R2100
A S S E M B L Y I N S T R U C T I O N S
To avoid possible damage to this Fitness Cycle,
please follow these assembly instructions.
Carefully remove all its parts from the box,
lay them out and review the parts list.
If any parts are missing, please call 1-800-335-4348, Ext 12
Before proceeding, find your Fitness Cycle's serial number,
located on the underside of main frame, and enter here:
______________________________
Refer to this number when calling for service.
I T
A L L
S T A R T S
W I T H
A
V I S I O N

Advertisement

Table of Contents
loading

Summary of Contents for Vision Fitness R2100

  • Page 1 R2100 A S S E M B L Y I N S T R U C T I O N S To avoid possible damage to this Fitness Cycle, please follow these assembly instructions. Carefully remove all its parts from the box, lay them out and review the parts list.
  • Page 2 R2100 Parts Diag ram...
  • Page 3 R2100 Parts VISION FITNESS R2100 Parts Description Part # Description Count Dimensions Front Wheel Parts #148 Front Foot Wheel Axle #149 Front Transport Wheels #150 Inside Wheel Washers #185 Outside Wheel Washers #182 Wheel Attachment Bolts 20mm L x 8mm D...
  • Page 4: Step 1 • Front Wheel Assembly

    R2100 Assembly NOTE: During each assembly step, ensure that ALL nuts and bolts are in place and partially threaded in before completely tightening any ONE bolt. Step 1 • Front Wheel Assembly 1: Slide the Front Foot Axle (148) through the Front Foot Nylon Sleeves (147).
  • Page 5: Step 3 • Seat Assembly

    R2100 Assembly Step 3 • Seat Assembly 1: Secure the Seat Mount Handlebars (110) to the Seat Frame (115) with four Seat Mount Handlebar Bolts (182) and four washers (156). 2: When mounting the Seat Cushion Bottom (136), you have two sets of holes to choose from. Using the rear set of holes is recommended for most people.
  • Page 6: Step 6 • Console Mast

    R2100 Assembly Step 5 • Pedals 1: Identify the left and right Pedals (152) and the left and right Pedal Straps (199). Attach the correct straps to each pedal, then thread each Pedal into the correct left and right crank arms and tighten.
  • Page 7: Step 8 • Cable Connection

    R2100 Final Assembly Step 7 • Console 1: Insert Upper Magnet Shift Cable (220) into the top of the Console mast (101). 2: Mount the Console (153) to the Console Mast (101) using the six Console Attachment Bolts (197). Make sure you DO NOT PINCH the Upper Magnet Shift Cable (220) and RPM Sensor Wire (64) between the Console (153) and Console Mast (101).
  • Page 8 621-D East Lake Street P.O. Box 280 Lake Mills, WI 53551 (920) 648-4090...
