INSTALLATION MANUAL
Ceiling and Floor Type
Digital Scroll and DC/AC Inverter Commercial Air-conditioner
KSEF-56 DN2.3
KS(E)F-56 DN2.3
KS(E)F-80DN2.3
The Digital Scroll and DC/AC Inverter share the same indoor units.
Thank you very much for purchasing our air conditioner. Before using your air conditioner, please
read this manual carefully and keep it for future reference.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Frigicoll Kaysun KSEF-56 DN2.3
Summary of Contents for Frigicoll Kaysun KSEF-56 DN2.3
- Page 1 INSTALLATION MANUAL Ceiling and Floor Type Digital Scroll and DC/AC Inverter Commercial Air-conditioner KSEF-56 DN2.3 KS(E)F-56 DN2.3 KS(E)F-80DN2.3 The Digital Scroll and DC/AC Inverter share the same indoor units. Thank you very much for purchasing our air conditioner. Before using your air conditioner, please read this manual carefully and keep it for future reference.
-
Page 3: Table Of Contents
When installing the unit in a small room, take measures CONTENTS PAGE against to keep refrigerant concentration from exceeding allowable safety limits in the event of refrigerant leakage. Contact the place of purchase for more information. Precautions..............1 Excessive refrigerant in a closed ambient can lead to oxygen deficiency. -
Page 4: Installation Information
Don't install the air conditioner in the following locations: The temperature of refrigerant circuit will be high, please keep the interconnection cable away from the copper tube. There is petrolatum existing. There is salty air surrounding (near the coast). After completing the installation work, check that the refrigerant does not leak. -
Page 5: Attached Fittings
3. ATTACHED FITTINGS CAUTION Please check whether the following fittings are of full scope. If there are some spare fittings, please restore them carefully. Never throw or beat the controller. Outline Usage Before installation, operate the remote controller to Nam e of Accessories determine its location in a reception range. - Page 6 Version II Table.4-1 Vertical unit with casing, with air intake from below and air outlet Ve rsio n on top, for installation on a wall or on feet on the floor. Ve rsio n I Ve rsio n II Ve rsio n III a ( m m ) ≥1 5 0 ≥1 5 0...
- Page 7 4.2 Version I Installation For installation, follow the instructions set out below: Remove the external casing, unscrewing the screws which secure it to the structure, as following indicated. Fig.4-13 Connecting point of refrigerant pipe (Liquid side Connecting point of Fig.4-10 refrigerant pipe (Gas side Fig.4-14...
-
Page 8: Install The Connecting Pipe
5. INSTALL THE CONNECTING PIPE Put the unit onto the feet, and fix it by screws. CAUTION Do not let air, dust, or other impurities fall in the pipe system during the time of installation. The connecting pipe should not be installed until the indoor and outdoor units have been fixed already. -
Page 9: Connect The Drain Pipe
Bend the pipe with thumb Bend Fig. 5-2 Fig. 6-2 Min-radius 100mm Fold Put as deep as possible (about 10cm) Make the ends straight Fig. 5-3 Downward declivity 2. Locate the Pipe V P 30 lower than 1/100 1) Drill a hole in the wall (suitable just for the size of the wall conduit, 90mm in general), then set on the fittings such as the wall Fig. - Page 10 7.5 Terminal Board Diagram 7.1 The specification of power Please refer to the indoor unit wiring diagram for the wiring. Table.7-1 Note: The air-conditioners can connect with Central Control Monitor (CCM). Before operation, please wiring correctly and 2.2-8.0 TYPE (kW) set system address and network address of indoor units.
- Page 11 7.8 Network address set CAUTION 1) Network address is set by communication of indoor and outdoor unit; the address is the same as indoor address, The system together have 64units (0-63), everyone has there is no need to set separately. only system address code, If two addresses are the same in 2) The central control of indoor units can be done on outdoor one system, the abnormal operation will occur.
-
Page 12: Trouble Shooting
Definition Definition 1 means old display panel Standard configure 0 means new display panel 1 means auto wind under auto mode 0 means auto wind under non auto mode Last one in the network reserved 8. TROUBLE SHOOTING Definition J1 no Jumpers means power off memory function J1 Jumpers means no power Timer lamp... -
Page 13: Test Operation
9. TEST OPERATION The test operation must be carried out after the entire installation has been completed. Please confirm the following points before the test operation: The indoor unit and outdoor unit are installed properly. Tubing and wiring are correctly completed. The refrigerant pipe system is leakage-checked.
