STAINLESS STEEL GAS GRILL MODEL NO.: 720-0061-LP ITEM NO: 57419 Jenn-Air is a Trademark of the Maytag Corporation and is used under license to Lowe’s Companies, Incorporated. FOR OUTDOOR USE ONLY PLEASE CONTACT 1-800-554-5799 FOR ASSISTANCE DO NOT RETURN TO PLACE OF PURCHASE...
TABLE OF CONTENTS SECTION ONE SECTION FIVE Safety Instructions………………………….. Exploded View……………………….….. Placement of the Grill………………………. Parts List ………………………………… SECTION TWO SECTION SIX Side Burner & Side Shelf Assembly……….. Grilling Hints …………………………….. Side Burner Lid & Handle Assembly………. Grill Cooking Chart ……………………… 20-22 Battery &...
PRECAUTIONS SAFETY INSTRUCTIONS USING THE SIDE BURNER WARNING Inspect the gas supply hose prior to turning on Do not attempt to light the grill if gas odor is the gas. If there is evidence of cuts, wear or present. Contact customer service at 1-800- abrasion, it must be replaced prior to use.
Page 4
SAFETY INSTRUCTIONS The grill is not intended to be installed in or on WARNING recreational vehicles and/or boats. Do not try lighting this appliance without first reading the “LIGHTING INSTRUCTIONS” section Children should not be left alone or unattended in of this manual.
Do not use briquettes of any kind in the grill. Clean the grill with caution. To avoid steam burns, The 720-0061-LP grill is designed for optimum do not use a wet sponge or cloth to clean the grill performance without the use of briquettes. Do not while it is hot.
SIDE BURNER & SIDE SHELF ASSEMBLY 1. Open the grill lid and remove the side burner from the fire box (Top drawing). 2. The screws used to attach the side shelf and side burner are already screwed into the side of the grill cart (Top drawing).
SIDE BURNER LID ASSEMBLY 1. Open the lid and cut the plastic tie. 2. Remove the screws from the handle and reinsert them through the side burner lid. 3. Tighten the screws. SIDE BURNER HANDLE ASSEMBLY 1. Remove the four handle screws from the side of the burner shelf. 2.
BATTERY ASSEMBLY 1. Remove the ignition button housing. 2. Insert the battery into the housing with the positive side facing outward. 3. Replace the ignition button housing after the battery has been installed. SPICE TRAY & BRAKE ASSEMBLY Press the black handle downward to lock the caster brake.
GAS HOLDER ASSEMBLY Secure the gas tank onto the slide tray with the retention kit screws. PROPANE TANK ASSEMBLY 1. Attach the regulator to the propane tank by turning the regulator handle clockwise. 2. Turn off the gas supply at the cylinder when the appliance is not in use.
GAS HOOK-UP Only the pressure regulator and hose assembly LP GAS HOOK-UP supplied with the grill should be used. Any Make sure the black plastic grommets on the LP replacement pressure regulator and hose assembly cylinder valve are in place and the hose does not must be specified by the grill manufacturer.
LEAK TESTING Only those parts recommended by the GENERAL Although gas connections on the grill are leak manufacturer should be used on the grill. tested prior to shipment, a complete gas tightness Substitutions will void the warranty. check must be performed at the installation site. Periodically check the whole system for leaks GAS FLOW CHECK following the procedures listed below.
WARNING Burner adjustments should only be performed after the burners have cooled. Always tighten the locking nut before relighting the burner. If the flames have yellow tips, loosen the locking nut and move the bolt in a clockwise direction. Locking Nut If the flames are making excessive noise or lifting, loosen the locking nut and turn the bolt in a counter-clockwise direction.
OPERATING INSTRUCTIONS GENERAL USE OF THE GRILL AND ROTISSERIE Each main burner is rated at 15,000 BTU/Hr. The After its first use, the stainless steel adjacent to the main grill burners encompass the entire cooking rotisserie burner will most likely turn dark blue. This area and are side ported to minimize blockage from is a normal property of the non-rusting type falling grease and debris.
NOTE Adjust the counter balance weight to balance the It is normal for the skewer to flex when larger cuts heavier side of the meat and avoid lopsided rotation of meat are being cooked. of the rotisserie motor. If the meat scrapes on the cooking grids during any CAUTION part of the rotation, the cooking grids must be When using the rotisserie burner, remove the...
TO MATCH LIGHT THE GRILL If the burner will not light after several attempts using the control knobs, the burner may be lit with a match. 1. If you have already attempted to light the burner with the igniter, allow 5 minutes for any accumulated gas to dissipate.
EASY LIGHTING ILLUSTRATIONS MAIN & SIDE BURNER LIGHTING ROTISSERIE BURNER LIGHTING 1. Open the top cover or lid. 1. Press and turn the rotisserie knob to the “ON” setting. 2. Press and turn one of the main or side 2. Press the electric igniter 3 to 4 seconds burner control knobs to the “HI”...
USING THE SIDE BURNER Inspect the gas supply hose prior to turning on 4. If the smell of gas is detected and the igniter the gas. If there is evidence of cuts, wear or is not functioning, immediately turn the control abrasion, it must be replaced prior to use.
CARE & MAINTENANCE OF THE GRILL STAINLESS STEEL GRILL BURNERS The grill is made of non-rusting and non- Extreme care should be taken when moving a magnetic stainless steel. There are many burner. It must be correctly centered on the stainless steel cleaners available.
TROUBLESHOOTING WHEN TO LOOK FOR SPIDERS You should inspect the burners at least twice a WARNING year or immediately after any of the following Spiders and insects can nest inside the burners conditions occur: of the grill and disrupt gas flow. This very dangerous condition could cause a fire behind 1.
PARTS LIST Model No. 720-0061-LP REF# DESCRIPTION REF# DESCRIPTION Lid, Front Gas Tank Tray Heat Indicator Gas Tank Screw Name Plate Front Door Heat Insulating spacer Door Handle Handle Assembly, Lid Slide Bracket Infrared Burner Lighting Rod Gas Collector Side Panel, Cart...
GRILLING HINTS The preparation of meat, whether rare, medium, To get the juiciest meat, add seasoning or salt or well done, is affected to a large degree by the after cooking is finished and turn the meat only thickness of the cut. once during cooking.
Page 23
FOOD WEIGHT FLAME APPROXIMATE SPECIAL OR THICKNESS SIZE TIME INSTRUCTIONS AND TIPS MEATS BEEF Hamburgers 1/2 to 3/4 inch Medium 10 to 18 minutes Grill, turning once when juices rise to the surface. Do not leave hamburgers unattended. A flare-up could occur quickly.
Page 24
FOOD WEIGHT FLAME APPROXIMATE SPECIAL OR THICKNESS SIZE TIME INSTRUCTIONS AND TIPS Breasts Medium 30 to 45 minutes Marinate with Italian dressing well-done FISH AND SEAFOOD Steaks Grill, turning once. Brush with Halibut 3/4 to 1 inch Medium to 8 to 15 minutes Melted butter, margarine or oil Salmon High...
GRILL RECIPES BBQ SALMON Half-hour before cooking, turn the 1tsp. Worcestershire sauce 2 large salmon steaks burner to the grill on high. Drain 1tsp. Dry mustard 2 tbs. oil seafood-reserving marinade. On each ¼ tsp. Thyme, crushed Salt & pepper of twelve 10”...
Page 26
heat tortillas on grill. Slice meat across CHICKEN TANDOORI STYLE 2 oz. lemon juice grain in thin slices. Place on hot platter. 8 large chicken thighs or drumsticks 10 lbs. pork roast Squeeze lemon juice over. Wrap meat and 1 c. plain nonfat yogurt any of the following toppings in tortillas: ½...
Saturday. Our telephone number is 1-800-554-5799, fax number 1-800-598-8829. Please direct all correspondence to: Nexgrill Industries, Inc. 280 Machlin Court, City of Industry, California, 91789, ATTN: Warranty Service Center. *Jenn-Air is a trademark of the Maytag Corporation and is used under license to Lowe’s Company Inc. Printed In China...
