This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service
or repair the products dealt with in this service information by anyone else could result in serious injury or death.
In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.
WARNING
PRECAUTION OF LOW TEMPERATURE
Indoor Unit
CS-XZ7SKEW
CS-XZ9SKEW
CS-XZ12SKEW
CS-XZ18SKEW
Order No: PAPAMY1604028CE
Outdoor Unit
CU-Z7SKE
CU-Z9SKE
CU-Z12SKE
CU-Z18SKE
Destination
EU
E.Europe
L.America
Turkey
© Panasonic Corporation 2016
