FortiGate-60 Administration Guide
Note: The following procedure does not include steps for configuring interface heartbeat
devices and interface monitoring. Both of these HA settings should be configured after the
cluster is up and running.
1 Power on the FortiGate unit to be configured.
2 Connect to the web-based manager.
3 Give the FortiGate unit a unique host name.
See "To change FortiGate host name" on page
individual cluster units.
4 Go to System > Config > HA.
5 Select HA.
6 Select the HA mode.
7 Select a Group ID for the cluster.
The Group ID must be the same for all FortiGate units in the HA cluster.
8 Optionally change the Unit Priority.
See "Unit Priority" on page
9 If required, select Override master.
See "Override Master" on page
Enter and confirm a password for the HA cluster.
11 If you are configuring Active-Active HA, select a schedule.
See "Schedule" on page
Select Apply.
The FortiGate unit negotiates to establish an HA cluster. When you select apply you
may temporarily lose connectivity with the FortiGate unit as the HA cluster negotiates.
If you are configuring a NAT/Route mode cluster, power off the FortiGate unit and
then repeat this procedure for all the FortiGate units in the cluster. Once all of the units
are configured, continue with
If you are configuring a Transparent mode cluster, reconnect to the web-based
manager.
You may have to wait a few minutes before you can reconnect.
Go to System > Status.
Select Change to Transparent Mode and select OK to switch the FortiGate unit to
Transparent mode.
Power off the FortiGate unit.
Repeat this procedure for all of the FortiGate units in the cluster then continue with
"To connect a FortiGate HA cluster" on page
87.
87.
88.
"To connect a FortiGate HA cluster" on page
