Freedom9 freeView Pro C80H Specifications

freeView Pro
1U Rackmount Console
with 15" LCD & 8-port
KVM Switch
freeView Pro C80H > 1U Rackmount Console
with 15" LCD & 8-port KVM Switch
The freeView Pro C80H KVM Console is an ideal solution for
network administration with multiple servers / platforms. The
15-inch TFT LCD colour displays and ultra-low-profile compact
industrial keyboard / touchpad provide a user-friendly and
reliable environment for network administrators. All these
functions are integrated in a 19-inch 1U space to achieve ultra
space saving with rugged design and high reliability for
demanding industrial network applications.
The freeView Pro C80H KVM Console drawers provide superior
picture quality and state-of-the-art features mounted in an
industrial grade, rack mount drawer. The drawer forms a
rugged enclosure that protects the monitor from industrial
hazards and permits easy access to monitor controls.
Specifications
PC Connectors
Cable Type
Keyboard/Mouse
Video
LCD Panel
KVM Cable
Rackmount Kit
Mouse Control
VGA Resolution
Bandwith
Power Adapter
Housing
Operating Temperature
Weight
Dimensions (H x W x D)
Model Numbers
Model Name
Description
Part Number
Revision 2.0 Specifications are subject to change without notice. Copyright 2008 Freedom9 Inc.
C80H
8
1-to-3 (High Density)
PS/2
VGA
15" Active-Matrix TFT-LCD
2 x 6 ft (1.8 m)
1
Touchpad
1024x768
200 Mhz
12V, 1A
Metal
32°F - 104°F (0°C - 40°C)
37.4 lb (17 kg)
1.7 x 17.4 x 22.4 in (43 x 443 x 57 mm)
freeView Pro C80H
1U Rackmount Console with 15" LCD
KDW-08HA
Features:
• A single LCD console drawer with built-in
KVM switch and 15" LCD display controls 8
computers directly
• Daisy-chain port allows max. access up to
120 PCs through eight bank of
freeView Pro 160P
• Supports eight characters password
protection
• Support DOS, Win3.x, Win 95 / 98 / 98SE /
2000 / Me, WinNT, Netware, Unix, and Linux
• PC selection via OSD and Hot Keys
• Provide console PS/2 to PC serial mouse
conversion
• Support VGA resolution up to 1024 x 768,
200MHz Bandwidth
• Auto Scan mode for monitoring PCs and
flexible scan time from 5~99 seconds
• Keyboard and mouse can be hot plugged
at any time
