AMERICAN STANDARD TELECASTER 0108400/8402
WHITE WIRE FROM
NECK PICKUP
YELLOW WIRE FROM
BRIDGE PICKUP
BLACK WIRE FROM
BRIDGE PICKUP
WHITE WIRE FROM
OUTPUT JACK
BLACK WIRE FROM
OUTPUT JACK
BRIDGE ASSEMBLY
22
23
24
CONTROL ASSEMBLY
25
SHIELD WIRE FRROM
NECK PICKUP
18
12
17
13
Pg. 2 of 4
11-28-99
