Ip Pool List; Ip Pool Options - Fortinet FortiGate FortiGate-50A Administration Manual

Firewall

IP pool list

IP pool options

FortiGate-50A Administration Guide
For example, if you add an IP pool to the internal interface, you can select Dynamic IP
pool for External->Internal policies.
You can add multiple IP pools to any interface and select the IP pool to use when
configuring a firewall policy.
You can enter an IP address range using the following formats.
• x.x.x.x-x.x.x.x, for example 192.168.110.100-192.168.110.120
• x.x.x.[x-x], for example 192.168.110.[100-120]
This section describes:
• IP pool list
• IP pool options
• Configuring IP pools
• IP Pools for firewall policies that use fixed ports
• IP pools and dynamic NAT
Figure 101:Sample IP pool list
The IP pool list has the following icons and features.
Create New Select Create New to add an IP pool.
Start IP The start IP defines the start of an address range.
End IP The end IP defines the end of an address range.
The Delete and Edit/View icons.
Figure 102:IP pool options
Virtual IP has the following options.
Interface Select the interface to which to add an IP pool.
01-28006-0001-20041105
IP pool
207
