Connections rear side of the device
1 2
3
26
25
24
23
HDMI 1 - HDMI input 1
1
HDMI 2 - HDMI input 2
2
PC IN - VGA/XGA input
3
AV - Euro-AV socket
4
LAN - Network connection
5
6
USB - USB connection
AUDIO IN - Audio input (analogue)
7
AUDIO DIGITAL OUT - Digital audio output
8
AUDIO DIGITAL IN - Digital audio input
9
CENTER IN - Centre audio input (analogue)
10
11
SERVICE - Service socket
ANT-TV - Antenna/cable analogue/digital
12
ANT SAT - Satellite antenna (Sat tuner 1)
12
ANT SAT 2 - Satellite antenna (Sat tuner 2)
12
AUDIO LINK - Surround audio outputs (analogue)
13
4
5
6 7
8
(1 (2
(1 (2
(1 (2
11
CI-COMMON INTERFACE - Common Interface 1 (CI slot 1)
14
CI-COMMON INTERFACE - Common Interface 2 (CI slot 2)
15
HDMI 3 - HDMI input 3
16
USB - USB connection
17
- Headphones connection
18
19
AUDIO IN L - Audio in left (AVS)
AUDIO IN R - Audio in right (AVS)
20
VIDEO IN - Video in (AVS)
21
AVS - S-Video connection (AVS)
22
220-240V~ 50/60Hz – Mains connection
23
IR LINK - Infrared transmitter connection
24
CONTROL - Rotating stand control
25
RS-232C - Serial interface
26
(1
Equipment and upgrade options, see page 146.
The position of the aerial sockets depends on the tuner equipment.
(2
12
13
14
15
16
17
18
19
20
21
22
11 -
