OWNER'S MANUAL
KAY-CF 26 DN7
KAY-CF 35 DN7
KAY-CF 52 DN7
IMPORTANT NOTE:
Read this manual carefully before installing or operating your new air conditioning unit. Make
sure to save this manual for future reference.
Casual CF Series
KAY-CF 71 DN7
KAY-CF 26 DR8
KAY-CF 35 DR8
KAY-CF 52 DR8
KAY-CF 71 DR8
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigicoll Kaysun Casual CF Series
Summary of Contents for Frigicoll Kaysun Casual CF Series
- Page 1 OWNER’S MANUAL Casual CF Series KAY-CF 26 DN7 KAY-CF 71 DN7 KAY-CF 52 DR8 KAY-CF 35 DN7 KAY-CF 26 DR8 KAY-CF 71 DR8 KAY-CF 52 DN7 KAY-CF 35 DR8 IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.
- Page 2 Table of Contents Owner’s Manual Safety Precautions ........Unit Specifications and Features ....SAFETY FIRST 2 Manual Operation (Without Remote) ..
- Page 3 Care and Maintenance ........Troubleshooting ..........European Disposal Guidelines ......Caution: Risk of fire/ flammable materials (For R-32 units only) WARNING: Servicing shall only be performed as recommended by the equipment manufacturer. Maintenance and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of theperson competent in the use of flammable refrigerants.
- Page 4 Safety Precautions Read Safety Precautions Before Installation Incorrect installation due to ignoring instructions can cause serious damage or injury. The seriousness of potential damage or injuries is classified as either a WARNING or CAUTION. This symbol indicates that ignoring instructions may cause serious injury. WARNING This symbol indicates that ignoring instructions may cause moderate injury to your person, or damage to your appliance or other property.
- Page 5 ELECTRICAL WARNINGS Only use the specified power cord. If the power cord is damaged, it must be replaced by the • manufacturer or certified service agent. Keep power plug clean. Remove any dust or grime that accumulates on or around the plug. Dirty •...
- Page 6 Unit Specifications and Features Unit Parts Front Panel Power Cable (Some Units) Remote Control Remote Control Holder (Some Units) Louver Display window(A) Display window(C) Display window(D) Display window(C) fresh defrost run timer fresh defrost run timer “ fresh ” when Fresh feature is activated (some units) “...
- Page 7 the infrared remote is not included in this literature package.
- Page 8 Achieving Optimal Performance Optimal performance for the COOL, HEAT, and DRY modes can be achieved in the following temperature ranges. When your air conditioner is used outside of these ranges, certain safety protection features will activate and cause the unit to perform less than optimally. Inverter Split Type COOL mode HEAT mode...
- Page 9 • Wireless Control (some units) For a detailed explanation of each function, Wireless control allows you to control refer to the Remote-Control Manual. your air conditioner using your mobile phone and a Wireless connection. device access, Other Features replacement, maintenance •...
- Page 10 Setting Angle of Air Flow • Setting vertical angle of air flow While the unit is on, use the SWING/DIRECT button to set the direction (vertical angle) of airflow. Press the SWING/DIRECT button once to activate the louver. Each time you press the button, it will adjust the louver by 6°.
- Page 11 Sleep Operation • The SLEEP function is used to decrease energy use while you sleep (and don’t need the same temperature settings to stay comfortable). This function can only be activated via remote control. Press the SLEEP button when you are ready to go to sleep.
- Page 12 Manual Operation (Without Remote) How to operate your unit without CAUTION the remote control The manual button is intended for testing If your remote control fails to work, your unit can purposes and emergency operation only. Please be operated manually with the MANUAL do not use this function unless the remote control CONTROL button located on the indoor unit.
- Page 13 Care and Maintenance Rinse the filter with fresh water, then shake Cleaning Your Indoor Unit off excess water. BEFORE CLEANING OR Dry it in a cool, dry place, and refrain from exposing it to direct sunlight. MAINTENANCE When dry, re-clip the air freshening filter to ALWAYS TURN OFF YOUR AIR CONDITIONER the larger filter, then slide it back into the SYSTEM AND DISCONNECT ITS POWER SUPPLY...
- Page 14 Maintenance – CAUTION Long Periods of Non-Use • If you plan not to use your air conditioner for an extended period of time, do the following: • • • Turn on FAN function until Clean all filters unit dries out completely Air Filter Reminders (Optional) Air Filter Cleaning Reminder After 240 hours of use, the display window on...
- Page 15 After long periods of non-use, or before periods frequent use, following: Check for leaks Replace batteries Check for damaged wires Clean all filters Make sure nothing is blocking all air inlets and outlets...
- Page 16 SAFETY PRECAUTIONS If ANY of the following conditions occurs, turn off your unit immediately! The power cord is damaged or abnormally warm • You smell a burning odor • The unit emits loud or abnormal sounds • A power fuse blows or the circuit breaker frequently trips •...
- Page 17 Issue Possible Causes A rushing air sound may occur when the louver resets its position. The indoor unit makes noises A squeaking sound may occur after running the unit in HEAT mode due to expansion and contraction of the unit’s plastic parts.
- Page 18 Troubleshooting When troubles occur, please check the following points before contacting a repair company. Problem Possible Causes Solution Temperature setting may be higher than ambient Lower the temperature setting room temperature The heat exchanger on the indoor or outdoor unit is Clean the affected heat exchanger dirty Remove the filter and clean it...
- Page 19 Problem Possible Causes Solution Wait for the power to be Power failure restored The power is turned off Turn on the power The fuse is burned out Replace the fuse The unit is not working Remote control batteries are Replace batteries dead The Unit’s 3-minute protection Wait three minutes after...
- Page 20 This appliance contains refrigerant and other potentially hazardous materials. When disposing of this appliance, the law requires special collection and treatment. Do not dispose of this product as household waste or unsorted municipal waste. When disposing of this appliance, you have the following options: •...
- Page 21 The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. CS78421-548-754 CS372U-AF 16122000002735 20171009...
