Power Washer Shut Down

WARNING
Fluid Injection. This machine produces
high-pressure fluid streams that can pierce
skin. Fluid injection could result in death or
serious injury.
IMPORTANT: Spray gun traps high-pressure
water, even when engine is stopped and water
is disconnected. Always point spray gun in
safe direction, and squeeze spray gun trigger
to release high-pressure. Engage trigger lock
when not in use.
1. Release spray gun trigger.
2. Push Start/Stop button for 1 second.
3. Turn water supply OFF.
4. Squeeze spray gun trigger and release
high-pressure water.
5. Engage trigger lock.
NOTE: If Start/Stop button fails to shut down
engine, press and hold the emergency stop
switch on side of engine for 6 seconds or until
the engine stops completely. See
Figure 3-4. Emergency Stop Switch

Apply Detergent

WARNING
Fluid Injection. This machine produces
high-pressure fluid streams that can pierce
skin. Fluid injection could result in death or
serious injury.
WARNING
Personal injury. Risk of fluid injection.
Do not aim spray gun at people, animals,
electrical devices, or fragile items. Keep out
of reach of children. Failure to do so
could cause death or serious injury.
NOTE: DO NOT use caustic liquid with power
washer. Use ONLY power washer safe
detergents. Follow
instructions on the detergent label.
Apply detergent as follows:
1. Verify black detergent nozzle is installed.
2. Open detergent tank cap.
3. Prepare detergent solution as required by
job.
Owner's Manual for Power Washer
(000106b)
Figure 3-4.
006220
(000106b)
(000117c)
all manufacturer's
NOTE: Verify siphoning tube and filter remain
fully submerged in detergent while in use.
NOTE: Detergent cannot be applied with high-
pressure nozzle (White, Green or Red). Only
use black nozzle with detergent.
4. Start engine.
5. Apply detergent to a dry surface. Start at
lower portion of area to be washed and
work upward
overlapping strokes.
IMPORTANT: Flush the detergent siphoning
system after each use. Contact Customer
Service at
www.drpower.com with questions.

Rinsing

WARNING
Risk of Falling. Use of machine creates wet
areas and trip hazards. Be aware of work area
conditions. A fall could result in death
or serious injury.
WARNING
Risk of Falling. Do not use this machine or
any components on elevated surfaces.
Doing so can result in a fall, serious injury,
or death.
1. Remove black detergent nozzle from
lance.
2. Select and install desired high-pressure
nozzle.
3. Point spray gun in safe direction and
squeeze trigger
detergent from system.
4. Keep spray gun a safe distance from area
you plan to spray.
5. Spray gun may kick back when using high
pressure spray. To avoid injury, firmly
grasp spray gun with both hands.
6. Apply a high-pressure spray to a small
area and then inspect surface for damage.
If no damage is found, continue rinsing.
7. Start at top of area to be rinsed, working
down with same overlapping strokes as
used for cleaning.
Clean Detergent Siphoning
Tube
Flush detergent siphoning tube after each use
before stopping the engine.
1. Place detergent siphoning tube/filter in
bucket of clean water.
2. Remove high-pressure nozzle from lance.
3. Select and install black detergent nozzle.
4. Flush for 1-2 minutes.
5. Shut engine OFF.
6. Point spray gun in a safe direction,
squeeze spray gun trigger to release
retained high water pressure. Engage
trigger lock.
Operation
using long, even,
1-855-447-3734
(000112)
(000114)
to flush remaining
or
9
