NAT/Route mode installation
FortiGate-60R Installation and Configuration Guide
3 Select New to add a route for connections to the network of ISP1.
• Destination IP: 100.100.100.0
• Mask: 255.255.255.0
• Gateway #1: 1.1.1.1
• Gateway #2: 2.2.2.1
• Device #1: wan1
• Device #2: wan2
4 Select New to add a route for connections to the network of ISP2.
• Destination IP: 200.200.200.0
• Mask: 255.255.255.0
• Gateway #1: 2.2.2.1
• Gateway #2: 1.1.1.1
• Device #1: wan1
• Device #2: wan2
• Select OK.
5 Change the order of the routes in the routing table to move the default route below the
other two routes.
• For the default route select Move to
• Type a number in the Move to field to move this route to the bottom of the list.
If there are only 3 routes, type 3.
• Select OK.
Adding the routes using the CLI
1 Add the route for connections to the network of ISP2.
set system route number 1 dst 100.100.100.0 255.255.255.0 gw1
1.1.1.1 dev1 wan1 gw2 2.2.2.1 dev2 wan2
1 Add the route for connections to the network of ISP1.
set system route number 2 dst 200.200.200.0 255.255.255.0 gw1
2.2.2.1 dev1 wan2 gw2 1.1.1.1 dev2 wan1
2 Add the default route for primary and backup links to the Internet.
set system route number 3 dst 0.0.0.0 0.0.0.0 gw1 1.1.1.1
dev1 wan1 gw2 2.2.2.1 dev2 wan2
The routing table should have routes arranged as shown in
Table 17: Example combined routing table
Destination IP' Mask
100.100.100.0 255.255.255.0
200.200.200.0 255.255.255.0
0.0.0.0 0.0.0.0
Configuration example: Multiple connections to the Internet
.
Gateway #1 Device #1
1.1.1.1 wan1
2.2.2.1 wan2
1.1.1.1 wan1
Table 17.
Gateway #2 Device #2
2.2.2.1 wan2
1.1.1.1 wan1
2.2.2.1 wan2
