- Page 1 Quadnet / Duonet Repeater Panel V3 (Suitable for Quadnet / Duonet repeater panels from V2.00) Repeater Panel User Guide (TO BE RETAINED BY USER) 26-0855 Issue 3...
- Page 2 Fike’s policy is one of continual improvement and the right to change a specification at any time without notice is reserved. Whilst every care has been taken to ensure that the contents of this document are correct at time of publication, Fike shall be under no liability whatsoever in respect of such contents.
-
Page 3: Table Of Contents
Quadnet / Duonet Repeater Panel User Guide Contents Introduction ......................4 Purpose of the Guide .................. 4 Definitions....................4 Understanding the Equipment ..............4 System Configuration .................. 5 What to do if……..................5 User Responsibilities ..................... 6 Introduction....................6 Routine Testing ................... -
Page 4: Introduction
What is Multipoint? This is the name of the automatic detector used in the Quadnet / Duonet installation. The Multipoint is a unique device, which provides several modes of detection & sensitivity options within a single device, enabling it to be easily configured for the application. -
Page 5: System Configuration
The system is powered from the mains supply and incorporates a standby battery which automatically maintains the system in operation for a time of at least 48 hours in the event of a mains supply failure. Note: the following controls can be carried out on a Quadnet / Duonet Repeater Panel. Silence Alarms... -
Page 6: User Responsibilities
Routine Testing For details on routine testing see the Quadnet Control Panel User Guide or the Duonet Control Panel User Guide. Any defects should be recorded in the log book and reported to the responsible person. A certificate of testing should also be completed and given to the responsible person. -
Page 7: General Operation
Quadnet / Duonet Repeater Panel User Guide General Operation Repeater Panel Front General Indication LEDs fire fault disabled test power V3.00 Panel 01: PANEL 01 Repeater Panel Information Window 23/05/11 23:01 NORM DUONET REPEATER Active Information Window TURN KEY OR ENTER CODE FOR CONTROLS... -
Page 8: Fire Alarm Controls
Quadnet / Duonet Repeater Panel User Guide Fire Alarm Controls Note: The Menus on repeater panels are exactly the same as the menus on control panels. Controls sent from repeater panels are limited but all controls will still appear in the menu structure in the repeater panel. -
Page 9: Access Levels And Codes
The codes may be changed using the Quadnet / Duonet OSP software. A valid access level code must be entered in order access any of the menus. -
Page 10: Resetting The System
Quadnet / Duonet Repeater Panel User Guide Resetting the System Before attempting to reset the system, the cause of the alarm should be established. Press ’RESET SYSTEM’ The panel buzzer and the fire indication lights should switch off. However, if any alarm condition still exists, eg., a... -
Page 11: Troubleshooting
Quadnet / Duonet Repeater Panel User Guide Troubleshooting Problem Possible Cause Remedial Action Unable to silence Panel not in Access Level 2A (User) Enter Access Level 2A (User) or Access alarms or Access Level 2B (Supervisor) Level 2B (Supervisor) - see section on operation. -
Page 12: Advanced Operation
Quadnet / Duonet Repeater Panel User Guide Advanced Operation Access Level 1 (Normal): Controls Enabled LED off At Access Level 1 (Normal), the main Fire Alarm Controls are disabled and the Controls Enabled LED is switched off. A valid access level code must be entered or the key switch must be used in order access any of the menus. -
Page 13: Access Level 2B (Supervisor)
Quadnet / Duonet Repeater Panel User Guide Access Level 2B (Supervisor): Controls Enabled LED flashing slowly At Access Level 2B (Supervisor), the main Fire Alarm Controls are enabled, and the following System Controls are accessible: 1. Delay On / Off 2. - Page 14 Quadnet / Duonet Repeater Panel User Guide 3. View Logs 2. Current Faults The Active Faults Log will display any current faults. These are displayed in text format and may be scrolled through by pressing the UP and DOWN keys.
- Page 15 Quadnet / Duonet Repeater Panel User Guide 6. Test Modes 1. Silent Test Not applicable. 6. Test Modes 2. Local Audible Test Not applicable. 6. Test Modes 3. System Test Not applicable. 7. Day / Night Mode 1. Override into Day Mode Not applicable.
-
Page 16: Led Indication
Quadnet / Duonet Repeater Panel User Guide LED Indication The operation of the LED indications on the front of the panel is described below. As this is a repeater panel, not all of the following indications are applicable. Description Colour... - Page 17 Quadnet / Duonet Repeater Panel User Guide FAULT OUTPUT Yellow Flashing A monitored output programmed to operate as a Fire Output is in the fault state. Continuous A monitored output programmed to operate as a Fire Output has been disabled.
-
Page 18: Log Book
Quadnet / Duonet Repeater Panel User Guide LOG BOOK Record all fire and fault events, whether or not an engineer was called Event Log Time Zone/Device Event Action Initials... - Page 19 Quadnet / Duonet Repeater Panel User Guide Time Zone/Device Event Action Initials...
- Page 20 Quadnet / Duonet Repeater Panel User Guide Time Zone/Device Event Action Initials...
- Page 21 Quadnet / Duonet Repeater Panel User Guide Time Zone/Device Event Action Initials...
- Page 22 Quadnet / Duonet Repeater Panel User Guide Time Zone/Device Event Action Initials...
- Page 23 Quadnet / Duonet Repeater Panel User Guide Time Zone/Device Event Action Initials...
-
Page 24: Installation Details
Quadnet / Duonet Repeater Panel User Guide Installation Details This section should be completed by the commissioning engineer at handover. ……….….………………………………………………………..…………. Name of Responsible Person: …………………..……………...………………………………………. Name and Address of Installation: .…………………………………………………………….………………………………………………………. Ref. No. (if applicable): ……….………………………………………………………………………………… ……….………………………………………………………………………………… Date of Handover: Name and Address of Installer: …………...………...…………………………………………………………...
