The Louvre ® Ceiling Fan Standard & Damp Location Models Net Weight 19 lbs. Model No. FP1320** OWNER’S MANUAL READ AND SAVE THESE INSTRUCTIONS Damp Location Model; Top of fan is marked, “Suitable For Use In Damp Locations”...
Fanimation. 7. Fanimation reserves the right to modify or discontinue any product at any time and may substitute any part under this warranty. 8. Under no circumstances may a fan be returned without prior authorization from Fanimation. The receipt of purchase must ac- company authorized returns and must be sent freight prepaid to Fanimation.
Fanimation. Substitution of parts or accessories not designated for use with this product by Fanimation could result in personal injury or property damage. Contact your retail store for missing or damaged parts.
7. 2. Optional fan & light remote control (C4), see page 8. NOTE: If you are using a Fanimation Light Fixture with your fan, see Ceiling Fan Light Kit Installation Instructions (packed with light kit) for wiring.
Page 5
How to Assemble Your Ceiling Fan (cont’d) NOTE: You will be using either the 6˝ downrod supplied with your fan or an optional downrod purchased seperately. 4. Loosen the two setscrews in the Downrod Support. Align the Clevis Pin holes in the Downrod with the holes in the Downrod Support.
▲WARNING To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before hanging. NOTE: If you are not sure if the outlet box is grounded, contact a licensed electrician for advice, as it must be grounded for safe operation.
How to Wire Your Ceiling Fan - Pull Chain If you feel that you do not have enough electrical wiring knowledge or experience, have your fan installed by a licensed electrician. ▲WARNING To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring.
How to Wire Your Ceiling Fan - C4 Hand-held Remote (Optional) If you feel that you do not have enough electrical wiring knowledge or experience, have your fan installed by a licensed electrician. ▲WARNING To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring.
How to Wire Your Ceiling Fan - C1 Wall Control (Optional) NOTE: If fan or supply wires are different colors than indicated, have this unit installed by a qualifi ed electrician. 1. Complete steps 1 thru 3 “How to Wire Your Fan - Pull Chain”...
Installing the Canopy Housing NOTE: This step is applicable after the neccessary wiring is completed. (see pages 7, 8 or 9) ▲WARNING To avoid possible fire or shock, make sure that the electrical wires are completely inside the canopy housing and not pinched between the housing and the ceiling.
Mounting the Fan Blades (cont’d) 7. Attach Blade Holders to the bottom of the Motor Housing using the 10-32 x ½˝ Flywheel Screws as shown in Figure Periodic cleaning of your new ceiling fan is the only maintenance that is needed. When cleaning, use only a soft brush or lint free cloth to avoid scratching the fi...
Before discarding packaging materials, be certain all parts have been removed When ordering repair parts, always give the following information: Contact your retail store for repair parts. Parts List Model #FP1320** Description How To Order Parts • Part Number • Part Description •...
The Lourve Ground Wire (Green) NOTE: The illustration shown is not to scale or its actual confi guration may vary ® FP1320** Exploded-View Ground Wire (Green) Figure 20...
For your own safety turn off power at fuse box or circuit breaker before trouble shooting your fan. Trouble 1. FAN WILL NOT START 1. Fuse or circuit breaker blown. 2. Loose power line connections to the fan, or loose switch wire connections in the switch housing.
