Pairing Instructions
iKey's BT-870-TP-SLIM unit is compatible
with any Windows or Android Operating
System device that has built in Bluetooth®
functionality.
-POWER ON: Press and hold the Power
Button for 3 seconds. Caps/Scroll/Num
Lock Indicators will flash twice and the
Power indicator will illuminate.
-POWER OFF: Press and hold the Power
Button for 3 second. All LED indicators will
turn off.
1. Power the keyboard ON.
2. Press and hold the Bluetooth Button until
the BT Link indicator begins to rapidly flash.
The BT-870-TP-SLIM is now is search mode.
3. Follow the Bluetooth pairing instructions
provided by your host computer.
4. The BT Link will become solid once a
connection is made and will turn off after 30
seconds.
NOTE: A slow flashing BT Link indicates the
keyboard is attempting to re-pair to the last
connected Bluetooth host computer.
Backlight Button
www.iKey.com • 512.837.0283
©2017 iKey, Ltd. All rights reserved.
BT-870-TP-SLIM
Operation Guide
Power Button
Bluetooth®
Button
Sleep Mode
•
The BT-870-TP-SLIM will go into sleep mode af-
ter 30 minutes of inactivity. To wake simply
press any key.
•
To wake the unit from sleep mode press
any key. BT-870-TP-SLIM will
automatically re-pair to the last connected
Bluetooth host computer.
Charging Instructions
•
To charge the keyboard, insert the provided
Micro USB charging cable into the back of the
keyboard and plug the other end of the cable
into a powered USB port on any computer.
The Charging LED indicator will illuminate
orange when charging and will turn off when
fully charged. In a fully discharged state,
the battery takes 5-6 hours to completely
recharge.
•
With average usage of the keyboard, the
anticipated battery life is three to four weeks.
Note:TheBT-870-TP-SLIM
ships from iKey with the internal
battery
fully
charged
ready to use out of the box.
and
Advertisement
Table of Contents
Related Manuals for iKey BT-870-TP-SLIM
Summary of Contents for iKey BT-870-TP-SLIM
- Page 1 Pairing Instructions Sleep Mode • The BT-870-TP-SLIM will go into sleep mode af- iKey’s BT-870-TP-SLIM unit is compatible ter 30 minutes of inactivity. To wake simply with any Windows or Android Operating press any key.
- Page 2 Switching to wired USB: In the event the Bluetooth connection is • disrupted by interference, the BT-870-TP-SLIM can switch to being a wired USB keyboard by connecting the keyboard to the computer via the supplied MicroUSB cable. When connected via USB the keyboard will begin to charge and communicate over USB.
- Page 3 3. Connect the equipment into an outlet on a circuit different from that to which the reciever is connected. 4. Consult the dealer or an experienced radio/TV technician for help. ***The User should not modify or change this equipment without written approval from iKey, Ltd. Modification could void authority to use this equipment.*** FCC Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
