Dreamline Prism Plus Installation Instructions Manual

Shower enclosure & base
Hide thumbs Also See for Prism Plus:

Advertisement

Quick Links

Download this manual
Prism Plus Shower Enclosure & Base
S
E
HOWER
IMPORTANT
DreamLine
reserves the right to alter, modify or redesign products at any time without prior notice.
®
For the latest up-to-date technical drawings, manuals, warranty information or additional details please refer
to your model's web page on DreamLine.com
STEP 1:
Shower Base Installation Instructions
STEP 2:
Shower Enclosure Installation Instructions
For more information about DreamLine
PRISM PLUS SHOWER ENCLOSURE & BASE
& B
NCLOSURE
Shower Doors, Tub Doors & Enclosures, please visit DreamLine.com
®
I
ASE
NSTALLATION
I
NSTRUCTIONS
©2017 DreamLine. All Rights Reserved

Advertisement

loading
Need help?

Need help?

Do you have a question about the Prism Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dreamline Prism Plus

Summary of Contents for Dreamline Prism Plus

  • Page 1 DreamLine.com STEP 1: Shower Base Installation Instructions STEP 2: Shower Enclosure Installation Instructions For more information about DreamLine Shower Doors, Tub Doors & Enclosures, please visit DreamLine.com ® ©2017 DreamLine. All Rights Reserved PRISM PLUS SHOWER ENCLOSURE & BASE...
  • Page 2 For the latest up-to-date technical drawings, manuals, warranty information or additional details please refer to your model’s web page on DreamLine.com Color options: --- - White...

  • Page 3: Tools Required

    “Detailed Diagram of Shower Door Components”. If the unit has been damaged, has a finishing defect, or has missing parts, please contact our customer support department within 3 business days of the delivery date. Please note that DreamLine ®...
  • Page 4 ©2018 DreamLine. All Rights Reserved SLIMLINE SHOWER BASE manual Ver 5 Rev 9 03/2018...
  • Page 5 ©2018 DreamLine. All Rights Reserved SLIMLINE SHOWER BASE manual Ver 5 Rev 9 03/2018...
  • Page 6 ©2018 DreamLine. All Rights Reserved SINGLE THRESHOLD SHOWER BASE Center Drain Configuration MODEL SPECIFICATION D (in) W (in) D1 (in) W1 (in) DLT-1132320 32"× 32" 32" 32" 15" 16" DLT-1136360 36"× 36" 36" 36" 15" 18" DLT-1132420 32” x 42”...
  • Page 7 ©2018 DreamLine. All Rights Reserved SINGLE THRESHOLD SHOWER BASE Left-Hand Drain Configuration MODEL SPECIFICATION D (in) W (in) D1 (in) W1 (in) DLT-1130601 30"×60" 30" 60" 15" 12" DLT-1132601 32"×60" 32" 60" 15" 12" DLT-1134601 34"×60" 34" 60" 17" 12"...
  • Page 8 ©2018 DreamLine. All Rights Reserved SINGLE THRESHOLD SHOWER BASE Right-Hand Drain Configuration MODEL SPECIFICATION D (in) W (in) D1 (in) W1 (in) DLT-1130602 30"×60" 30" 60" 15" 12" DLT-1132602 32"×60" 32" 60" 15" 12" DLT-1134602 34"×60" 34" 60" 17" 12"...
  • Page 9 ©2018 DreamLine. All Rights Reserved NEO ANGLE SHOWER BASE MODEL SPECIFICATION W (in) A (in) B (in) C (in) DLT-2036360 36"×36" 36" 18 5/16" 25" 12" DLT-2038380 38"×38" 38" 20 5/16" 25" 12" DLT-2040400 40"×40" 40" 22 5/16" 25" 14 3/8"...
  • Page 10 ©2018 DreamLine. All Rights Reserved QUARTER ROUND SHOWER BASE MODEL SPECIFICATION W (in) C (in) R (in) DLT-7033330 33"×33" 33" 12" 21 5/8" DLT-7036360 36"×36" 36" 12" 21 5/8" DLT-7038380 38"×38" 38" 12" 21 5/8" SLIMLINE SHOWER BASE manual Ver 5 Rev 9...
  • Page 11 ©2018 DreamLine. All Rights Reserved DOUBLE THRESHOLD SHOWER BASE Corner Drain Configuration MODEL SPECIFICATION W (in) C (in) DLT-1032320 32"×32" 32" 12" DLT-1036360 36"×36" 36" 12" SLIMLINE SHOWER BASE manual Ver 5 Rev 9 03/2018...
  • Page 12 ©2018 DreamLine. All Rights Reserved DOUBLE THRESHOLD SHOWER BASE Left-Hand Drain Configuration MODEL SPECIFICATION D (in) W (in) D1 (in) W1 (in) DLT-1034481 34"×48" 34" 48" 17" 12" DLT-1036481 36"×48" 36" 48" 18" 12" DLT-1036541 36"×54" 36" 54" 18" 12"...
  • Page 13 ©2018 DreamLine. All Rights Reserved DOUBLE THRESHOLD SHOWER BASE Right-Hand Drain Configuration MODEL SPECIFICATION D (in) W (in) D1 (in) W1 (in) DLT-1034482 34"×48" 34" 48" 17" 12" DLT-1036482 36"×48" 36" 48" 18" 12" DLT-1036542 36"×54" 36" 54" 18" 12"...
  • Page 14 ©2018 DreamLine. All Rights Reserved Shower Base Cross Section Diagram Cement board Finished Wall Shower Base (2"×4") Stud Mortar Drain* * not included SLIMLINE SHOWER BASE manual Ver 5 Rev 9 03/2018...
  • Page 15 ©2018 DreamLine. All Rights Reserved Shower Base Installation - Preparation 1. Ensure that the floor and the studs are at right angles. Provide a 5”×5” opening in the sub- floor for the drain. The 2” PVC waste pipe should extend above the surface of the...
  • Page 16 ©2018 DreamLine. All Rights Reserved 2. Install the shower drain (NOT INCLUDED) according to the drain installation manual (supplied with the drain). See Fig. 3 for example Fig. 3 3. Place the tray into the designated position so that the Drain cutout drops around the Drain Pipe and butt the Shower Base up against the studs.
  • Page 17 ©2018 DreamLine. All Rights Reserved 4. Level the tray and place marks on the studs above the upper edge of the tile flange. See Fig. 5 for details. Level base in two directions Fig. 5 5. Mix the bedding material (Mortar, cement-sand mix, etc.) Concrete...
  • Page 18 ©2018 DreamLine. All Rights Reserved 6. After the bedding material has been before poured and it sets, place the shower base into the position with the drain assembly sliding over the PVC waste pipe. It will be necessary to push...
  • Page 19 ©2018 DreamLine. All Rights Reserved Fig. 9 SLIMLINE SHOWER BASE manual Ver 5 Rev 9 03/2018...

  • Page 20: Product Maintenance

    To maximize the life of your door, it is important to regularly inspect the glass and other hardware for misalignment, proper attachment, and/or damage. Contact DreamLine with any questions or concerns. SLIMLINE SHOWER BASE manual Ver 5 Rev 9 03/2018...
  • Page 21 TEL: 866-731-2244 FAX: 866-857-3638 REAM INE.COM For more information on DreamLine ® Shower Doors Enclosures please visit DreamLine.com...
  • Page 22 SHEN-2638380-## SHEN-2640400-## ##=finish 01- Chrome 04- Brushed Nickel 06- Oil Rubbed Bronze Left-swing installation shown 09- Satin Black For more information about DreamLine Shower Doors & Tub Doors please visit DreamLine.com ® PRISM PLUS manual Ver 1 Rev 2 11/2016...
  • Page 23 Please note that depending on the model, the glass may be coated on either one or both surfaces. For best results, squeegee the glass after each use and dry with a soft cloth. PRISM PLUS manual Ver 1 Rev 2 11/2016...
  • Page 24 2. Please note that you should consult your local building codes with questions on installation compliance standards. Building and plumbing codes may vary by location, and DreamLine ®...
  • Page 25 If any parts are damaged or missing, please contact DreamLine for replacement. The shipping boxes may contain extra parts not used in ® your model configuration. NOTE: Retain these installation instructions for future reference. PRISM PLUS manual Ver 1 Rev 2 11/2016...

  • Page 26: Parts List

    Handle Anti-water bottom strip (sweep vinyl) 7 Φ8 (5/16”) Wall Anchor 14pcs 3mm/4mm Hex Key 1 each 8pcs 2pcs Round Head Screw ST4.2×25 Round Head Screw ST4.2×40 4pcs Truss Head Screw ST4.2×40 PRISM PLUS manual Ver 1 Rev 2 11/2016...

  • Page 27: Installation Steps

    Make sure the Stainless Steel U-channels (#11) are absolutely vertical. Mark the position of the Stainless Steel U-channels (#11) on the walls. See Fig 2 for details outside outside U-channel outside Fig 2 PRISM PLUS manual Ver 1 Rev 2 11/2016...
  • Page 28 Set the Stationary Glass 2 (hinge panel) (#03) onto the threshold and into the Stainless Steel U-channel (#11). See Fig 5 for details inside Fig 5 Left-swing door installatiion shown for example PRISM PLUS manual Ver 1 Rev 2 11/2016...
  • Page 29 Measure the area where the door glass will be installed. This distance needs to be 23-15/16”. Mark the position of the glass on the threshold as shown. See Fig 7 for details 23-15/16” overhead view Fig 7 PRISM PLUS manual Ver 1 Rev 2 11/2016...
  • Page 30 Install the Bottom Brackets (#12) onto the threshold using the ST4.2 x 25 Round Head screws (#08) with washers and decorative covers (#10). inside See Fig 9 for details washer inside Fig 9 PRISM PLUS manual Ver 1 Rev 2 11/2016...
  • Page 31 L-Shape Bracket Parts Diagram Parts List Rubber pad M5 rubber tip set screw 2pcs L-Bracket Decorative cover Wall Anchor 6pcs Wall Plate ST4.2x40 Screw 6pcs M5x14 Screw 2pcs PRISM PLUS manual Ver 1 Rev 2 11/2016...
  • Page 32 See Fig 10, 11 & 12 for details Fig 10 NOTE: The left hand L-bracket installation is shown. Follow the same steps to install the right-hand L-bracket. Right hand L-bracket Fig 11 Left hand L-Bracket installation shown PRISM PLUS manual Ver 1 Rev 2 11/2016...
  • Page 33 DO NOT lift the glass using the Handle. This could result in damage to the glass and /or serious personal injury. Always use an assistant or a professional grade glass suction cup when handling heavy glass. PRISM PLUS manual Ver 1 Rev 2 11/2016...
  • Page 34 U-channel before hanging the door glass. Leave the shims in place beneath the door glass while the silicone cures, especially if an out-of-plumb wall condition is present. 13/16” shim Fig 14 PRISM PLUS manual Ver 1 Rev 2 11/2016...
  • Page 35 Fully press the cut strips onto the vertical edge of the Door Glass (#02). See Fig 16 for details Stationary Door glass (01) inner part Inside 1” Door Around Bottom sweep Fig 16 PRISM PLUS manual Ver 1 Rev 2 11/2016...
  • Page 36 Shower base or threshold. Allow 24 hours for the silicone to fully cure before using the shower. See Fig. 17 for details Hours Fig 17 PRISM PLUS manual Ver 1 Rev 2 11/2016...
  • Page 37 • Use a soft cloth to clean the hinge surfaces. Do not use abrasives or acidic liquids as this will damage the finish. • Be careful not to scratch the finished surfaces of the hinge during installation. PRISM PLUS manual Ver 1 Rev 2 11/2016...
  • Page 38 NOTE: To maximize the life of your door, it is important to regularly inspect the glass and all hardware for misalignment, proper attachment, and/or damage. Contact DreamLine with any questions or concerns. PRISM PLUS manual Ver 1 Rev 2 11/2016...
  • Page 39 TEL: 866-731-2244 FAX: 866-857-3638 DREAMLINE.COM For more information on DreamLine Shower Doors and Enclosures please visit DreamLine.com ®...
