Planning Document

Brine-Water and Water-Water

AQUATOP T Heat Pumps

General information

•

Calculations, dimensioning, installations and commissioning

with regard to the products described in this document

may only be executed by proven experts.

•

Locally valid regulations must be observed; they may deviate

from the information in this document.

•

Changes remain reserved.

02/2013

Art. No. 420010415301
