Epson Solar Series Watch Movement Specification And Drawing page 14

Cal.
VS76A
Small second hand
Crown
2H button
4H button
[*1] How to set the "0" position / System-reset (Crown position : 2nd click)
How to set the "0" position.
Pull crown out to the 2nd click position.
Press 2H button for 2 seconds.
Press 4H button repeatedly to set it to "0" position.
Press 2H button for 2 seconds.
Press 4H button repeatedly to set it to "0" position.
Press 2H button for 2 seconds.
Press 4H button repeatedly to set it to "0" position.
Press 2H button for 2 seconds here will allow you to resume the procedure again as
indicated by the arrow if necessary.
Push crown back to normal position.
System-reset
Pull crown out to the 2nd click position.
Press 2H and 4H buttons at the same time for longer than 2 seconds.
It is necessary to set the "0" position after system-reset.
Operation-01
Second chronograph hand
Hour hand
0 click
Free
Chronograph Start/Stop
Restart
Chronograph Reset
Split
Split release
↓
1/20 second chronograph hand turns a full round and can
now be set to correct "0" position.
↓
↓
Second chronograph hand turns a full round and can now be
set to correct "0" position.
↓
↓
Minute chronograph hand turns a full round and can now be
set to correct "0" position.
↓
↓
↓
1/20 second chronograph hand
Minute hand
2H button
0 ® 1 ® 2
4H button
Minute chronograph hand
Crown position
1st click
Turn clockwise for date
change
Chronograph Start/Stop
Restart
Chronograph Reset
Split
Split release
Date : 24/Apr./'15
Rev. : 01
Crown
2nd click
Time setting
[*1]
[*1]
P.10-01
