Home PBXware SERVERware TELCOware SIPmon SIPProt Desktop & Mobile UADs Appliances From Bicom Systems Wiki Contents 1 Introduction 2 Requirements 2.1 Identifying phone model 2.2 Phone firmware 2.3 DHCP server 2.4 PBXware version 3 Installation 3.1 Power adapter 3.2 Power over Ethernet (PoE) 3.3 Find the phone IP address 3.4 Reset to factory settings 4 Registering phone...
Make sure that your phone is loaded with appropriate firmware version, 2.8.94. To find out the firmware version of your Gigaset phone model open a new browser window and enter your phone IP address in order to access the phone web administration interface login screen.
If you are using Power over Ethernet (PoE), you don't need to connect the AC adapter. Make sure the Ethernet cable and router or switch is Power over Ethernet (PoE) compliant. Find the phone IP address Find out your Gigaset phone IP Address. Press Menu button. Go to Settings menu.
Do not unplug or remove power to the phone while it is updating firmware and configuration. Registering phone This chapter describes how to identify Gigaset phone model, requirements that must be met and how to register the phone using manual configuration or auto provisioning. The following topics are covered:...
Page 5
UAD settings Navigate to Settings:UAD. Make sure Gigaset UAD is enabled. To check the UAD status click on the edit icon corresponding to your Gigaset phone. Make sure Status is set to Active, Auto provisioning is set to No, and DHCP is set to Yes.
Page 6
Department to which extension will belong to. Example: Sales. Click on the Save button. Registering Phone This chapter describes how to register Gigaset phone using Hostname or IP Address. Hostname or IP Address Login to phone web administration interface Open a new browser window and enter your phone IP address in order to access the phone web administration interface login screen.
Same number as the Authentication name. Display name Usually the same as the Authentication name. Domain PBXware IP address or domain name. Example: 192.168.10.1 or http://abc.bicomsystems.com Proxy server address Same as the Domain field. Registration server Same as the Domain field. Click on Save button.
Page 8
UAD settings. Navigate to Settings:UAD. Make sure Gigaset UAD is enabled. To check the UAD status click on the edit icon corresponding to your Gigaset phone. Make sure Status is set to Active, Auto provisioning is set to Yes, and DHCP is set to Yes.
Page 9
Set to Yes. MAC Address Enter Gigaset phone MAC address. Example: 7C2F80123456. MAC address can be found at the back of the phone. Click on the Save button. Registering Phone This chapter describes how to register Gigaset phone using DHCP or HTTP.
PBXware. If everything is done as above described, you should have successfully registered your phone to PBXware. Dial *123 to verify registration. Configure BLF This chapter describes how to configure BLF (Busy Lamp Field) for Gigaset Maxwell 10. Extension Settings Login to PBXware web administration interface.
Page 11
On the Extensions page click on the edit icon corresponding to your extension. Click on Enhanced services. Click on Directory / BLF List check box and click on Save button in order to enable this feature. Click on Directory / BLF List Edit button. Click Add extension button.
