Summary of Contents for Loewe Connect 55

  • Page 1 Connect Connect 55 Connect 48 Connect 40 Connect 32 DR+ User manual...

  • Page 2: Imprint

    Connect 32 DR+ - Connect 55 User manual Imprint Imprint Loewe Technologies GmbH Industriestraße 11 Editorial date 01/16-3.0 TB D-96317 Kronach © Loewe Technologies GmbH, Kronach www.loewe.tv ID: 2.2.13.0 All rights including translation, technical modifications and errors reserved.

  • Page 3: Table Of Contents

    Remote control button mapping ..........8 Photo ...................67 Operating controls on the TV set ..........9 Photo display ....................68 Connections rear side of the device Connect 55/48/40 ..10 Web ..................... 69 Connections rear side of the device Connect 32 DR+ ....11 MediaNet .....................69 Browser ......................71...
  • Page 4 Connect 32 DR+ - Connect 55 User manual Table of contents External devices ................117 Devices to the HDMI connections ............117 Digital Link HD ....................118 Devices on AV .....................119 Connecting the speaker system (AUDIO OUT) ........121 Connecting the speaker system (DAL) ..........121 Connecting active loudspeakers ............

  • Page 5: Welcome

    Thank you, About this user manual for choosing a Loewe product and having placed your trust in us. For best results regarding safety and the longevity of the set, we recommend you read the chapter For your safety before switching With Loewe you have not simply decided on a modern and technically the TV set on for the first time.

  • Page 6: For Your Safety

    TV set. upper and lower edges of the housing. Please use the Loewe 3D TV sets only with the Loewe 3D glasses which can be purchased as an accessory from your Loewe dealer. Do not stand it up on the bottom edge, so as to reduce the risk of damage and soiling.
  • Page 7 For your safety Set-up Automatic shutdown Loewe flatscreen TV sets are specified for Loewe accessories. The TV If the TV is not operated for 4 hours (adjustment of volume, programme set is suitable for mounting in many different ways. Note the assembly change, etc.) the TV will automatically switch to stand-by mode to save...

  • Page 8: Remote Control Button Mapping

    Connect 32 DR+ - Connect 55 User manual Remote control Remote control button mapping Depending on the selected operating mode (TV/Video/Audio/Photo/Web) and function (e.g. DR+, EPG, PIP, Teletext, HbbTV, etc.), the key assignment may differ from the assignment described here (see the corresponding chapter in this user manual).

  • Page 9: Operating Controls On The Tv Set

    Connect 32 DR+ - Connect 55 User manual Operating controls on the TV set Functions of the operating elements Mains switch: The mains switch is located on the bottom of the set. Always return the TV set to Standby mode before switching it off with the main switch.

  • Page 10: Connections Rear Side Of The Device Connect 55/48/40

    DIGITAL AUDIO LINK - Surround audio outputs (digital) – (RJ45) A: in case of Connect 55/ 48/ 40 (5444xx50). Optional connection for individual country-specific variants of the TV set. B: in case of Connect 55 (54443x51). Connection for a motorized swivel stand.

  • Page 11: Connections Rear Side Of The Device Connect 32 Dr

    Connect 32 DR+ - Connect 55 User manual Connections rear side of the device Connect 32 DR+ Position and function of the connections Connect 32 DR+ Slot for Kensington lock HEADPHONE - Headphone connection Jack 3,5 mm – Headphones 32–200 Ohm AC IN - Mains connection Mains socket –...

  • Page 12: Preparing The Tv Set

    (see installation instructions of the table stand). Cable DVB-T DVB-S analogue / In case of the Connect 55 with wall mount WM67 you can thread the DVB-C Velcro cable tie through the two openings of the rear wall. Connect 32/40/48 Connect 55...

  • Page 13: Preparing The Remote Control Unit

    WLAN antenna. Only use leak-proof micro-cells of the LR 03 (AAA) Alkali-Manganese In order to play back data from your home network your Loewe TV type. Do not use different types of batteries and old and new batteries supports the UPnP AV standard.

  • Page 14: Switching The Tv Set On/Off

    USB hard disks with the TV set. indicator in the control panel lights up in green. Loewe are not liable for the loss of data on the integrated hard disk of your TV set. To avoid data loss, we recommend copying important recordings to an external storage medium.

  • Page 15: General Information On Menu Operation

    Connect 32 DR+ - Connect 55 User manual General information on menu operation General information on menu operation Structure of the Menu screen Basically, the structure of the different menu screens is similar, The most important keys for navigation will be explained in general.
  • Page 16 Connect 32 DR+ - Connect 55 User manual General information on menu operation Screen structure: Setup (example: picture) Navigation: Wizards Picture ad- justment If your desired display format has not been automatically Picture Contrast selected then you can choose it in the 3D settings menu.
  • Page 17 Connect 32 DR+ - Connect 55 User manual General information on menu operation Entering characters with on-screen keyboard Table of characters for entering text by means of the remote control For certain functions, entering letters or characters is required, e.g., for Web addresses (URLs) in the browser or for renaming archive entries.

  • Page 18: On-Screen Displays

    Connect 32 DR+ - Connect 55 User manual On-screen displays Operation without remote control Explanation of keys Operation without remote control An explanation of the main operating keys that can be used at the Changing Volume moment, can be displayed.

  • Page 19: Initial Installation

    Connect 32 DR+ - Connect 55 User manual Initial installation Initial installation wizard Energy Home mode: efficiency The emphasis for home use is on low energy (continued) Initial installation after switching on for the first time consumption. The automatic dimmer is activated.
  • Page 20 Connect 32 DR+ - Connect 55 User manual Initial installation Connect Setting options for reception via Cable analog: antennas If you have not selected Cable analog in step Connect antenna Connect antenna cable(s) cable(s) Your television will automatically search for stations. With...
  • Page 21 Connect 32 DR+ - Connect 55 User manual Initial installation Setting options for DVB-T reception: Supply voltage If you have not selected Terrestrial (DVB-T) in step Connect antenna cable(s) in the initial installation, proceed to the next section Setting options for DVB-C reception.
  • Page 22 Connect 32 DR+ - Connect 55 User manual Initial installation Setting options for DVB-C reception: Network ID If you select none here, DVB signals of all current If you have not selected Cable (DVB-C) in step Connect antenna transmitter networks are searched automatically cable(s) in the initial installation, proceed to the next section Setting (recommended for most cable networks).
  • Page 23 Connect 32 DR+ - Connect 55 User manual Initial installation Setting options for DVB-S reception: other Select setting if the TV set is connected to a If you have not selected Satellite (DVB-S/cable x) in step Connect communal single-cable system (without DiSEqC). Several...
  • Page 24 Connect 32 DR+ - Connect 55 User manual Initial installation Setting options for the satellite system (single satellite): Setting options for the satellite system (2 satellites on 22 kHz switchbox / 2 satellites on toneburst switch): Select single satellite Satellite...
  • Page 25 Connect 32 DR+ - Connect 55 User manual Initial installation Setting options for the satellite system LNB frequencies frequencies (max. 4 satellites on DiSEqC multiswitch): Please select the LNB frequencies for both High and Low Bands. Note: The newly selected parameter in each case must be confirmed with the button.
  • Page 26 Connect 32 DR+ - Connect 55 User manual Initial installation Setting options for the satellite system frequencies (DiSEqC one cable communal system): Number of LNB frequencies system channel used ASTRA1 19,2°E low Band 9750 MHz 10000 MHz 10200 MHz 10600 MHz ASTRA1 19,2°E high Band...
  • Page 27 Connect 32 DR+ - Connect 55 User manual Initial installation Setting options for the satellite system (other communal installation): Select single satellite Select satellites Please specify here which satellite you receive. Note: The newly selected parameter must be confirmed with the button.
  • Page 28 Connect 32 DR+ - Connect 55 User manual Initial installation Setting options for DVB-S reception (continued): Test reception You should now receive a picture and sound from the following satellite: Astra1 19,2°E Level Otherwise, please adjust your antenna. If it is already correctly adjusted, please continue all the same, without receiving picture or sound for the moment.
  • Page 29 Connect 32 DR+ - Connect 55 User manual Initial installation Age-related Setting options for all types of reception: lock Subtitle and Subtitle and audio languages (DVB) audio You can preset the desired languages and reserve languages for subtitles and audio for Age-related lock DVB programmes here.

  • Page 30: Tv Set As A Monitor

    Connect 32 DR+ - Connect 55 User manual Initial installation Inform about Sound playback new software via ... Software-Update Sound playback via ... You have the option of performing a software update via the Internet. Please specify Please specify here via which sound components you want to listen to your TV sound. If you whether the TV set is to automatically inform you about newly available software.

  • Page 31: Home View

    Connect 32 DR+ - Connect 55 User manual Home view Home view Home view - Favourites The Home view is the central overview page for all of your TV set‘s You will find your favourites on the right of the individual operating operating modes.

  • Page 32: Setting The Volume

    Connect 32 DR+ - Connect 55 User manual Volume / Station Selecting a station out of the station list In normal TV mode, without other displays: In TV mode that can be selected via the Home overview, you can use the basic TV functions of your TV set.
  • Page 33 Connect 32 DR+ - Connect 55 User manual Station Selecting stations by means of the expanded station list Selecting stations by personal lists You can save your preferred stations in personal lists (e.g., for several In normal TV mode, without other displays: users).

  • Page 34: Status Display

    Virtual speaker (VS mode) developed by Dolby is activated for the virtual sound reproduction in sound mode (4) and (5). In sound mode HDTV programme. (3), proprietory settings of Loewe are used for the virtual reproduction. HbbTV mode available from this station.

  • Page 35: Function List (Tv Mode)

    Connect 32 DR+ - Connect 55 User manual Function list / AV list Function list (TV mode) Explanations of the symbols in the function list (continued): Call Edit station list. The function list contains settings and additional options. Die individual Delete stations, shift stations, restore deleted stations.

  • Page 36: Electronic Programme Guide - Epg

    Connect 32 DR+ - Connect 55 User manual Electronic Programme Guide Electronic Programme Guide – EPG Meaning of the colours in the EPG The coloured labels indicate the genre of the respective programme. EPG stands for Electronic Programme Guide and provides you with When filtering with genre selection in the header, the programmes of on-screen programme details.
  • Page 37 Connect 32 DR+ - Connect 55 User manual Electronic Programme Guide Switching to the current broadcast Calling additional information about the programmes Mark current broadcast. INFO: Call up detailed information. OK press briefly: switch to current broadcast. Detailed info Back The electronic programme guide will be closed.
  • Page 38 Connect 32 DR+ - Connect 55 User manual Electronic Programme Guide Recording a programme via EPG Adapting the EPG Overview You can programme timer recordings of TV programmes conveniently The options to be selected are in the header, using the EPG.

  • Page 39: Teletext

    Connect 32 DR+ - Connect 55 User manual Teletext Teletext Additional page selection possibilities First possibility: Your TV set supports the two operating systems TOP text and FLOF. Up to 2000 pages are stored in order to get quick access.

  • Page 40: Connect

    Connect 32 DR+ - Connect 55 User manual Teletext Newsflash Some text pages, e.g., live tickers, will be permanently updated. In order to keep track of changes and also to be able to watch the TV programme at the same time you may hide the Teletext temporarily and can still remain informed on updates of the page.

  • Page 41: Hbbtv / Mediatext

    Connect 32 DR+ - Connect 55 User manual HbbTV / MediaText HbbTV / MediaText Opening HbbTV text directly Depending on the programme provider, the direct HbbTV (Hybrid broadcast broadband television) offers the user Call of MediaText may not be possible. MediaText comprehensive multimedia contents, e.g., media centres or additional...

  • Page 42: Picture In Picture (Pip)

    Connect 32 DR+ - Connect 55 User manual Picture in Picture (PIP) Selecting the station of the PIP picture If the frame colour of the PIP picture is not green, The concurrent display of two different images is referred to as Picture press the green key.

  • Page 43: Digital Recorder

    You can record programmes on the integrated hard disk of your TV You see the station’s live picture again. set with the digital recorder of your Loewe TV set. The TV broadcast that you watch is automatically recorded in the background.

  • Page 44: Archive Recording

    Connect 32 DR+ - Connect 55 User manual Digital Recorder Archive recording Viewing another programme from the archive during archive recording Programmes that you wish to watch at a later date can be recorded in After you have started the recording, you can also watch a programme the Digital Recorder Archive (DR+ archive).

  • Page 45: Multi Recording

    Connect 32 DR+ - Connect 55 User manual Digital Recorder Subtitles Multi recording Subtitles of a broadcast can also be stored during recording. The Multi Recording function makes it possible to record two pro- The recording of subtitles in DR+ continuous mode must be grammes at the same time and still watch a third one as well.

  • Page 46: Dr+ Archive

    Connect 32 DR+ - Connect 55 User manual Digital Recorder DR+ archive DR+ archive function list The function list of the DR+ archive contains the individual function With the DR+ archive you have access to all the recorded programmes for its archive entries.
  • Page 47 Connect 32 DR+ - Connect 55 User manual Digital Recorder Displaying detailed information on the recording Multi select If detailed information exists on the recorded broadcast from the EPG, Multiple selection allows to mark several archive entries and then you can deplay it.

  • Page 48: Connect

    You can copy/move archive entries to an externally connected USB In the DR+ archive, you can create new directories when using the storage device or to the hard disk of compatible Loewe TV sets in the function move. home network.
  • Page 49 To avoid data loss, we recommend copying important recordings to an external USB hard disk (see Export of archive entries). Viewing a locked movie Loewe are not liable for data loss from the Digital Recorder’s hard disk. The desired locked entry in the DR+ archive is marked.

  • Page 50: Dr + Streaming

    The TV sets also need to be connected via a network (wireless To use DR + streaming, at least two Loewe TV sets are required, of connection via WLAN or cable connection via Ethernet, PowerLine).

  • Page 51: Timer

    Connect 32 DR+ - Connect 55 User manual Timer Timer New instruction: New recording In the Timer list: In the timer menu you will find the Timer List and the Timer Services. All programmed recordings, earmarked programmes and copy jobs Mark Create newly, are listed in the timer list.
  • Page 52 Connect 32 DR+ - Connect 55 User manual Timer New recording – Manual recording (current station) New copy job You should copy recordings that you want to save permanently on an In the Timer list, New recording is selected. external USB hard disk.
  • Page 53 Connect 32 DR+ - Connect 55 User manual Timer Delete/change programmed timer instruction Entering the Timer data After selecting the station you wish to record, timer data will be Use this function in the timer list if you want to delete recordings displayed.
  • Page 54 Connect 32 DR+ - Connect 55 User manual Timer Explanations of the setting options in the menu Timer data – Timer Services Additional options This menu offers you convenient alarm services. Programmed alarms are also active when the TV set has been switched off to standby.

  • Page 55: Video

    Connect 32 DR+ - Connect 55 User manual Video Video Video function list The video function list contains the individual functions for your videos. The item Video gives you access to videos from local (USB, home network) and online sources.

  • Page 56: Video Playback

    Connect 32 DR+ - Connect 55 User manual Video Video playback Symbol Remote Description (icon) control key The description of the following functions applies to the playback of videos from the DR+ archive as well as for videos from USB storage –...

  • Page 57: User Manual

    Connect 32 DR+ - Connect 55 User manual Video Pause playback (freeze picture) Skipping with Smart jump The Smart jump function ensures that the jump width is halved each PAUSE key: Switch to freeze picture. time the jump direction is changed or doubled after three jumps in the same direction (max.

  • Page 58: User Manual

    Connect 32 DR+ - Connect 55 User manual Video Wind Repeat To search for desired scenes in movies you can fast forward and rewind Videos can be repeated, i.e., replayed in an endless loop. Depending at three different speeds. Sound is not audible during winding.

  • Page 59: Additional Functions For Dr+ Archive Playback

    Connect 32 DR+ - Connect 55 User manual Video Select language/sound Additional functions for DR+ archive playback Videos, especially those recorded from TV broadcasts, can contain There are additional editing and playback functions for playback of several sound tracks. recorded programmes from the DR+ archive.

  • Page 60: User Manual

    Connect 32 DR+ - Connect 55 User manual Video Deleting individual bookmarks Interval functions Jump to the manually set bookmark to be deleted. The intervals between manually or automatically set bookmarks (intervals) can be faded out for future playbacks. Back...

  • Page 61: User Manual

    Connect 32 DR+ - Connect 55 User manual Video Show hidden sections Determine cover picture A screen message will appear when a hidden section is skipped during The covers for the display of the entry in the DR+ archive can be freely replay of a DR+ archive entry.

  • Page 62: Audio/Radio

    Connect 32 DR+ - Connect 55 User manual Audio/Radio Audio/Radio Audio/Radio function list The audio/radio function list contains the individual functions for your With item Audio/Radio you find music files from your USB storage music titles. media and media servers in the home network and you access DVB An audio source has been selected.

  • Page 63: Audio Playback

    Connect 32 DR+ - Connect 55 User manual Audio/Radio Audio playback Pause playback PAUSE key: Stop current playback. Description of the symbols in the status display for audio playback Snow Patrol / Eyes Open Back Snow Patrol / Eyes Open...

  • Page 64: User Manual

    Connect 32 DR+ - Connect 55 User manual Audio/Radio Select another title / play current title from start Shuffle playback The music titles of your current medium are replayed in random order. BACK: Call music selection. Select music title as described in chapter Audio/ Mark Shuffle playback Radio, section Selecting music titles.

  • Page 65: Radio Mode (Dvb Radio)

    Connect 32 DR+ - Connect 55 User manual Audio/Radio Radio mode (DVB radio) Explanation of keys INFO (press longer): show Explanation of keys. The TV set can receive digital radio stations via DVB. The AUDIO key has been preset to radio mode in the factory.

  • Page 66: Radio Mode (Internet Radio)

    Connect 32 DR+ - Connect 55 User manual Audio/Radio Radio mode (Internet radio) Artist Search (Search for artists) By means of the search for artists, you can quickly and easily see all The TV set can receive digital radio stations via the Internet.

  • Page 67: Photo

    Connect 32 DR+ - Connect 55 User manual Photo Photo Photo function list The photo function list contains the individual functions for your Via menu item Photo you can view photos from your local media and photos. from online sources on your TV screen.

  • Page 68: Photo Display

    Connect 32 DR+ - Connect 55 User manual Photo Photo display Full-screen mode A photo is highlighted in the selection (list view). Description of the symbols in the status display for photos OK View photo in full-screen mode. USB1 -> CRW_7266b Back USB1 ->...

  • Page 69: Web

    Connect 32 DR+ - Connect 55 User manual MediaNet Here you have access to multimedia content in the Internet (MediaNet) Call MediaNet as well as a high-quality web browser. To use the full functionality of MediaNet, the TV set must be connected to the Internet.

  • Page 70: User Manual

    Connect 32 DR+ - Connect 55 User manual MediaNet – Browse Define application as favourite Under the item Browse, you browse the full range of applications by Mark the desired application. topic. MediaNet-Browse is called. Add the marked application to the Home favourites.

  • Page 71: Browser

    Connect 32 DR+ - Connect 55 User manual Browser Entering a URL (Internet address) Browser status is displayed. You can access Internet sites directly using the integrated Opera browser. The web browser can also be used without an Internet Mark the URL (Internet address) of the connection.

  • Page 72: System Settings

    Connect 32 DR+ - Connect 55 User manual System settings System settings Menu items Stations: Automatic scan TV+Radio, Manuell scan (incl. Under the menu item System settings in the Home menu you find antenna status), Station lists TV, Station lists Radio, all settings and adaptabilities of your TV set.

  • Page 73: Picture

    Image+ Active is a special picture improvement a so-called deblocking filter can be activated which Active developed by LOEWE which provides a detailed and counteracts this interference. contrasting, sharper, natural and true colored picture which is rich in detail and contrast.

  • Page 74: User Manual

    The picture format when in 3D operation is always 16:9 PC. You require a pair of Loewe Active Glasses 3D to be able to use the 3D functionality in its entirety (see chapter Accessories). Please read the operating instructions included with the 3D glasses.

  • Page 75: User Manual

    Connect 32 DR+ - Connect 55 User manual System settings Picture Picture adjustment Selecting the picture format By selecting one of the preset picture adjustment modes (Home The setting options depend on the transmitted picture content. Mode, Premium Mode, Cinema Mode or Shop Mode), the picture HOME: Call Home view.

  • Page 76: Sound

    Connect 32 DR+ - Connect 55 User manual System settings Sound Sound Explanations of the sound settings (continued): Dolby PLII In matrix mode, the front speakers are „mirrored“ Calling the sound settings mode to the rear speakers. Front left is mixed with left rear,...

  • Page 77: Stations

    Connect 32 DR+ - Connect 55 User manual System settings Stations Stations Under the item Stations you find all settings concerned with station search for TV and DVB radio as well as functions for creating and editing the various station lists.

  • Page 78: Automatic Scan Tv+Radio

    Connect 32 DR+ - Connect 55 User manual System settings Stations Automatic scan TV+Radio Explanations of some search settings (continued): DVB-T/C/S If several networks are available, you can decide For automatic scan TV+Radio, a search wizard will be started that...

  • Page 79: Manual Scan Tv / Radio

    Connect 32 DR+ - Connect 55 User manual System settings Stations Search for/update stations – handling of new and no longer Manual Scan TV / Radio found stations Here, you can enter all the settings available for a station. However, The number of new TV stations found is displayed after the automatic this requires detailed knowledge.

  • Page 80: User Manual

    Connect 32 DR+ - Connect 55 User manual System settings Stations Manual search for cable analogue (analogue cable reception): Manual DVB-T/C/S search: Manual search is called. Manual search is called. Cable analogue has been selected as signal source. Manual scan (incl. antenna status)

  • Page 81: Station Lists Tv / Radio

    Connect 32 DR+ - Connect 55 User manual System settings Stations Station lists TV / Radio Move block / Change order Stations with LCN cannot be reordered. In this case, Under the menu item Station lists TV or Station lists Radio you the function Move block is hidden.

  • Page 82: Compose / Edit Personal List

    Connect 32 DR+ - Connect 55 User manual System settings Stations Compose / edit Personal list Adding stations to Personal list The Personal list must be opened to add new Each personal list can contain up to 99 stations. You can compose the stations to it.

  • Page 83: Update Station List Automatically

    Connect 32 DR+ - Connect 55 User manual System settings Stations Update station list automatically At once The station list will be immediately updated. Normally this occurs in the background without interfering Some programme providers offer an automatic update of the sta- further with the TV‘s operation.

  • Page 84: Control

    Connect 32 DR+ - Connect 55 User manual System settings Control Control more ... After confirmation with the OK key you will be offered additional not so frequently used sub items for the In the chapter Control you find settings for the various operating modes current menu item.

  • Page 85: Language

    Connect 32 DR+ - Connect 55 User manual System settings Control Language Specify the language for all menus in the TV set in the language menu. Calling EPG settings The language for the DVB subtitles and the film language can be set HOME: Call Home view.

  • Page 86: Parental Lock

    Connect 32 DR+ - Connect 55 User manual System settings Control Parental lock Explanations of setting possibilities in the Parental lock menu: Lock all The TV set is locked immediately the menu is exited. You can select and set various security options to prevent...

  • Page 87: Energy Efficiency

    Connect 32 DR+ - Connect 55 User manual System settings Control Energy efficiency Quick start mode Determine how energy efficient your TV set shall be. The value for If you enable the Quick Start Mode and you switch on the TV set from the contrast (and thus the brightness of the background lighting) standby, the TV picture can be immediately seen without delay.

  • Page 88: Software Update

    Software update USB stick - requirements USB sticks tested by Loewe and compatible in type and format can It is possible to update the software on your Loewe TV set. be ordered from the Loewe dealer using the article no. 90456.900.

  • Page 89: User Manual

    Connect 32 DR+ - Connect 55 User manual System settings Control Software update via USB storage device New software package found To do this, plug the USB stick with the downloaded software into a New software A new software version was found.

  • Page 90: User Manual

    Connect 32 DR+ - Connect 55 User manual System settings Control Manual update via the Internet New software package found If an Internet connection is available, new software can be downloaded New software directly and installed onto the TV set.

  • Page 91: User Manual

    Connect 32 DR+ - Connect 55 User manual System settings Control Software update via Antenna Load new software package Updating software A software update via antenna is only available for stations of the The "V1.1.14.0" software is currently being programmed, please wait ...

  • Page 92: User Manual

    Connect 32 DR+ - Connect 55 User manual System settings Control Automatic update via the internet At the end of the initial installation, Information on new software updates was selected. This item cannot be called up via the menu, but appears automatically when a new version is found in the search for software.

  • Page 93: On-Screen Displays

    Connect 32 DR+ - Connect 55 User manual System settings Control On-screen displays Time and date You can select different settings in this menu which affect the on- The time and date are normally acquired automatically by the TV screen displays.

  • Page 94: Dvb Settings

    Connect 32 DR+ - Connect 55 User manual System settings Control DVB settings You can make general pre-settings for DVB stations. Adjust size of the PIP image HOME: Call Home view. Calling DVB settings Mark System settings, HOME: Call Home view.

  • Page 95: User Manual

    With this, all the settings are activated to make all Mark DR+, Streaming the films on your DR+ archive available to other go to next column. LOEWE TVs using your home network (or vice-versa, e.g. allowing you to use the DR+ archive of other LOEWE TVs). Recording Recording You may set the pre-record and post-record times here.

  • Page 96: Standard Teletext

    Connect 32 DR+ - Connect 55 User manual System settings Control Call DR+ streaming settings Standard Teletext The DR+ settings are called (see previous page). In the Standard Teletext menu you can configure the Teletext. Mark DR+ Streaming, Call Teletext settings go to next column.

  • Page 97: Hbbtv

    Connect 32 DR+ - Connect 55 User manual System settings Control HbbTV WEB key function Here you can do all settings for the HbbTV mode. You can assign the Web key on the remote control unit a particular function (MediaNet, picture/sound menu, sound mode, etc.).

  • Page 98: Hard Disks

    Connect 32 DR+ - Connect 55 User manual System settings Control Hard disks Formatting the hard disk If problems were detected when the hard disk was being tested (see left column), re-formatting may be able to remedy the problem. Checking the hard disk...

  • Page 99: Export Log File

    IP address. All data will be deleted from our servers not later than 4 weeks. to the Loewe server and stored as soon as a problem More information can be found in our privacy policy. situation has occurred.

  • Page 100: Multimedia / Network

    Internet capabilities, e.g. computer, smartphone, etc. In this respect, Loewe guarantees that this data will not be personally exploited in any way. However, a statistical analysis of anonymised data records may be carried out.

  • Page 101: User Manual

    Connect 32 DR+ - Connect 55 User manual System settings Multimedia / Network Configuration of the built-in LAN adaptor Configuration of the built-in WLAN bridge adaptor As network operation was selected On, wired only. As network operation was selected On, wireless only.

  • Page 102: User Manual

    Connect 32 DR+ - Connect 55 User manual System settings Multimedia / Network Explanation of the settings in the network status: Proxy server In the proxy server wizard you make arrangements for your TV set for Network shows the current type of connection (wireless or a connection with a home network with proxy server.

  • Page 103: Multimedia Settings

    Connect 32 DR+ - Connect 55 User manual System settings Multimedia / Network Multimedia settings Renderer Here you can allow external devices to access your TV set (renderer) Under this menu item you find further settings for Audio, Video and via app to render (play back) contents there.

  • Page 104: Mobile Recording

    In the last step it is checked whether the email account is accessible If a record command is sent by the Loewe Assist Smart App, this with the set data. command reaches a connecting server.

  • Page 105: Connections

    Connect 32 DR+ - Connect 55 User manual System settings Connections Connections Settings for the connection of external appliances are made in this menu. The menu item Connections is not available while a timer record- ing is active. Calling the connections menu HOME: Call Home view.

  • Page 106: Sound Components

    Connect 32 DR+ - Connect 55 User manual System settings Connections Sound components Sound playback via ... Some sound components can only be selected when the respective The sound components wizard helps you to configure the components device is connected to the TV set.

  • Page 107: User Manual

    Connect 32 DR+ - Connect 55 User manual System settings Connections Adjusting the speaker system (AUDIO OUT) Subwoofer + ext. front speakers TV loudspeakers as centre speaker Sound playback via ... – Speaker system (AUDIO OUT) loudspeakers Please specify whether you want to use your...

  • Page 108: User Manual

    Connect 32 DR+ - Connect 55 User manual System settings Connections Adjusting the speaker system (DAL) Select the start value of the frequency response of the speakers for the correct setting (e.g., 50Hz for t h e s p e c i f i c a t i o n “ Fre q u e n c y re s p o n s e Sound playback via ...

  • Page 109: User Manual

    Connect 32 DR+ - Connect 55 User manual System settings Connections Connect Adjust Connect subwoofer Adjust speaker level subwoofer speaker level Please specify here whether you want to You hear a sound from every speaker one after Sound com- Sound com-...

  • Page 110: User Manual

    Connect 32 DR+ - Connect 55 User manual System settings Connections Adjusting the HiFi/AV amplifier Sound Sound formats formats Please specify, what kind of sound formats can be processed by your Sound com- HiFi/AV amplifier and mark them by the button ponents Sound playback via ...

  • Page 111: Antenna Dvb

    Connect 32 DR+ - Connect 55 User manual System settings Connections Antenna DVB AV connection settings Here you can make settings for the DVB-T antenna and call the antenna In the AV connection settings menu the parameters for the AV wizard for the DVB-S antenna.

  • Page 112: Digital Link

    Connect 32 DR+ - Connect 55 User manual System settings Connections Digital Link Gaming mode In the digital link menu you make further setting for comfortably linking For the inputs of your TV set on which game consoles, PC applications external devices to the TV set.

  • Page 113: Extras

    Mark Extras, By activating this function you can make your TV set Extras available to other LOEWE TVs that are set up for this for a Streaming go to next column. specified period of time (can be configured using the digital recorder menu item "System settings ->...

  • Page 114: Integrated Features

    Connect 32 DR+ - Connect 55 User manual System settings Extras Integrated features Reset to factory settings Here you can obtain information on the integrated features of the Here you can reset some of the settings to the factory default values.

  • Page 115: Conditional Access Module (Ca Module)

    TV set. They are usually available from Standard. CI Plus slots are in principle downward compatible to the your dealer. Loewe does not provide any guarantee for the functioning previous CI standard, i.e. CA modules and Smart Cards according to of the CA module.

  • Page 116: User Manual

    Connect 32 DR+ - Connect 55 User manual System settings Extras Searching for scrambled stations Station mapping If no search for encrypted stations was performed during initial startup, If two CA modules are both used for the decoding of stations, you this can be done later using the search wizard.

  • Page 117: External Devices

    Connect 32 DR+ - Connect 55 User manual External devices Devices to the HDMI connections Playback from the device If the device at HDMI supports the Digital Link HD functionality, the The HDMI connections (High Definition Multimedia Interface) allow TV set will automatically switch to the corresponding HDMI input after the transmission of digital video and audio signals from a player (e.g.

  • Page 118: Digital Link Hd

    Operation of Digital Link HD (HDMI CEC) enabled devices Switching the control via the TV key is only possible when no device The Digital Link HD (HDMI CEC) function allows Loewe television sets key is assigned to the HDMI device you are using.

  • Page 119: Devices On Av

    Switch off all devices before connecting them. The required adapters (Scart or VGA adapter) are available as an accessory from your Loewe dealer (see chapter Accessories). Connect the Scart output of the DVD player to the TV set’s AV socket using the Scart adaptor The AV sockets can process different signal types.
  • Page 120 Connect 32 DR+ - Connect 55 User manual External devices Connecting a DVD recorder to the TV set Connecting PC / Set-top box You can connect a PC and thus use the TV screen as a monitor. A DVD recorder has been selected in the System settings...

  • Page 121: Connecting The Speaker System (Audio Out)

    Connecting the speaker system (DAL) You can easily connect a speaker system using the AUDIO OUT You can easily connect a Loewe speaker system using the DIGITAL interface of your TV set. AUDIO LINK interface (DAL) of your TV set.

  • Page 122: Connecting Active Loudspeakers

    Center right Connect the HDMI1 socket of the TV using an HDMI cable with the HDMI socket of the ARC-compatible audio (pre) amplifier (e.g.Loewe Subwoofer MediaVision 3D). It is not necessary to log-in the amplifier separately with the TV set.

  • Page 123: Audio Playback From External Devices

    The IR Link function allows the operation of concealed additional to the AV inputs of the TV set. devices made by other manufacturers via the Loewe TV set. The remote control commands are passed from the IR receiver of Connecting an external appliance (e.g. MP3 player)

  • Page 124: Setting The Remote Control

    Setting the remote control Setting the remote control for other Loewe devices You can operate various Loewe devices with the remote control. The device keys STB – VIDEO – AUDIO can be reassigned to operate Using the remote control for the TV mode of the TV set different Loewe devices.

  • Page 125: Teaching The Remote Control

    Connect 32 DR+ - Connect 55 User manual Teaching the remote control Teaching the remote control Teaching individual keys All keys (except the TV, STB, VIDEO and AUDIO device keys as well By means of key code 18 (Set-Top Box data base) your remote control...
  • Page 126 Connect 32 DR+ - Connect 55 User manual Teaching the remote control Deleting individual key functions You can delete the taught function of an individual button. Press STB and green key simultaneously for five seconds. The LED above the STB key lights up perma- nently.

  • Page 127: Loewe Apps

    Start the Loewe App. The application will automatically search for compatible TV sets in the home network. A list of Loewe TVs will appear in the home network. The name of the TV set can be defined under System Settings Control more ...

  • Page 128: Smart Assist App

    The application will automatically search for compatible TV sets Add to my favourites: allows you to add the currently in the home network. A list of Loewe TVs will appear in the home selected entry (programme, archive entry, etc.) to your network.

  • Page 129: Troubleshooting

    Connect 32 DR+ - Connect 55 User manual Troubleshooting Problem Possible cause Remedy / Instructions The TV set switches off automatically. The automatic shutdown switches off the Using automatic shutdown is recommended TV set to save energy after 4 hours of for the purposes of energy saving and safety.
  • Page 130 Connect 32 DR+ - Connect 55 User manual Troubleshooting Problem Possible cause Remedy / Instructions Despite video or music file being played back, a) The TV set is set to mute or the volume has a) Increase the volume by pressing the V+ key no sound can be heard.

  • Page 131: Technical Data

    TV set is used. On-Mode (home) values less than 100 W must have decimal places (,0). Supplied mounting option: WM67 (Connect 55), Table Stand Connect 40/ 48 (Connect 40/ 48), Table Stand Connect 32 (Connect 32). For the playability of the individual formats no guarantee can be given.

  • Page 132: Signals Via Av (Pc In) / Hdmi

    Connect 32 DR+ - Connect 55 User manual Technical Data Signals via AV (PC IN) / HDMI Signal input groups The following table shows the compatible signals which may be In your TV set the signals are sorted in various signal input groups represented by your TV set using the appropriate adapter at the AV according to their source.

  • Page 133: Accessories

    Adapter Micro-AV / 25cm / Scart (part no. 72150080) set of 3: ponents. Numerous options for loudspeaker combinations can be The Loewe scart adaptor allows you to extend your TV set by adding realised with floor-standing loudspeakers, satellite loudspeakers and an AV socket to connect, e.g., DVD players or DVD recorders.

  • Page 134: Mounting Options

    Wall Mount Slim/ Vesa Size 100/200/300/400 Wall Mount WM 67 / WM 68 Wall Mount Isoflex 32-55 Connect 55: included in delivery (WM 67) Connect 55: 71363B00 Connect 55: 71361T20 (Vesa Size 400) Connect 48: 72115W80 (WM 67) Connect 48: 71363B00...

  • Page 135: Vesa Standard

    On the rear wall of the TV set, there are four points of screw connections to receive the VESA adapter bolts. Mounting a Loewe flat screen TV set to a holder according to the VESA standard necessarily requires the use of Loewe VESA adaptor bolts.

  • Page 136: Environment

    Dispose of your batteries at no charge in the the Free Software Foundation. collection containers which are set up for this pur- The publication of this programme by Loewe is carried out WITHOUT pose in retail stores. ANY GUARANTEE OR SUPPORT, particularly without an implicit guarantee concerning MARKET MATURITY or the USABILITY FOR A SPECIFIC PURPOSE.

  • Page 137: Miscellaneous

    Connect 32 DR+ - Connect 55 User manual Miscellaneous CA module error codes In case of problems with a CA module, error codes are displayed by TV set. The following table from the CI specification shows the meaning of the error codes.

  • Page 138: Glossary

    Digital Link HD: System for controlling units via the HDMI connection required in addition to the HDMI cable, redundant. of the Loewe TV set when they have been set up in a covered position. Automatic time control: Also called Accurate Recording. Similar to DMM: Abbreviation for Digital Movie Mode.
  • Page 139 Dynamic contrast ratio: Here the light intensity of the display is Loewe TV set. The infrared sensor required for this is available as an ac- adapted in case of a high black content in the picture. The so-called cessory and can be connected to the IR-Link connection of the TV set.
  • Page 140 Connect 32 DR+ - Connect 55 User manual Glossary Page Catching: For teletext, refers to marking and calling a page Terrestrial: In data transmission a wireless transmission that does not use satellites as intermediate station is referred to as terrestrial.

  • Page 141: Ec Declaration Of Conformity

    Connect 32 DR+ - Connect 55 User manual EC Declaration of Conformity Dieses Gerät entspricht den grundlegenden Anforderungen und den weiteren entsprechenden Vorgaben der Richtlinie 1999/5/ EG. Es darf in allen Ländern der EU sowie zusätzlich in Island, Norwegen und der Schweiz betrieben werden. In Frankreich und Italien ist die Nutzung nur in Innenräumen zulässig.

  • Page 142: Index

    Connect 32 DR+ - Connect 55 User manual Index Clear data base ................85 Clock display ..................18 3D ......................73 Code number .................. 86 3D function ..................74 Color intensity ..................72 Coloured keys .................. 39 Colour intensity ................73 Access code ..................86 Colour temperature ..............
  • Page 143 Connect 32 DR+ - Connect 55 User manual Index Edit new personal list ..............82 Language ..............19, 72, 85, 129 Edit personal list ................82 Licence agreement ................19 Energy efficiency ..............19, 72, 87 LNC/LNB ................24, 26, 27 Environment ...................136...
  • Page 144 Connect 32 DR+ - Connect 55 User manual Index Photo ...................31, 67 Smart Assist App ................128 Exit ....................68 Smart Card ..................115 Full-screen mode ................. 68 Smart jump ................57, 95 Rotate photo ................68 Smart tv2move App ..............127 Slide show ..................
  • Page 145 Connect 32 DR+ - Connect 55 User manual Index Update station list automatically ..........72, 77 UPnP ....................13 USB stick ..................88 Value-added service ..............8, 41 VBD+ ....................73 VESA standard ................135 Video ...................31, 55 VIDEO key ..................124 Video playback Change picture format ..............

  • Page 146: Service

    Connect 32 DR+ - Connect 55 User manual Service Nonplus Ultra Home Automation Pvt Ltd Gaplasa S.A. 3LOGIC Sp.z o.o. Qualifi Pty Ltd First Floor, No. 615, Second Main Road Conde de Torroja, 25 ul. Zakopiańska 153 24 Lionel Road Indiranagar Stage I, Indiranagar 28022 Madrid, España...

  • Page 147: Code Page

    Connect 32 DR+ - Connect 55 User manual Code page CONDOR 164, 226 LORENZEN 161, 162, 163, 164, 165, 186 CONNEXIONS 047, 096, 226, 231 GENIX LORRAINE BSAT 166, 169 CONRAD 006, 010, 164, 169, 226, 230 GENERAL-INSTRUMENTS LUPUS AEGIR...
  • Page 148 Connect 32 DR+ - Connect 55 User manual Code page OPTIMA SATMASTER 191, 205, 206, 211 OPTUS SATPARTNER 017, 079, 094, 133, 179, THORENS ORBIT 025, 194 180, 193, 201 THORN ORBITECH 006, 017, 103, 169, 181, 224 SATSTATION THORN-FERGUSON...

  • Page 149: Notes

    Connect 32 DR+ - Connect 55 User manual Notes...
  • Page 150 Connect 32 DR+ - Connect 55 User manual Notes...

This manual is also suitable for:

Connect 48Connect 32 dr+Connect 40Art 55Art 48Art 40

Table of Contents
