMBING SYSTEMS JAYCO TOWABLE There are two different water systems in your recreation vehicle:  The fresh water system consists of the fresh water holding tank, fresh water connections, water pump, outside shower assembly (if so equipped), water heater, faucets, tub/shower, and water purification system (if so equipped).
  • Page 92 JAYCO TOWABLE SECTION 8-PLUMBING SYSTEMS Operation Press only one “tact” switch at a time. As you push either the “FRESH”, “BLK” “GREY1” or “GREY2” switch, one or more LED lights will illuminate (from left to right) indicating the content level for that tank. When pushing the “BATT” switch, the LED lights illuminate from left (lowest) to right (highest) to indicate the estimated auxiliary battery condition.
  • Page 93 SECTION 8-PLUMBING SYSTEMS JAYCO TOWABLE RESH ATER OLDING The fresh water tank can be filled by pressure filling through the fresh water inlet. There are plastic overflow tubes plumbed into the fresh water holding tank. They allow water to flow out of the water tank. Occasionally, you may see water coming from the overflow tubes when the fresh water holding tank is filled.
  • Page 94 JAYCO TOWABLE SECTION 8-PLUMBING SYSTEMS Water pump strainer Fig 8.1 Water pump Water pump ATER RESSURE EGULATOR CUSTOMER UPPLIED Excessive pressure from the water supply source may be encountered in some parks, especially in mountain regions when using the fresh water inlet or black tank flush. Water pressure regulators are available to protect your recreation vehicles plumbing system against such high pressure.
  • Page 95 SECTION 8-PLUMBING SYSTEMS JAYCO TOWABLE Turn ON the water at the water source. Enter the vehicle and open the cold water supply faucets to bleed air from the water lines. When the water lines are nearly full, you may experience some "air pockets." Allow them to escape before closing the cold water supply faucets.
  • Page 96 JAYCO TOWABLE SECTION 8-PLUMBING SYSTEMS ATER EATER The water heater is designed to heat water quickly and efficiently. The water heater manufacturer has preset the sensing limit to maintain the water temperature when the water heater is activated. WARNING Hydrogen gas may result if you have not used the water heater for two weeks or more.
  • Page 97 SECTION 8-PLUMBING SYSTEMS JAYCO TOWABLE Pilot Reset Button P&T valve Water Heater pilot ignition Gas valve Temp. Refer to the water heater manufacturer’s manual for lighting instructions. Water heater bypass (If So Equipped) Your recreation vehicle may be equipped with a water heater bypass. This three-valve system is located at either the water heater, or on the system panel depending on your model.
  • Page 98 JAYCO TOWABLE SECTION 8-PLUMBING SYSTEMS Operating the water heater without the proper anode rod protection will decrease tank life and will void the tank manufacturer’s warranty on the tank. To extend the anode life, drain the water from the water heater tank whenever the RV is not being used. Avoid any extended time of non-use with water in the tank.
  • Page 99 SECTION 8-PLUMBING SYSTEMS JAYCO TOWABLE Maintenance Do not allow the burner to burn with a yellow flame, or continue to operate the water heater with an improper burner flame. Periodically, inspect the water heater vent for soot. Soot is a sign of incomplete combustion and must be corrected before operating the water heater.

  • Page 100: Faucets

    JAYCO TOWABLE SECTION 8-PLUMBING SYSTEMS UTSIDE HOWER QUIPPED A handheld shower assembly with both hot and cold water may be included for use outside of your recreation vehicle. Be sure the water heater is ON and had sufficient time to heat the water.
  • Page 101 SECTION 8-PLUMBING SYSTEMS JAYCO TOWABLE The bathing facilities in your recreation vehicle function similar to those in your home. Keep the water heater and holding tank capacities in mind when using the fresh water system. Long showers are not suggested due to the limited amount of water available. The used water will drain through the plumbing pipes into the grey water holding tank.
  • Page 102 JAYCO TOWABLE SECTION 8-PLUMBING SYSTEMS Drain the sink by removing the drain cap. Turn ON the water pump and allow it to run as needed. If the RV water heater has bypass valves: A&B are closed, valve C is open (refer to the Water Heater Bypass section).
  • Page 103 SECTION 8-PLUMBING SYSTEMS JAYCO TOWABLE NOTE: The Full System Canister must have the filter removed Turn the pump ON which sends sanitizer into the water lines. Open all hot water faucets one by one until water begins to flow continuously and a chlorine smell is noticeable.

  • Page 104: Winterizing The Plumbing System

    JAYCO TOWABLE SECTION 8-PLUMBING SYSTEMS Run water through all faucets (hot & cold, including outside shower) until chlorine smell is gone. Turn the pump ON to send water through the lines. Close all faucets including outside shower. Turn pump OFF.
  • Page 105 SECTION 8-PLUMBING SYSTEMS JAYCO TOWABLE Residential Refrigerator (if so equipped): Remove the refrigerator water filter (if so equipped), discard it. (Install a new filter in the spring) Open the refrigerator low point drain and drain water out of the refrigerator lines. Unplug the refrigerator. Prop open the refrigerator doors to prevent odors from developing.
  • Page 106 JAYCO TOWABLE SECTION 8-PLUMBING SYSTEMS Washing Machine (If So Equipped): Set the water temperature to WARM, begin filling the washing machine. This will bring antifreeze in through the hot and cold water lines. Run the washer just long enough to bring about a quart of antifreeze into the drum.
  • Page 107 SECTION 8-PLUMBING SYSTEMS JAYCO TOWABLE WARNING Do not add automotive antifreeze or caustic chemicals such as laundry detergents into the holding tanks. Although these products may have a deodorizing effect, they may damage the plastic and rubber parts of the plumbing system or the components.
  • Page 108 JAYCO TOWABLE SECTION 8-PLUMBING SYSTEMS Open the black tank dump valve. (Valve may be located under the RV, or on the Utility Center if so equipped) Close the dump valve when the black water holding tank is emptied. Open the grey tank dump valve. (Valve may be located under the RV, or on the Utility Center if so equipped) Close the dump valve when the grey holding tank is emptied.
  • Page 109 SECTION 8-PLUMBING SYSTEMS JAYCO TOWABLE Using the Tank Flush Inlet: Connect the flexible sewer hose to the 4 inch dump outlet. Open the black water dump valve and leave it open. Allow the tank to drain. Attach a water hose to the Tank Flush Inlet. Do not use your fresh water hose for this.
  • Page 110 JAYCO TOWABLE SECTION 8-PLUMBING SYSTEMS Sewage (black) tank preparation Release one to two quarts (1 or 2 liters) of water into the toilet bowl. Follow the directions on your (approved RV) toilet chemical bottle (customer supplied), by placing the recommended quantity of holding tank chemical into the toilet bowl.

  • Page 111: Section 9-Heating & Cooling

    SECTION 9-HEATING & COOLING JAYCO TOWABLE ONDITIONER Roof Mount (If So Equipped) The roof mounted air conditioning system is controlled by a thermostat. Cooled air enters the RV through the adjustable “chill grill.” Make sure you have sufficient power available before operating the air conditioner.
  • Page 112 JAYCO TOWABLE SECTION 9 HEATING & COOLING URNACE The furnace installed in your motor home is controlled by a thermostat. The furnace requires both 12-volt power and propane gas for full operation. Make sure you have sufficient power available before operating your furnace.

  • Page 113: Section 10-Appliances

    SECTION 10-APPLIANCES JAYCO TOWABLE ICROWAVE QUIPPED Make sure there is sufficient 120-volt power available before operating the microwave. Make sure the microwave turntable (if so equipped) is secured prior to traveling. Do not operate the microwave when it is empty.

  • Page 114: Bbq Grill (If So Equipped)

    JAYCO TOWABLE SECTION 10-APPLIANCES QUIPPED WARNING Do not cover the oven vent openings while the oven is in operation. Restricting the flow of combustion air will create an asphyxiation hazard. The propane gas oven must have 12-volt power to operate. If you have any questions contact your dealer or our customer service department.

  • Page 115: Cooking With Propane

    SECTION 10-APPLIANCES JAYCO TOWABLE Place the “quick coupler handle in the OFF position and push back the sleeve. The valve handle must be OFF to make the connection. Insert the plug and release the sleeve. Push the plug until the sleeve snaps forward, locking the plug into the socket.

  • Page 116: Refrigerator

    JAYCO TOWABLE SECTION 10-APPLIANCES REASE WARNING Do not attempt to use water to put out the fire. Water can spread some types of fire, and electrocution is possible with an electrical fire. Grease is flammable. Never allow grease to collect around top burners or on the cook top surface.

  • Page 117: Water Heater-See Plumbing Section

    SECTION 10-APPLIANCES JAYCO TOWABLE Cleaning the interior Unplug refrigerator or disconnect power. Hand wash, rinse, and dry removable parts and interior surfaces thoroughly. Use a clean sponge or soft cloth and a mild detergent in warm water. For the inside of the refrigerator, use a warm water and baking soda solution consisting of approximately 1 tablespoon (15ml) baking soda to 1 quart (1 liter) of water.
  • Page 118 JAYCO TOWABLE SECTION 10-APPLIANCES Locate the black locking lever at the base of the swing arm. Push in on the lever while pulling forward on the swing arm. Swing the cooktop unit open as far as the swing arm will allow.
  • Page 119 SECTION 10-APPLIANCES JAYCO TOWABLE To return the kitchen unit to the stowed position, first disconnect the propane connection. Hold in the release button on the support leg and retract the lower portion of the leg. Swing the leg up into the stowed position and extend the leg into the storage bracket.
  • Page 120 JAYCO TOWABLE SECTION 10-APPLIANCES HIS PAGE LEFT INTENTIONALLY BLANK 10-8...

  • Page 121: Section 11-Electronics

    SECTION 11-ELECTRONICS JAYCO TOWABLE ELEVISION NTENNA IF SO EQUIPPED To view local stations at either (or both) the front or bedroom television sets using the television antenna, make sure the TV power supply is ON and the TV roof antenna is raised to the operating position.

  • Page 122: Television Power Supply

    JAYCO TOWABLE SECTION 11-ELECTRONICS DONT'S  Don’t force elevating crank up or down.  Don’t rotate directional handle hard against stops.  Don’t travel with lift in up position.  Don’t leave lift part way up or down.  Don’t apply sealing compound or paint over top of base plate or anywhere on lift.

  • Page 123: Section 12-Interior

    SECTION 12-INTERIOR JAYCO TOWABLE LEANING NTERIOR To keep the value of your recreation vehicle, perform regular maintenance using the proper materials and procedures. Using the wrong cleaner may result in damage to the surfaces in your vehicle. Check with the manufacturer’s information for the recommended cleaning agent.
  • Page 124 JAYCO TOWABLE SECTION 12-INTERIOR J-Cube Sofa (If So Equipped) The J-Cube Sofa functions similar to a residential futon. The slanted back pillows offer numerous options as a sofa, along with the ability to extend the cushions for additional sleeping space.

  • Page 125: Countertops

    SECTION 12-INTERIOR JAYCO TOWABLE & T ABINETRY ABLES To keep hardwood doors, cabinet fronts and hardwood tables looking like new regularly dust with a soft cloth dampened with a cleaning polish or mild detergent solution. Avoid using ammonia based products or silicone oils as they may cause damage if used over a long period of time.

  • Page 126: Flooring

    JAYCO TOWABLE SECTION 12-INTERIOR To clean, use a mild solution of soap and lukewarm water with a soft sponge or cloth. Wipe dry with a soft, clean cloth. CAUTION Do not use abrasive cleaners as they may cause the vinyl to scratch and become dull.

  • Page 127: Décor Items

    SECTION 12-INTERIOR JAYCO TOWABLE  Do not tuck in the wired area of the heated bed mats.  Let the cord hang free. Do not route electrical cords between the heated bed mats and the bed boards. Do not allow the cords to be pinched. NEVER pull a heated bed mat by its cord.

  • Page 128: Section 13-Exterior

    SECTION 13-EXTERIOR JAYCO TOWABLE LEANING XTERIOR To protect your recreation vehicle’s exterior finish, wash it often and thoroughly. For recreation vehicles with painted exterior graphics: If desired you may wash and wax your vehicle 60 days after purchase. The exterior paint does need time to cure before any wax is applied to the exterior surface.
  • Page 129 JAYCO TOWABLE SECTION 13-EXTERIOR Drying the recreation vehicle is just as important as washing your vehicle. Tap and well water contain many chemicals that could water stain your vehicle’s finish. We suggest using a damp natural or synthetic chamois. There are other drying products such as lint- free micro-fiber towels that work just as well.
  • Page 130 SECTION 13-EXTERIOR JAYCO TOWABLE Damaged paint To prevent corrosion, touch up small cracks and scratches in the paint coat as soon as possible with touch-up film or paint. Carefully check the body areas facing the road and the tires for damage to the paint coat caused by flying stones, etc. To purchase touch-up paint, use the closest automotive paint (available locally) match possible.

  • Page 131: Exterior Roof & Sidewall Vents

    JAYCO TOWABLE SECTION 13-EXTERIOR When using any of the above products, please follow the cleaning product manufacturer’s directions! If practical, use a wet/dry vacuum to remove all moisture or excess cleaning product. Do not fold up tent while fabric is still wet or damp! Most of the above items can be purchased at local hardware stores, and RV or Marine dealers or supply stores.

  • Page 132: Sealants

    SECTION 13-EXTERIOR JAYCO TOWABLE EALANTS Sealants perform a very important function and should be inspected closely and regularly maintained. We incorporate many different types of sealants, including butyl/putty, black butyl-encapsulated foam, silicone (clear and colored), roof sealant and foam. In general, sealants do not have "set"...
  • Page 133 JAYCO TOWABLE SECTION 13-EXTERIOR CAUTION Failure to properly maintain or reseal your recreation vehicle may result in serious water damage to the roof and other parts of the recreation vehicle. This damage is not covered by the Towable Limited Warranty.

  • Page 134: Ready To Leave Checklist

    SECTION 14-CHECK LISTS JAYCO TOWABLE TART The following checklist will help ensure a trouble-free camping season:  Inspect and work all interior and exterior latches and locks (lube if necessary).  Make sure the batteries are fully charged and installed correctly.

  • Page 135: Rv Storage

    JAYCO TOWABLE SECTION 14-CHECK LISTS  Turn off interior lights and appliances.  Disconnect any cable TV or phone hookups.  Lower the TV antenna (if so equipped).  Move slideout (if so equipped) in and lock it in place.
  • Page 136 SECTION 14-CHECK LISTS JAYCO TOWABLE  Close the propane cylinder valve(s). If you do not have a propane cylinder cover, we recommend purchasing one to make sure the regulator is covered.  Cover all external outlets, such as furnace, exhaust, etc. to prevent mice or other rodents from entering.
  • Page 137 JAYCO TOWABLE SECTION 14-CHECK LISTS Each Trip  Inspect and reseal as needed.  Check the auxiliary battery (If so equipped).  Have the propane system checked for leaks by your dealer.  Check running lights.  Check tire pressure and wear, including spare (if so equipped). Make sure the tires are cold when checking the tire pressure.

  • Page 138: Section 15-Additional Information

    SECTION 15-ADDITIONAL INFORMATION JAYCO TOWABLE AINTENANCE ECORD Make: Model: Model Year: Vehicle Serial#: Service Performed Work Performed Notes Date 15-1...
  • Page 139 JAYCO TOWABLE SECTION 15-ADDITIONAL INFORMATION Service Work Performed Performed By Notes Date 15-2...
  • Page 140 SECTION 15-ADDITIONAL INFORMATION JAYCO TOWABLE OTES 15-3...

  • Page 141: Featured Components Quick Reference Chart

    Your RV may be equipped with some of the items listed below. This is a partial listing and it is not intended to cover all components in your RV. All information is the latest available at the time of publication. Jayco reserves the right to change any of the following information without notice. COMPONENT...
  • Page 142 SECTION 15-ADDITIONAL INFORMATION JAYCO TOWABLE HIS PAGE LEFT INTENTIONALLY BLANK 15-5...
  • Page 143 JAYCO TOWABLE SECTION 15-ADDITIONAL INFORMATION Jayco Ownership Notification Fax Form To: (800) 825-7876 ATTENTION! Federal record keeping laws require that we maintain a file of owners of our product. Your cooperation in filling out this from will be appreciated. □...

This manual is also suitable for:

2016 jay feather72016 whitehawk towablesJay feather 2016Jay feather 7 20162016 jay flight

Table of Contents

Save PDF
