Factory default settings

Factory default settings

Configuring NAT/Route mode

24
The FortiGate-5001FA2 unit ships with a factory default configuration. The default
configuration allows you to connect to and use the FortiGate-5001FA2 web-based
manager to configure the FortiGate-5001FA2 board onto the network. To
configure the FortiGate-5001FA2 board onto the network you add an administrator
password, change the network interface IP addresses, add DNS server IP
addresses, and, if required, configure basic routing.
Table 5: FortiGate-5001FA2 factory default settings
Operation Mode
Administrator Account
port1 IP/Netmask
port2 IP/Netmask
Default route
Primary DNS Server:
Secondary DNS Server:
Note: At any time during the configuration process, if you run into problems, you can reset
the FortiGate-5001FA2 board to the factory defaults and start over. From the web-based
manager go to System > Status find System Operation at the bottom of the page and
select Reset to Factory Default. From the CLI enter execute factory reset.
Use Table 6 to gather the information you need to customize NAT/Route mode
settings for the FortiGate-5001FA2 security system. You can use one table for
each board to configure.
Table 6: FortiGate-5001FA2 board NAT/Route mode settings
Admin Administrator Password:
IP:
port1
Netmask:
IP:
port2
Netmask:
Device (Name of the Interface
connected to the external
network):
Default Gateway IP address:
Default Route
The default route consists of the name of the interface connected
to an external network (usually the Internet) and the default
gateway IP address. The default route directs all non-local traffic to
this interface and to the external network.
Primary DNS Server:
DNS Servers
Secondary DNS Server:
NAT/Route
User Name: admin
Password: (none)
192.168.1.99/24
192.168.100.99/24
Gateway: 192.168.100.1
Device: port2
65.39.139.53
65.39.139.53
_____._____._____._____
_____._____._____._____
_____._____._____._____
_____._____._____._____
_____._____._____._____
_____._____._____._____
_____._____._____._____
FortiGate-5001FA2 Security System Guide
Quick Configuration Guide
01-30000-0379-20080606
