RADIUS
RADIUS server options
240
Server Name/IP The domain name or IP address of the RADIUS server.
Figure 115:RADIUS configuration
Name
Server Name/IP Enter the domain name or IP address of the RADIUS server.
Server Secret
To configure the FortiGate unit for RADIUS authentication
1
Go to User > RADIUS.
2
Select Create New to add a new RADIUS server or select the Edit icon to edit an
existing configuration.
3
Enter the Name of the RADIUS server.
4
Enter the domain name or IP address of the RADIUS server.
5
Enter the RADIUS server secret.
6
Select OK.
To delete a RADIUS server
You cannot delete a RADIUS server that has been added to a user group.
1
Go to User > RADIUS.
2
Select the Delete icon beside the RADIUS server name that you want to delete.
3
Select OK.
The Delete and Edit icons.
Enter a name to identify the RADIUS server.
Enter the RADIUS server secret.
01-28006-0008-20041105
Users and authentication
Fortinet Inc.
