OWNER'S & INSTALLATION

MANUAL

Duct

KPDA-35 DVR15

KPDA-26 DVR15

IMPORTANT NOTE:

Read this manual and SAFETY MANUAL(if any) carefully before installing or

operating your appliance. Make sure to save this manual for future reference.

Table of Contents

Need help?

Do you have a question about the Kaysun KPDA-35 DVR15 and is the answer not in the manual?

Questions and answers

Summary of Contents for Frigicoll Kaysun KPDA-35 DVR15

Page 1 OWNER'S & INSTALLATION MANUAL Duct KPDA-35 DVR15 KPDA-26 DVR15 IMPORTANT NOTE: Read this manual and SAFETY MANUAL(if any) carefully before installing or operating your appliance. Make sure to save this manual for future reference.
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY PRECAUTIONS TROUBLESHOOTING PRODUCTION INSTALLATION PRODUCT OVERVIEW REFRIGERANT PIPING CONNECTION WIRING PRECAUTIONS AIR EVACUATION NOTE ON ADDING REFRIGERANT TEST RUN PACKING AND UNPACKING THE UNIT Read this manual Inside you’ll ﬁnd many helpful hints on how to use and maintain your air conditioner properly. Just a little preventive care on your part can save you a great deal of time and money over the life of your air conditioner.
Page 3: Safety Precautions
SAFETY PRECAUTIONS Intended Use The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. Please check the packaging and appliance on arrival to make sure everything is intact to ensure safe operation. If you ﬁnd any damage, please contact the retailer or dealer.
Page 4 WARNINGS FOR PRODUCT USE If an abnormal situation arises (like a burning smell), immediately turn o the unit • and disconnect the power. Call your dealer for instructions to avoid electric shock, ﬁre or injury. Do not insert ﬁngers, rods or other objects into the air inlet or outlet. This may •...
Page 5 ELECTRICAL WARNINGS • Only use the speciﬁed power cord. If the power cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualiﬁed persons in order to avoid a hazard. • The product must be properly grounded at the time of installation, or electrical shock may occur.
Page 6 • Do not turn on the power until all work has been completed. • When moving or relocating the air conditioner, consult experienced service technicians for disconnection and reinstallation of the unit. How to install the appliance to its support, please read the information for •...
Page 7 (1)IEC Standard Requirements (Only applicable to IEC 60335-2-40: 2018). Ceiling-mounted Wall-mounted m (kg) m (kg) ≤2.503 ≤ 2.048 2.503 m 4.28 2.048 m 4.58 2.6 m 2.2 m 5.45 4.97 2.8 m 5.70 2.4 m 6.40 3.0 m 6.49 2.6 m 7.42 3.2 m 7.32...
Page 8 Reusable mechanical connectors and ﬂared joints are not allowed indoors • (EN Standard Requirements). Mechanical connectors used indoors shall have a rate of not more than 3g/year • at 25% of the maximum allowable pressure. When mechanical connectors are reused indoors, sealing parts shall be renewed. When ﬂared joints are reused indoors,the ﬂare part shall be re-fabricated.(UL Standard Requirements) When mechanical connectors are reused indoors, sealing parts shall be renewed.
Page 9 CARE AND MAINTENANCE CAUTION Cleaning Your Indoor Unit • Always TURN OFF your AC system and disconnect its power supply before cleaning or maintenance. • Only use a soft, dry cloth to wipe the unit clean. You can use a cloth soaked in warm water to wipe it clean if the unit is especially dirty.
Page 10: Troubleshooting
TROUBLESHOOTING CAUTION If any of the following conditions occurs, turn o your unit immediately! • The power cord is damaged or abnormally warm • You smell a burning odor • The unit emits loud or abnormal sounds • A power fuse blows or the circuit breaker frequently trips •...
Page 11 Issue Possible Causes The outdoor unit The unit will make different sounds based on its current operating mode. makes noises Dust is emitted from The unit may accumulate dust during extended periods of non-use, which will be either the indoor or emitted when the unit is turned on.
Page 12 Problem Possible Causes Solution Wait for the power to be restored Power failure The power is turned off Turn on the power The unit is not Contact a professional technician directly to repair The fuse is burned out the fuse working Remote control batteries are dead Replace batteries...
Page 13 Troubleshoot Your Wireless Remote Control Problem Possible Causes Solution In AUTO mode, the fan speed is Check whether AUTO set automatically and cannot be mode is selected. changed. The fan speed cannot be changed. In DRY mode, the FAN SPEED Check whether DRY button is ineffective.
Page 14: Production Installation 1
PRODUCTION INSTALLATION ACCESSORIES The air conditioner comes with the following accessories. Use all of the installation parts and accessories to install the air conditioner. Improper installation may result in water leakage, electrical shock and ﬁre, or cause the equipment to fail. The items are not included with the air conditioner must be purchased separately.
Page 15 MANUAL button: This button selects the mode in the following order:AUTO, FORCED COOL, OFF. FORCED COOL mode: In FORCED COOL mode, the Operation light ﬂashes. The system will then turn to AUTO after it has cooled with a high wind speed for 30 minutes. The remote control will be disabled during this operation.
Page 16 INSTALLATION SUMMARY Install the indoor unit Install the drainpipe Install the outdoor unit L(L1) N(L2) Evacuate the Connect the wires Connect the refrigerant refrigeration system pipes Perform a test run...
Page 17: Product Overview 1
PRODUCT OVERVIEW NOTE ON ILLUSTRATIONS: Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit may be slightly di erent. The actual shape shall prevail. The installation must be performed in accordance with the requirement of local and national standards.
Page 18 Install the Indoor Unit Select installation location NOTE Before installing the indoor unit, you must choose an appropriate location. The following are standards that will help you choose an appropriate location for the unit. Proper installation locations meet the following standards: Enough room exists for the There is no direct radiation Enough room exists for...
Page 19 Conﬁrm sizes installation Installation place The distance between the mounted indoor unit should meet the speciﬁcations illlustrated in the following diagram. >11.8in(30cm) Strong and durable ceiling >0.8in(2cm) Indoor unit Left Right side side >0.8in(2cm) Service access Ceiling >7.9in(20cm) >11.8in(30cm) Floor Maintenance space Air outlet ≥11.8in(30cm)
Page 20 Hang indoor unit 3.1. Please refer to the following diagrams to locate the four positioning screw bolt holes on the ceiling. Be sure to mark the paces where you will drill ceiling hook holes. Air outlet dimensions Air inlet dimensions Air ﬁlter Descending ventilation opening and mounted hook Air ﬁlter...
Page 21 3.2 Ceiling Bolt Installation Guidelines 2. Install and ﬁt pipes and wires after you have ﬁnished installing the main body.When 1) Wood choosing where to start, determine the The mounting holes for upper foam are used for direction of the pipes to be drawn out. auxiliary positioning bolts (if the foam is damaged, Especially in cases where there is a ceiling the spacing between the actual lifting lugs shall be...
Page 22 Duct and accessories installation 1. Install the ﬁlter (optional) according to the size NOTE: of the air inlet. 1. The min. length of the duct should be more 2. Install the canvas tie-in between the body and than 1m, and ﬁx on the air inlet by screws duct.
Page 23 Fresh air duct installation Dimension : Duct joint for fresh air MODLE 9-18k Ø92mm(3.62”) Ø113mm(4.45”) Motor and drain pump maintenance (The rear ventilated panel is used as an example) 1) Motor maintenance: 2) Pump maintainance: Take o the ventilated panel. Remove four screws from the drain pump.
Page 24 Drill wall hole for connective piping 1. Determine the location of the wall hole CAUTION based on the location of the outdoor unit. 2. Using a 65mm (2.5in) or 90mm(3.54in) When drilling the wall hole, make (depending on models )core drill, drill a sure to avoid wires, plumbing, and hole in the wall.
Page 25 Connect drain hose The drainpipe is used to drain water away from NOTE ON DRAINPIPE INSTALLATION the unit. Improper installation may cause unit When using an extended drainpipe, • and property damage. tightenthe indoor connection with CAUTION an additionalprotection tube. This Insulate all piping to prevent condensation, •...
Page 26 Units with a pump. 3. Pass the drain hose through the wall hole. Make sure the water drains to a safe location 1. Remove the test cover. where it will not cause water damage or a Fill the water pan with 2 liters of water. slipping hazard.
Page 27 Install Your Outdoor Unit Select installation location NOTE : PRIOR TO INSTALLATION Before installing the outdoor unit, you must choose an appropriate location. The following are standards that will help you choose an appropriate location for the unit. Proper installation locations meet the following standards: 60cm（24"）...
Page 28 Install drain joint(Heat pump unit only) Base pan hole of outdoor unit Step 1： Find out the base pan hole of outdoor unit. Seal Step 2： Fit the rubber seal on the end of the drain joint that will connect to the ●...
Page 29 Anchor Outdoor Unit WARNING WHEN DRILLING INTO CONCRETE, EYE PROTECTION IS RECOMMENDED AT ALL TIME. The outdoor unit can be anchored to the ground or to a wall-mounted bracket with bolt(M10). Prepare ● the installation base of the unit according to the dimensions below. The following is a list of di erent outdoor unit sizes and the distance between their mounting feet.
Page 30: Refrigerant Piping Connection
REFRIGERANT PIPING CONNECTION When connecting refrigerant piping, DO NOT let substances or gases other than the speciﬁed refrigerant enter the unit. The presence of other gases or substances will lower the unit’s capacity, and can cause abnormally high pressure in the refrigeration cycle. This can cause explosion and injury.
Page 31 Connection Instructions—Refrigerant Piping CAUTION The branching pipe must be installed horizontally. An angle of more than 10° • may cause malfunction. DO NOT install the connecting pipe until both indoor and outdoor units have • been installed. Insulate both the gas and liquid piping to prevent condensation. •...
Page 32 • Clamp ﬂare from on the end of the pipe. The end of the pipe must extend beyond the ﬂare form. (Bigger Flare form Pipe • Place ﬂaring tool onto the form. Torque wrench • Turn the handle of the ﬂaring tool clockwise until the pipe is fully ﬂared.
Page 33: Wiring Precautions
WIRING PRECAUTIONS WARNING BEFORE PERFORMING ANY ELECTRICAL WORK, READ THESE WARNINGS. All wiring must comply with local and national Do not let wires touch or rest against ● ● electrical codes, regulations and must be installed refrigerant tubing, the compressor, or any by a licensed electrician.
Page 34 NOTE ON AIR SWITCH When the maximum current of the air conditioner is more than 16A, an air switch or leakage protection switch with protective device shall be used (purchased seperately). When the maximum current of the air conditioner is less than 16A, the power cord of air conditioner shall be equipped with plug (purchased seperately).
Page 35 Minimum Cross-Sectional Area of 4. Clamp down the cable with the cable clamp. Power and Signal Cables (For reference) 5. Insulate unused wires with electrical tape. Keep them away from any electrical or metal Rated Current of Nominal Cross-Sectional parts. Appliance (A) Area (mm ) 6.
Page 36 INDOOR UNIT WIRING 1. Prepare the cable for connection. CAUTION a. Using wire strippers, strip the rubber jacket from both ends of the signal cable to reveal While connecting the wires, please strictly • about 15cm (5.9”) of the wire. follow the wiring diagram.
Page 37 Power Speciﬁcations(Not applicable for North America) NOTE Electric auxiliary heating type circuit breaker/fuse need to add more than 10 A. The circuit breaker/fuse speciﬁcation shall be subject to the unit nameplate. (applicable for Australian model) Indoor Power Supply Speciﬁcations MODEL(Btu/h) ≤18K PHASE 1 Phase...
Page 38 Inverter Type A/C Power Speciﬁcations MODEL(Btu/h) ≤18K PHASE 1 Phase POWER (indoor) 220-240V VOLT CIRCUIT BREAKER/ 15/10 FUSE(A) PHASE 1 Phase POWER (outdoor) VOLT 220-240V CIRCUIT BREAKER/ 25/20 FUSE(A)
Page 39: Air Evacuation
AIR EVACUATION NOTE When opening valve stems, turn the hexagonal wrench until it hits against the stopper. Do not try to force the valve to open further. Close the Low Pressure side of the manifold Preparations and precautions gauge, and turn o the vacuum pump. Wait for 5 minutes, then check that there Air and foreign matter in the refrigerant circuit has been no change in system pressure.
Page 40: Note On Adding Refrigerant
NOTE ON ADDING REFRIGERANT CAUTION DO NOT mix refrigerant types. Some systems require additional charging depending on pipe lengths. The standard pipe length varies according to local regulations. For example, in North America, the standard pipe length is 7.5m (25’). In other areas, the standard pipe length is 5m (16‘).
Page 41: Test Run
TEST RUN CAUTION Failure to perform the test run may result in unit damage, property damage, or personal injury. f. Check to see that the drainage system is Before test run unimpeded and draining smoothly. g. Ensure there is no vibration or abnormal A test run must be performed after the entire noise during operation.
Page 42: Packing And Unpacking The Unit
PACKING AND UNPACKING THE UNIT Instructions for packing unpacking the unit: Unpacking: Indoor unit: 1. Cut the packing belt. 2. Unpack the package. 3. Take out the packing cushion and packing support. 4. Remove the packing ﬁlm. 5. Take out the accessories. 6.
Page 43 The design and speciﬁcations are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. Any updates to the manual will be uploaded to the service website, please check for the latest version. QS006UI-T2 16123000003973 20240105...
