Custom Service List; Custom Service Options - Fortinet FortiGate FortiGate-50A Administration Manual

Service

Custom service list

Custom service options

194
Table 18: FortiGate predefined services (Continued)
Service name Description
WAIS Wide Area Information Server is an Internet
search protocol.
WINFRAME For WinFrame communications between
computers running Windows NT.
X-WINDOWS For remote communications between an
X-Window server and X-Window clients.
Add a custom service if you need to create a policy for a service that is not in the
predefined service list.
Figure 88: Sample custom service list
The custom services list has the following icons and features.
Create New Select a protocol and then Create New to add a custom service.
Service Name The name of the custom service.
Detail The protocol and port numbers for each custom service.
The Delete and Edit/View icons.
Different options appear depending on the protocol type of custom service you want to
define. Choose from TCP, UDP, ICMP, or IP.
TCP and UDP custom service options
Figure 89: TCP and UDP custom service options
Name The name of the TCP or UDP custom service.
Protocol Type Select the protocol type of the service you are adding: TCP or UDP. TCP
and UDP options are the same.
01-28006-0001-20041105
Firewall
Protocol Port
tcp 210
tcp 1494
tcp 6000-6063
Fortinet Inc.
