FIKE SAFETY TECHNOLOGY LTD.
Do not attempt to use this equipment until you have fully read and understood this guide.
A knowledge of BS5839-1: Fire Detection and Alarm Systems for Buildings is essential.
It is strongly recommended that a suitably qualified and competent person is consulted in connection with the Fire Alarm System
design and that the entire system is commissioned in accordance with the current national standards and specifications.
Equipment Guarantee
The equipment carries no warranty unless the system is installed, commissioned and serviced in accordance with the manual and the
relevant standards by a suitably qualified and competent person or organisation.
Access Level
Description
1 – NORM
Normal
2A – USER
2B – SUPR
Supervisor
3 – ENGR
Engineer
Installation Guide
Controls LED
OFF
User
ON
SLOW FLASH
FAST FLASH
31 Springvale Industrial Estate
Cwmbran, Tofaen, NP44 5BD, UK.
+44 (0) 1633 865 556
Surface Mounting
The five mounting holes should be used to
secure the cabinet to a solid wall using
suitable screws of at least 50mm in length.
Ensure that a minimum gap of 50mm is left
between the sides of the back box and any
wall or projection (such as another box )
Key Operation
Default Code
NO
N/A
YES
8737
NO
7877
NO
3647
Document No. 26-1867-01
Subject to change
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Fike RDU-A-400
Summary of Contents for Fike RDU-A-400
- Page 1 FIKE SAFETY TECHNOLOGY LTD. Installation Guide Do not attempt to use this equipment until you have fully read and understood this guide. A knowledge of BS5839-1: Fire Detection and Alarm Systems for Buildings is essential. It is strongly recommended that a suitably qualified and competent person is consulted in connection with the Fire Alarm System design and that the entire system is commissioned in accordance with the current national standards and specifications.
- Page 2 RDU-A-400 Installation Guide CIE-A-400 Control Panel Engineering and Commissioning Manual Fire Alarm Controls The menus on repeater panels are exactly the same as the menus on a control panel. However, most of the controls are not relevant for repeater panels so will give the message ‘ NOT AVAILABLE ON RDU’.
- Page 3 RDU-A-400 Installation Guide CIE-A-400 Control Panel Engineering and Commissioning Manual Connections The jumpers are fitted to impedance match the cable with the driver ICs & prevent signal reflections down the cable. The jumpers must be changed on the CIE and last RDU.
- Page 4 Fike’s policy is one of continual improvement and the right to change a specification at any time without notice is reserved. Whilst every care has been taken to ensure that the contents of this document are correct at time of publication, Fike shall be under no liability what- soever in respect of such contents.
