SNMP

Fortinet MIB fields

90
Table 8: FortiGate antivirus traps
Trap message Description
Virus detected The FortiGate unit detects a virus and removes the infected file from an
(AvVirus) HTTP or FTP download or from an email message.
Table 9: FortiGate logging traps
Trap message Description
Log full On a FortiGate unit with a hard drive, hard drive usage exceeds 90%. On a
(SysLogFull) FortiGate unit without a hard drive, log to memory usage has exceeds 90%.
Table 10: FortiGate HA traps
Trap message Description
Primary unit The different unit in the HA cluster became the primary unit.
switch
(HaSwitch)
The Fortinet MIB contains fields reporting current FortiGate unit status information.
The tables below list the names of the MIB fields and describe the status information
available for each one. You can view more details about the information available
from all Fortinet MIB fields by compiling the fortinet.2.80.mib file into your SNMP
manager and browsing the Fortinet MIB fields.
Table 11: System MIB fields
MIB field Description
model FortiGate model number, for example, 400 for the FortiGate-400.
serial FortiGate unit serial number.
version The firmware version currently running on the FortiGate unit.
versionAv The antivirus definition version installed on the FortiGate unit.
versionNids The attack definition version installed on the FortiGate unit.
haMode The current FortiGate High-Availability (HA) mode (standalone, A-A, A-P)
opMode The FortiGate unit operation mode (NAT or Transparent).
cpuUsage The current CPU usage (as a percent).
memUsage The current memory utilization (in MB).
sesCount The current IP session count.
01-28006-0001-20041105
