1. BEFORE YOU BEGIN
HOW TO USE THESE INSTRUCTIONS
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
SPECIFICATIONS
S
K-705250 Shower Enclosure:
36" x 36" x 72" H
PREPARATION
S
Before starting the installation, lay out and identify
all the parts. Use the exploded view parts list and
illustrations on pages 8 through 10 for reference.
S
Install shower receptor in accordance with
instructions supplied with receptor.
AB
116897-2-
R
1 1
ARICA
SHOWER ENCLOSURE
All information in these instructions is based on the latest
product information available at the time of publication.
Kohler Co. reserves the right to make changes in product
characteristics, packaging, or availability at any time with-
out notice.
These instructions contain important care, cleaning, and
warranty information – please leave instructions for the
consumer.
TOOLS AND MATERIALS REQUIRED
S
Conventional woodworking tools
S
Measuring tape
S
Pencil
S
Safety glasses
S
Screwdriver - Flat
S
Caulking gun
S
Masking tape
S
Silicone Sealant (RTV)
S
Center punch
S
Hammer
S
Screwdriver - Phillips
S
Electric drill
S
Drill bit - 5/16"
S
Masonry bit for ceramic tile - 5/16"
CAUTION: Tempered glass cannot be cut.
NOTE: For ease of installation, it is recommended that
two people install shower enclosure.
K-705250
ROUND
E2000 Kohler Co.
Advertisement
Related Manuals for Kohler ARICA K-705250
Summary of Contents for Kohler ARICA K-705250
- Page 1 Follow the sections that pertain to your Kohler Co. reserves the right to make changes in product particular installation. This will help you avoid costly characteristics, packaging, or availability at any time with- mistakes.
-
Page 2: Installation
Left-Hand Fixed Panel Bottom B. INSTALL MOVING PANELS Apply supplied silicone lubricant to the bottom track groove, making sure to apply to the entire length of the groove. Apply Silicone Lubricant to the Bottom Track Groove 116897-2- Kohler Co., Kohler, WI... - Page 3 #6-20 x 1” Panhead Screw Align each end of the assemblies with the top and bottom track screwports and fasten with twelve #6-20 x 1” panhead screws but do not tighten. Bottom Kohler Co., Kohler, WI 116897-2-...
- Page 4 Move the lever back one step as shown to allow for sufficient operating clearance. Move Lever Back One Step Repeat for the remaining three catches. Bottom Track Catch in the Engaged Position Stand door assembly upright. 116897-2- Kohler Co., Kohler, WI...
- Page 5 Secure sides of enclosure at bottom by installing two #8-18 x 1-1/4” panhead screws through each expander jamb and wall jamb into the installed anchors in wall. Repeat, securing the top of the enclosure and lastly the middle. Kohler Co., Kohler, WI 116897-2-...
- Page 6 Interlock Seal Excessive Interference If there is not enough interference when closing the door, Interlock Base the interlock seal can be changed to the depth shown. Interlock Seal Insufficient Interference 116897-2- Kohler Co., Kohler, WI...
- Page 7 Carefully apply a bead of silicone sealant around the outside (dry side) of door where: 1) Bottom frame meets the shower ledge. 2) Wall jambs meet the shower walls. Kohler Co., Kohler, WI 116897-2-...
-
Page 8: Exploded Parts List
#6-20 x 1” Philips Panhead Screw Wall Jamb Cover Adjustment Screw Retainer Adjustment Screw Expander Jamb Wall Jamb #8-18 x 1-1/4” Philips Panhead Screw Hollow Wall Anchor Hex Wrench (not shown) Silicone Lubricant (not shown) 116897-2- Kohler Co., Kohler, WI... - Page 9 Center (Moving) Panels Kohler Co., Kohler, WI 116897-2-...
- Page 10 12 25 Fixed Panels 116897-2- Kohler Co., Kohler, WI...
-
Page 11: Important Consumer Information
Kohler Warranty, its benefits, and limitations. Kohler Co. and its distributors support you with one of the largest Kohler Co. will, at its election, repair, replace, or make Service Networks of its type. Here’s what you need to do appropriate adjustment where Kohler Co. inspection... - Page 12 116897-2- Kohler Co., Kohler, WI...
