Freedom9 freeView Pro X80H Specifications

freeView Pro
8-port HD/CAT5 Rackmount
KVM Switch
freeView Pro X80H > 8-port HD/CAT5 Rackmount
KVM Switch
The freeView Pro X80P is an 8-port KVM with a CAT 5 extender designed
to allow you to control multiple computers at the rack and from up to
500 feet away using a single keyboard, mouse and monitor.
The freeView Pro X80H converts the signals from PS/2 and VGA to signals
that travel on CAT 5 cable allowing them to be transmitted over a long
distance to the receiver which converts the signal back to PS/2 and VGA.
The freeView Pro X80H facilitates the control of computers remotely. It is
an excellent solution for secure server rooms with restricted access, and
also to allow staff to work outside of noisy server rooms.
The freeView Pro X80H is also able to daisy chain with up to seven other
KVMs (freeView Pro 80P and freeView Pro 160P), allowing you to control
up to 120 computers from a single keyboard, mouse, and monitor.
Specifications
Host Connections
Connector Type
Keyboard/Mouse
Video
Console Connections
Keyboard/Mouse
Video
Extension Port
Daisy Chain Port
PC Selection
7 segment LED
Scan Intervals
VGA Resolution
Bandwith
Daisy Chain
Power Adapter
Housing
Operating Temperature
Storage Temperature
Humidity
Weight
Dimensions (H x W x D)
Model Numbers
Model Name
Description
Part Number
Revision 2.0 Specifications are subject to change without notice. Copyright 2008 Freedom9 Inc.
X80H
8
1-to-3 (HD)
PS/2
VGA
1
PS/2
VGA
RJ-45
3-to-3
Push Button, Hot-Key, OSD
Bank x 1, PC Port x 2
5~99 sec.
1920x1440
200 Mhz
Max. level: 8 & Max. PC connections: 120
DC 12V, 1A
Metal
32°F - 104°F (0°C - 40°C)
-4°F - 140°F (-20°C - 60°C)
0~80% Non-Condensing
4.8 lb (2.2 kg)
16.1 x 6.5 x 1.7 in (410 x 165 x 44 mm)
freeView Pro X80H
8-port HD/CAT5 Rackmount KVM Switch
KVM-08H
Features:
• 19" rackmount design
• Supports Microsoft Intellimouse / Explorer,
Logitech Net Mouse or other fully compatible
MS mice
• Supports DOS, MS Windows, Novell, Unix, and
Linux
• Hot Pluggable
• Resolution up to 1920 x 1440, Bandwidth;
200MHz
• No extra software required
• Supports CAT 5, CAT 5e, and CAT 6 Ethernet
cables
• Easy PC selection via On Screen Display menu,
Push Buttons and Hot Keys
• Supports eight-character password protection and
search by PC server name
• Auto Scan Mode for monitoring PCs with flexible
Scan time from 5~99 seconds
• Keyboard status restored when switching between
PCs
• LED Display for easy status monitoring
• Audible alert confirming port changes
• Built-in, extra daisy chain port
• Auto detection of daisy chain bank
