- Page 1 SMART OPS PC modules with Windows® 10 Pro USER GUIDE PCM11-i5 (PCM11-1) PCM11-i7v (PCM11-2) PCM8-i5 (PCM8-1) PCM8-i7v (PCM8-2) Was this document helpful? smarttech.com/docfeedback/171747...
- Page 2 © 2021 SMART Technologies ULC. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language in any form by any means without the prior written consent of SMART Technologies ULC. Information in this manual is subject to change without notice and does not represent a commitment on the part of SMART.
-
Page 3: Important Information
Responsible Party – US Contact Information SMART Technologies Inc. EU Declaration of Conformity 2401 4th Ave., 3rd Floor Hereby SMART Technologies ULC declares that the OPS PCM8 Seattle, WA 98121 and PCM11 are in compliance with Directive 2014/53/EU. compliance@smarttech.com The full text of the EU declaration of conformity is available at the following internet address: smarttech.com/compliance. - Page 4 Important information Innovation, Science and Economic AVERTISSEMENT Development Canada statement (i) les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin This device complies with RSS-247 of the Innovation, Science de réduire les risques de brouillage préjudiciable aux and Economic Development Canada Rules.
-
Page 5: Table Of Contents
Contents Important information Chapter 1: Welcome Chapter 2: Installing and using the SMART OPS PC module Viewing the OPS PC module input source Connecting USB drives, peripherals, and other devices Connecting external displays Chapter 3: Troubleshooting Appendix A: Connectors PCM11 series PCM8 series Appendix B: Hardware environmental compliance... -
Page 6: Chapter 1: Welcome
SMART Notebook® collaborative learning software, SMART TeamWorks™ visual collaboration software, and SMART Meeting Pro® software, and access the internet directly through your existing interactive display’s network connection. Upgrades and service for the OPS PC module are easy to perform without removing the interactive display from its mounting. -
Page 7: Chapter 2: Installing And Using The Smart Ops Pc Module
AC power inlet is in the OFF (O) position. NOTE For a list of SMART Board interactive displays in which you can install the OPS PC module, see the OPS PC module’s specifications. Series... -
Page 8: Viewing The Ops Pc Module Input Source
Chapter 2 Installing and using the SMART OPS PC module Viewing the OPS PC module input source 1. Open the display’s input source menu: Display series iQ status Procedure Open the Side Toolbar menu by tapping and sliding either of the Side Toolbar menu handles... -
Page 9: Connecting Usb Drives, Peripherals, And Other Devices
Chapter 2 Installing and using the SMART OPS PC module Connecting USB drives, peripherals, and other devices You can use USB drives, peripherals, and other devices with the OPS PC module by connecting those devices to the OPS PC module’s USB 2.0 Type-A, USB 3.0 Type-A, and USB Type-C receptacles. -
Page 10: Connecting External Displays
Chapter 2 Installing and using the SMART OPS PC module Connecting external displays You can connect an external display to the HDMI out connector on the OPS PC module (rather than the HDMI out connector on the display). This allows you to duplicate or extend the OPS PC module’s desktop to the external display. -
Page 11: Chapter 3: Troubleshooting
Chapter 3 Troubleshooting This chapter explains how to resolve common issues with the SMART OPS PC module. If the symptoms you’re encountering aren’t covered below or the solutions to the symptoms don’t work, refer to the SMART knowledge base (community.smarttech.com) for additional troubleshooting information. -
Page 12: Appendix A: Connectors
Appendix A Connectors PCM11 series PCM8 series PCM11 series The following diagram and table present the connectors on the PCM11 series of SMART OPS PC modules: Connector Connects to Notes Stereo 3.5 mm Headphones or headsets Analog audio cables and connectors. - Page 13 USB cables and connectors. RJ45 [N/A] The OPS PC module uses the SMART Board interactive display’s network connection (if available), so you typically don’t need to connect the OPS PC module directly to a network. USB 2.0 Type-A Supported USB drives,...
- Page 14 Appendix A Connectors PCM8 series The following diagram and table present the connectors on the PCM8 series of SMART OPS PC modules: Connector Connects to Notes USB Type-C Supported USB drives, See Connecting USB drives, peripherals, and other devices peripherals, and other devices on page 9 and...
- Page 15 Appendix A Connectors Connector Connects to Notes HDMI out External display See Connecting external displays on page 10 and HDMI cables and connectors. Stereo 3.5 mm out External speakers or Analog audio cables and headphones connectors. Stereo 3.5 mm in Microphone Analog audio cables and connectors.
-
Page 16: Appendix B: Hardware Environmental Compliance
Appendix B Hardware environmental compliance SMART Technologies supports global efforts to ensure that electronic equipment is manufactured, sold, and disposed of in a safe and environmentally friendly manner. Waste Electrical and Electronic Equipment (WEEE) Electrical and electronic equipment and batteries contain substances that can be harmful to the environment and to human health. - Page 17 SMART TECHNOLOGIES smarttech.com/support smarttech.com/contactsupport smarttech.com/kb/171747...
