STAINLESS STEEL LP GAS GRILL
MODEL NO.: 720-0337
Jenn-Air is a Trademark of the Maytag Corporation and is used under license to Lowe's Companies, Incorporated.
FOR OUTDOOR USE ONLY
PLEASE CONTACT 1-800-554-5799 FOR ASSISTANCE
DO NOT RETURN TO PLACE OF PURCHASE
ITEM NO: 242610
300
400
5 00
6 00
20 0
100
800
700
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 720-0337 and is the answer not in the manual?

Questions and answers

Related Manuals for Jenn-Air 720-0337

Summary of Contents for Jenn-Air 720-0337

  • Page 1 STAINLESS STEEL LP GAS GRILL MODEL NO.: 720-0337 ITEM NO: 242610 Jenn-Air is a Trademark of the Maytag Corporation and is used under license to Lowe’s Companies, Incorporated. ® 5 00 6 00 20 0 FOR OUTDOOR USE ONLY PLEASE CONTACT 1-800-554-5799 FOR ASSISTANCE...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SECTION ONE SECTION FIVE Safety Instructions Exploded View Placement of the Grill Parts List 26-27 SECTION TWO SECTION SIX Side Shelf & Side Burner Assembly Grilling Hints Spice Tray Assembly Grill Cooking Chart 28-30 Side Burner Hose Quick-Connect Assembly Grill Recipe Suggestions 31-32 Side Shelf Handle &...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS RECOGNIZED SAFETY SYMBOLS, WORDS AND LABELS WARNING WARNING Do not try lighting this appliance without first reading the “LIGHTING INSTRUCTIONS” section of this manual. WARNING – Hazards or unsafe practices which COULD result in severe personal injury or death. WARNING Spiders and insects can nest inside the burners of CAUTION...
  • Page 4 SAFETY INSTRUCTIONS WARNING WARNING Do not use the grill if the odor of gas is Failure to properly place the burner over the present. Contact customer service at 1-800- orifice could cause a fire to occur behind and 554-5799. beneath the valve panel, thereby damaging the grill and making it unsafe to operate.
  • Page 5 SAFETY INSTRUCTIONS USING THE SIDE BURNER WARNING I nspect the gas supply hose prior to turning on Do not attempt to light the grill if gas odor is the gas. If there is evidence of cuts, wear or present. Contact customer service at 1-800-554- abrasion, it must be replaced prior to use.
  • Page 6 SAFETY INSTRUCTIONS WARNING The grill is not intended to be installed in or on Do not try lighting this appliance without first reading recreational vehicles and/or boats. the “LIGHTING INSTRUCTIONS” section of this manual. Children should not be left alone or unattended in an area where the grill is being used.

  • Page 7: Placement Of The Grill

    Do not use briquettes of any kind in the grill. Clean the grill with caution. To avoid steam burns, The 720-0337 liquid propane gas grill is designed do not use a wet sponge or cloth to clean the grill for optimum performance without the use of while it is hot.
  • Page 8 SIDE SHELF ASSEMBLY Estimated Assembly Time: Approximately 10 minutes Required Tools: Phillips Screwdriver (not included) 1. Open the grill lid and remove the side shelf from the fire box. 2. The screws used to attach the side shelf are already screwed into the side of the grill cart. Remove the screws from the side panels.

  • Page 9: Spice Tray Assembly

    SPICE TRAY ASSEMBLY Mount the tabs on the spice tray into the holes on the left door of the grill.

  • Page 10: Side Burner Hose Quick-Connect Assembly

    SIDE BURNER HOSE QUICK-CONNECT ASSEMBLY Estimated Assembly Time: Approximately 5 minutes Required Tools: Phillips Screwdriver 1. Insert the side burner hose with female sleeve through side panel of cart (Top drawing). 2. Push the sleeve of the female socket back and insert the male end of the connector. Release the sleeve.
  • Page 11 SIDE SHELF HANDLE ASSEMBLY Estimated Assembly Time: Approximately 5-7 minutes Required Tools: Phillips Screwdriver (not included) 1. Remove the four side shelf handle screws from the side of the shelf. 2. Align the holes in the side shelf handle with the holes in the shelf. 3.

  • Page 12: Cylinder Retention System

    BRAKING SYSTEM OPERATIONS 1. Push to the right to lock. 2. Push to the left to unlock. 7 00 LIQUID PROPANE CYLINDER RETENTION SYSTEM 1. Attach the liquid propane gas cylinder to the slide-out tray using the gas cylinder retention screw. Turn the retention screw clockwise to tighten the gas cylinder.

  • Page 13: Hook-Up

    SLIDE-OUT TRAY LOCKING SYSTEM 1. To lock and unlock the liquid propane gas cylinder tray, press the gas cylinder tray’s top button to lock (A). Press the side button to unlock (B). PROPANE REGULATOR HOOK-UP Attach the regulator to the propane cylinder by turning the regulator handle clockwise. If the outdoor cooking appliance is not in use, the gas must be turn off at the supply cylinder.

  • Page 14: Gas Hook Up

    Remove plastic valve cover from the liquid propane cylinder. Make sure the grill gas hoses do not Total gas consumption (per hour) of the 720-0337 contact the grease tray or grill firebox when the liquid propane gas grill with all burners set on “HI”: liquid propane cylinder is pushed into the cart.

  • Page 15: Leak Testing

    3. Detach the regulator assembly from the 4. Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust tank valve by turning the quick coupling nut counterclockwise. cap on the cylinder valve outlet that is provided with the cylinder valve.

  • Page 16: Installer Final Check

    INSTALLER FINAL CHECK The unit has been tested and is free of leaks. Specified clearance maintained 24 inches from The gas supply shut off valve has been located. combustible materials/construction. All burners are factory installed. All internal packaging has been removed. Keep the instruction manual with the grill for The hose and regulator are properly connected.

  • Page 17: Operating Instructions

    OPERATING INSTRUCTIONS GENERAL USE OF THE GRILL AND ROTISSERIE Each main burner is rated at 13,000 BTU/Hr. The local codes, with the National Electrical Code, main grill burners encompass the entire cooking ANSI/NFPA 70. area and are side ported to minimize blockage from After its first use, the stainless steel adjacent to the falling grease and debris.

  • Page 18: Lighting Instructions

    Adjust the counter balance weight to balance the heavier side of the meat and avoid lopsided rotation NOTE of the rotisserie motor. It is normal for the skewer to flex when larger cuts of meat are being cooked. CAUTION When using the rotisserie burner, remove the If the meat scrapes on the cooking grids during any warming rack.
  • Page 19 Keep a spray bottle of soapy water near the gas supply valve and check the connections before each use.

  • Page 20: Lighting Illustrations

    LIGHTING ILLUSTRATIONS MAIN BURNER LIGHTING ROTISSERIE BURNER & SEARING SIED BURNER LIGHTING 1. Push and turn rear burner knob slowly to “IGNITE / ON” setting, hold in until th 1. Open the top cover or lid. burner is lit up, continue to press and hold for 15 seconds and release.

  • Page 21: To Match Light The Grill

    TO MATCH LIGHT THE GRILL If the burner will not light after several attempts using the control knobs, the burner may be lit with a match. 1. If you have already attempted to light the burner with the igniter, allow 5 minutes for any accumulated gas to dissipate.

  • Page 22: Grill Lights

    GRILL LIGHTS Light Operation Instruction 1. Make sure light’s power switch on the control panel is in the “OFF” position. 2. Connect power plug to properly grounded outlet. 3. Turn the light’s power switch to “ON”. WARNING Keep any electrical supply cord away from any heated surface.
  • Page 23 5. Use a screwdriver to loosen the two screws locking the bulb. Pull out the light bulb and replace with a new bulb. 6. Reverse the instruction from steps 5-1 for installation. Cleaning Method Follow steps 1-4 above for glass cover removal. Use a damp towel to clean the surface of glass cover.

  • Page 24: Using The Side Burner

    USING THE SIDE BURNER Inspect the gas supply hose prior to turning on the 4. If the smell of gas is detected and the igniter is gas. If there is evidence of cuts, wear or abrasion, it not functioning, immediately turn the control must be replaced prior to use.

  • Page 25: Care And Maintenance Of Side Burner

    CARE & MAINTENANCE OF SIDE BURNER BURNER CLEANING STAINLESS STEEL Clean the exterior of the burner with a wire brush. There are many stainless steel cleaners Clear any clogged burner ports with a straightened available. Always use the mildest cleaning paper clip.
  • Page 26 CARE & MAINTENANCE OF THE GRILL STAINLESS STEEL Grease specks can gather and bake onto the WARNING surfaces of the stainless steel, giving the Failure to properly place the burner over the orifice appearance of rust. For removal, use an abrasive could cause a fire to occur behind and beneath the pad with a stainless steel cleaner.

  • Page 27: Troubleshooting

    TROUBLESHOOTING WHEN TO LOOK FOR SPIDERS You should inspect the burners at least twice a WARNING year or immediately after any of the following Spiders and insects can nest inside the burners conditions occur: of the grill and disrupt gas flow. This very dangerous condition could cause a fire behind 1.

  • Page 28: Exploded View

    EXPLODED VIEW MODEL 720-0337 46( A) 46( B) 46( D ) 46( C )

  • Page 29: Parts List

    PARTS LIST Model No. 720-0337 REF# DESCRIPTION REF# DESCRIPTION Main Lid Front Trim Panel, Left Temperature Gauge Front Door, Left Logo Door Handle Temperature Gauge Heat Insulating Front Door, Right Spacer Main Lid Handle Heat Insulating Cover Front Trim Panel, Right...
  • Page 30 REF# DESCRIPTION REF# DESCRIPTION Side Burner Grease Tray Foot Brake Side Burner Orifice Brass Connector Wheel Axle Side Burner Flex Gas Axletree Base Side Burner Gas Valve Wheel Side Burner Control Panel Tank Bolt Sear Burner Igniter Wire Lighting Rod Side Panel, Right Lighting Rod Cover Gas Hose Retention Clamp...

  • Page 31: Grilling Hints

    GRILLING HINTS This Jenn-Air grill has an infrared side burner – It is recommended that meat be defrosted overnight commonly referred to as a “searing” burner. This in the refrigerator as opposed to a microwave. This type of burner produces extreme heat that can be generally yields a juicier cut of meat.
  • Page 32 FOOD WEIGHT FLAME APPROXIMATE SPECIAL OR THICKNESS SIZE TIME INSTRUCTIONS AND TIPS MEATS BEEF Hamburgers 1/2 to 3/4 inch Medium 10 to 18 minutes Grill, turning once when juices rise to the surface. Do not leave hamburgers unattended. A flare-up could occur quickly.
  • Page 33 FOOD WEIGHT FLAME APPROXIMATE SPECIAL OR THICKNESS SIZE TIME INSTRUCTIONS AND TIPS Breasts Medium 30 to 45 minutes Marinate with Italian dressing well-done FISH AND SEAFOOD Steaks Grill, turning once. Brush with Halibut 3/4 to 1 inch Medium to 8 to 15 minutes Melted butter, margarine or oil Salmon High...
  • Page 34 GRILL RECIPES BBQ SALMON Half-hour before cooking, turn the 1tsp. Worcestershire sauce 2 large salmon steaks burner to the grill on high. Drain 1tsp. Dry mustard 2 tbs. oil seafood-reserving marinade. On each ¼ tsp. Thyme, crushed Salt & pepper of twelve 10”...
  • Page 35 heat tortillas on grill. Slice meat across CHICKEN TANDOORI STYLE 2 oz. lemon juice grain in thin slices. Place on hot platter. 8 large chicken thighs or drumsticks 10 lbs. pork roast Squeeze lemon juice over. Wrap meat and 1 c. plain nonfat yogurt any of the following toppings in tortillas: ½...

  • Page 36: Limited Warranty

    Our telephone number is 1-800-554-5799, fax number 1-800-598-8829. Please direct all correspondence to: Nexgrill Industries, Inc. 280 Machlin Court, City of Industry, California, 91789, ATTN: Warranty Service Center. *Jenn-Air is a trademark of the Maytag Corporation and is used under license to Lowe’s Company Inc. Printed in China...
