Kohler SKYLINE K-706035T-FM-SHP Installation Instructions Manual

BEFORE YOU BEGIN

BEFORE YOU BEGIN
·
Before you install your shower door, please read
these instructions carefully to familiarize yourself
with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
·
All information is based on the latest product
information available at the time of publication.
Kohler China Ltd. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
·
These instructions contain important care, cleaning,
and warranty information-
instructions for the consumer.
·
Make sure that the bath and the finished wall
material are completely and correctly installed prior
to installing your shower door. Prepare waterproof
layer to wall and floor of the showering area. It is not
allowed for any presence of electric switches and
sockets. Make sure the floor drain runs smoothly.
·
Before starting the door installation, lay out and
identify all the parts. Use the exploded view
illustrated on page 3 for reference.
·
For the installation method of customized shower
with different dimensions, please refer to this
instructions.
· The product complies with QB 2584-2007.
CAUTION: Risk of injury or product damage.
Tempered glass cannot be cut, drilled or
knocked by hard object. Make sure corner area
of the glass refraining from knocking so as to
cause personal injury due to broken glass.
ATTENTION: Please install this door on Kohler
receptors or curbs(Not included). If the curb is not
Kohler-branded, please note its top width should be
more than 80mm.
IMPORTANT: The shower door requires a flat vertical
finished wall. The squareness of the wall is
recommended no more than 3 mm/m. KOHLER
Company won't take responsibility of the installation
quality.
ZHONGSHAN KOHLER SHOWER CO., LTD.
DEVELOPMENT ZONE, ZHONGSHAN, GUANGDONG, CHINA
1279909-T01-A
please leave these
·
·
·
·
·
·
·
QB 2584-2007
)
3mm/m
NO13-1, XINYE ROAD, ZHONGSHAN TORCH
13-1
©
Copyright Kohler China Investment Co., Ltd. 2016
-1-
©
SKYLINE
Installation INSTRUCTIONS
SLIDING, ROUND, 8mm
K-706035T-FM-SHP
3
80mm
POST CODE: 528437
528437
8mm
(
2016
