Transparent mode installation

Next steps

FortiGate-60M Installation Guide
Figure 11: FortiGate-60M Transparent mode connections
Hub or Switch
FortiGate-60M
You can use the following information to configure FortiGate system time, to register
the FortiGate unit, and to configure antivirus and attack definition updates.
Refer to the FortiGate Administration Guide for complete information on configuring,
monitoring, and maintaining your FortiGate unit.
To set the date and time
For effective scheduling and logging, the FortiGate system date and time must be
accurate. You can either manually set the system date and time or configure the
FortiGate unit to automatically keep its time correct by synchronizing with a Network
Time Protocol (NTP) server.
1 Go to System > Config > Time.
2 Select Refresh to display the current FortiGate system date and time.
3 Select your Time Zone from the list.
4 Optionally, select Automatically adjust clock for daylight saving changes check box.
5 Select Set Time and set the FortiGate system date and time.
6 Set the hour, minute, second, month, day, and year as required.
Internal Network
DMZ
Internal
INTERNAL
PWR STATUS 1 2 3 4 DMZ WAN1 WAN2
LINK 100 LINK 100 LINK 100 LINK 100 LINK 100 LINK 100 LINK 100
WAN1
Internet
01-28008-0111-20050128
Other Network
Hub or Switch
Public Switch
or Router
Next steps
47
