- Page 1 NSTALLATION 60” D HIS MODEL IS NOT FIELD CONVERITBLE FOR FROM THE ACTORY SET FOR HIS MODEL IS NOT FIELD CONVERTIBLE FOR ACTORY SET FOR F YOU HAVE QUESTIONS CALL WEBSITE NSTRUCTIONS ROFESSIONAL ANGE ODELS ONVECTION LEAN 60” N ATURAL ODELS *TN637-7BW *TN637-7W...
-
Page 2: Before You Begin
Consumer. • Note to Consumer Keep these instructions for future reference. • FiveStar recommends this product be installed by a licensed professional. • Product failure due to improper installation is not covered under the Warranty. WARNING: This appliance must be properly grounded. - Page 3 This will help eliminate possible damage to the backguard that is packed in the top of the range carton. Remove, unwrap and temporarily lay aside any parts that are not attached to the range.
-
Page 4: Remove Packaging
REMOVE PACKAGING Before moving the range indoors: Remove outer carton and packing material from the shipping base. The range is now ready for removal from the wooden base. STEP 2 Due to the weight of these ranges, use a dolly with soft wheels to move this range. - Page 5 STEP 5 CONNECTING THE RANGE TO ELECTRIC WARNING: THIS APPLIANCE MUST BE CONNECTED AS SHOWN IN FIGURE 1 OR 2. IF THE CORD IS REPLACED IT MUST BE RATED AT 250 VOLTS, 40 AMPERES AND CERTIFIED FOR USE ON HOUSEHOLD RANGES.
-
Page 7: Installing The Backguard
LEASE READ ALL INSTRUCTIONS BEFORE STARTING INSTALLATION Remove the burner grates, griddle/grill and housing. From the front of the range, remove the Phillip screws in the rear of each burner pan (black pan where the top burners are located). From the rear of the range, remove two screws from the rear of the side panels, the upper most screw on each side. -
Page 8: Level The Range
STEP 8 LEVEL THE RANGE 1. Remove shipping tape from the leveling legs. 2. Carefully slide the range into position. Be careful not to damage the floor or entangle power cord and gas flexible tubing. 3. To adjust leveling legs, turn counter- clockwise to raise the range;... -
Page 10: Electric Oven
STEP 11 OVEN OPERATION GAS OVEN • Turn oven thermostat knob counter clockwise to 350°. • The oven burner should light within 60 seconds. ELECTRIC OVEN • Turn oven thermostat knob counter clockwise to 350° in bake position. It will take a couple of minutes before a change in color will occur to the lower element. - Page 11 STEP 13 CHECKLIST FOR SEALED BURNER INSTALLATION MAKE SURE ALL CONTROLS ARE IN THE “OFF” POSITION. Gas supply is “on” Electric power is “on” Check for proper seating of burner caps into burner base Burner grates in position Oven and broiler racks installed Surface burner ignition test Griddle/Grill burner ignition test Griddle/Grill assembly in position...
