New Access List; New Access List Entry - Fortinet FortiGate FortiGate-800 Administration Manual

Router

New access list

New access list entry

FortiGate-800 Administration Guide
Figure 67: Access list name configuration
To add an access list name
1 Go to Router > Router Objects > Access List.
2 Select Create New.
3 Enter a name for the access list.
4 Select OK.
Figure 68: Access list entry configuration
list Entry
Action
Prefix
Exact match
To configure an access list entry
1 Go to Router > Router Objects > Access List.
2 Select the Add access-list entry icon to add a new access list entry or select the edit
icon beside an existing access list entry to edit that entry.
3 Select Permit or Deny for the Action to take for the prefix in this access list entry.
4 Select either Match any or Match a network address.
5 If you selected Match a network address, enter the IP address and netmask that
define the prefix for this access list entry.
6 Select Exact match if required.
7 Select OK.
The access list name and the number of this entry.
Set the action to take for this prefix to Permit or Deny.
Select Match any to match any prefix. Select Match a network address
and enter the prefix (IP address and netmask) for this access list rule.
By default, access list rules are matched on the prefix or any more
specific prefix. Enable Exact match to match only the configured prefix.
01-28006-0008-20041105
Router objects
159
