Videonics PTM-1 User Manual

Personal titlemaker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Personal
TitleMaker
PTM–1
User Guide
Table of Contents
MANL-0715-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PTM-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Videonics PTM-1

Summary of Contents for Videonics PTM-1

  • Page 1 Personal TitleMaker PTM–1 User Guide Table of Contents MANL-0715-01...
  • Page 2 Disclaimers Television screens are simulated. Subject to change without notice. This device is not to be used for the unau- thorized copying of copyrighted material. Trademarks TitleMaker is a trademark of Videonics, Inc.The Videonics logo, Thumbs Up, and Videonics Video TitleMaker are registered trademarks of Videonics, Inc.

  • Page 3: Table Of Contents

    1 Introduction Major Features ..........2 Personal TitleMaker Package Contents .
  • Page 4 Contents 4 Personal TitleMaker Tutorial What You Need ..........34 Objective .
  • Page 5 Page Attributes ..........69 Setting In Effects and Page Duration .
  • Page 6 Contents 8 Working with Menus Menu Structures ..........90 The Color Menus .
  • Page 7 A Personal TitleMaker Demo Running a Locked Demo ........128 Using the Demo as a Boilerplate .
  • Page 8 Notes ®...
