HORNET 251 MANUAL - HIGH PRESSURE CLEANER
HIGH PRESSURE WATER CLEANER
Cold Water
Record Serial Number below and retain product serial number which is
located on nameplate.
UNIT SERIAL NO.
ENGINE SERIAL NO.
PURCHASE DATE
Petrol Driven
V1.0 - 2019
Advertisement
Table of Contents
Related Manuals for Jetwave Hornet Series
Summary of Contents for Jetwave Hornet Series
- Page 1 HORNET 251 MANUAL - HIGH PRESSURE CLEANER WARNING! Read this Operator’s Manual carefully before using this machine. Failure understand and follow the contents of this manual may result in electrical shock, fire and/or serious personal injury. READ CAREFULLY HIGH PRESSURE WATER CLEANER Cold Water Petrol Driven Record Serial Number below and retain product serial number which is...
-
Page 2: Table Of Contents
HORNET 251 MANUAL - HIGH PRESSURE CLEANER Table of Contents Safety Symbols General Power Tool Safety Warnings Work Area Safety Electrical Safety Personal Safety Tool Use And Care Service High Pressure Cleaning Safety Description, Specifications And Standard Equipment Description Specifications Standard Equipment Machine Assembly &... -
Page 3: Safety Symbols
HORNET 251 MANUAL - HIGH PRESSURE CLEANER Safety Symbols In this operator’s manual and on the product, safety symbols and signal words are used to communicate important safety information. This section is provided to improve understanding of these signal words and symbols. This is the safety alert symbol. -
Page 4: High Pressure Cleaning Safety
Read and understand Australia/New Zealand standard AS/NZS4233.1:13 High Pressure Water Jetting SAVE ALL WARNINGS AND INSTRUCTIONS Systems Part 1: Safe Operation & Maintenance. FOR FUTURE REFERENCE! If you have any question concerning this Jetwave product: ® – Contact your local Jetwave distributor. -
Page 5: Description, Specifications And Standard Equipment
™ gasoline Honda engine to drive the triplex plunger pump. ™ Figure.2 - (Optional) Hose Reel Standard equipment A Jetwave Hornet High Pressure Cleaner comes with: ™ • High Pressure gun & back part lance • Varaible dual lance with high and low nozzles •... -
Page 6: Machine Assembly & Operation
HORNET 251 MANUAL - HIGH PRESSURE CLEANER The machine serial number is located on the frame. The prevent unit damage. first 4 digits indicate the year and month of manufacture Always wear appropriate safety equipment, when inspecting your unit. respectively. NOTICE This machine is made high pressure water clean. -
Page 7: Machine And Work Area Set-Up
HORNET 251 MANUAL - HIGH PRESSURE CLEANER Engines produce carbon monoxide, a colorless, odorless poison gas. Breathing carbon monoxide can cause nausea, fainting or death. Do not start and run engine in an enclosed area, even if doors and windows are open. Only operate outside. Set-up the unit and work area according to these procedures to reduce the risk of injury from high pressure water, chemical burns, infections, carbon... -
Page 8: Water Supply
HORNET 251 MANUAL - HIGH PRESSURE CLEANER Water Supply Operating Instructions Run a hose from the water source to the unit water inlet. CAUTION Use the largest diameter, shortest length hose possible. A 3/4” I.D. Inlet hose is the minimum recommended size. An appropriate backflow prevention device should be used to comply with all local codes and ordinances. - Page 9 HORNET 251 MANUAL - HIGH PRESSURE CLEANER 7. With the wand pointed in a safe direction, squeeze the • Be sure that you have good balance and do not have wash wand trigger to reduce pressure and allow the to overreach. engine to be started.
-
Page 10: Transportation And Storage
HORNET 251 MANUAL - HIGH PRESSURE CLEANER Transportation and Storage • Reserve Capacity (RC): 45 • Terminal Type: Offset Lug Terminal (OLT) 1. Turn off the fuel valve and the battery isolation switch. • Assembly Type: C 2. Drain water from unit as needed. •... -
Page 11: Gearbox Lubrication
At 1000 hours of use (less in severe use conditions) the unit authorized Jetwave service technician. should be taken to a Jetwave Independent Service Center for pump seal and valve service. Unit should be taken to a Jetwave Independent Service Center or returned to the factory. -
Page 12: Troubleshooting
HORNET 251 MANUAL - HIGH PRESSURE CLEANER Trouble Shooting FAULT CAUSE SOLUTION Pump runs normally Pump is sucking air. Check that all hoses and fittings are airtight. but pressure does not Valves are worn or dirty. Check, clean or replace. achieve rated value. -
Page 13: Maintenance Log
HORNET 251 MANUAL - HIGH PRESSURE CLEANER Maintenance Log Hour Meter Date Maintenance Performed Service Agent Reading... - Page 14 HORNET 251 MANUAL - HIGH PRESSURE CLEANER Notes...
- Page 16 72–74 Richmond Road, Keswick, 5035 Adelaide, South Australia, AU +61 8 8371 3599 sales@jetwave.com.au jetwave.com.au jetwavegroup jetwave.group jetwavegroup jetwavegroup jetwave-group...
