Testing A New Firmware Image Before Installing It - Fortinet FortiGate FortiGate-5001FA2 Installation Manual

FortiGate Firmware

Testing a new firmware image before installing it

FortiGate-5000 series Installation Guide
The FortiGate-5000 module installs the new firmware image and restarts. The
installation might take a few minutes to complete.
Restoring the previous configuration
Change the internal interface address if required. You can do this from the CLI using
the command:
config system interface
edit internal
set ip <address_ipv4mask>
set allowaccess {ping https ssh telnet http}
end
After changing the interface address, you can access the FortiGate-5000 module from
the web-based manager and restore the configuration.
• To restore the FortiGate-5000 module configuration, see
.
Guide
• To restore IPS custom signatures, see
• To restore web content filtering lists, see
• To restore email filtering lists, see
• To update the virus and attack definitions to the most recent version, see
FortiGate Administration Guide
If you are reverting to a previous firmware version (for example, reverting from
FortiOS v2.80 to FortiOS v2.50), you might not be able to restore your previous
configuration from the backup up configuration file.
You can test a new firmware image by installing the firmware image from a system
reboot and saving it to system memory. After completing this procedure the FortiGate-
5000 module operates using the new firmware image with the current configuration.
This new firmware image is not permanently installed. The next time the FortiGate-
5000 module restarts, it operates with the originally installed firmware image using the
current configuration. If the new firmware image operates successfully, you can install
it permanently using the procedure
page 44.
For this procedure you:
• access the CLI by connecting to the FortiGate console port using a null-modem
cable,
• install a TFTP server that you can connect to from port8. The TFTP server should
be on the same subnet as port8.
Note: The default interface for TFTP server firmware downloads is port8. You can specify a
different interface after you restart the FortiGate-5000 module as described in the following
procedure.
01-28011-0259-20060210
the FortiGate Administration Guide.
the FortiGate Administration Guide
the FortiGate Administration Guide
.
"Upgrading to a new firmware version" on
the FortiGate Administration
.
.
the
51
