Fanimation Edgewood TF100 Series Specification Sheet

Wet Location Model
WET LOCATION – TF900**
WET LOCATION – TF970**
*FAN CONTROL OPTIONS (Dry Applications Only):
Optional controls are: C1 or C2 wall controls; C4 remote control with canopy receiver.
Installation & operating instructions provided with each control.
10983 Bennett Parkway
Toll Free (888) 567-2055
Outside U.S. call (317) 733-4113
Visit Our Website www.fanimation.com
Copyright 2008 Fanimation, Inc.
WET LOCATION – TF900**
Electrical Requirements 120 VAC, 60 Hz
Fan Motor; Energy Star Rated 188 x 12
Blade Sweep / Pitch 50˝ / 14°
13.6˝ from ceiling to switch cup
Dimension (w/4½˝ DR)
11.7˝ from ceiling to blade edge
Fan Controls (*Options) Pull Chain & Reverse Switch
3 - Speed, Reversible - RPM's High - 185; Med - 125; Low - 70
Plastic Blades (set of 5) Traditional Wood style – Included
Down Light Kit / Glass Optional – Sold Separately
Net Hanging Weight 18 lbs
Damp/Wet Location Usage UL Rated
Available Uni-Packed Finishes
Fan / Housing Assembly Blades - Traditional
AW – Antique White Antique White
AZ – Aged Bronze Dark Cherry
SN – Satin Nickel Light Cherry
WH – White White
WET LOCATION – TF970**
Electrical Requirements 120 VAC, 60 Hz
Fan Motor; Energy Star Rated 212 x 25
Blade Sweep / Pitch 60˝ / 16°
13.6˝ from ceiling to switch cup
Dimension (w/4½˝ DR)
11.7˝ from ceiling to blade edge
Fan Controls (*Options) Pull Chain & Reverse Switch
3 - Speed, Reversible - RPM's High - 155; Med - 105; Low - 45
Plastic Blades (set of 5) Brown Painted – Included
Down Light Kit / Glass Optional – Sold Separately
Net Hanging Weight 32 lbs
Damp/Wet Location Usage UL Rated
Available Uni-Packed Finishes
Fan / Housing Assembly Blades - Traditional
TS – Tortoise Shell Brown, Painted
Zionsville, IN 46077
FAX (866) 482-5215
The
TF100/300/600/700/900 Series Fans
SPECIFICATION SHEET
2008/05
Edgewood
Product Specifi cations subject to change
Series
®
