SMART CAS-340 Quick Reference

Classroom amplification system

Hide thumbs Also See for CAS-340:

Download this manual

CAS-340 control unit top view

CAS-340 control unit bottom view

USB receptacle

Connect your computer here.

Auxiliary inputs

Connect your projector to Aux In 1 and

any other audio input to Aux In 2.

Quick reference

SMART Audio™ classroom

amplification system

Models CAS-340 and CAS-360

Power

1017155

Line Out / ALS Out

Connect a recording feed or an

assistive listening device here.

Power connection

Reset

Hold for three seconds

to reset the system.

Room connection

Connect your room

module here.

Need help?

Do you have a question about the CAS-340 and is the answer not in the manual?

Page 1 Quick reference SMART Audio™ classroom amplification system Models CAS-340 and CAS-360 CAS-340 control unit top view Power CAS-340 control unit bottom view Power connection Reset USB receptacle Hold for three seconds Connect your computer here. to reset the system. Room connection...
Page 2 Q UI CK R E F E R E NC E – S MART AUDI O CL ASS ROOM AMP LIFI CATI O N SYS TE M CAS-360 control unit top view LCD screen Power Control dial CAS-360 control unit bottom view Power in Reset Hold for three seconds...
Page 3 | smarttech.com/contactsupport © 2012 SMART Technologies ULC. All rights reserved. SMART Audio, the SMART logo, smarttech and all SMART taglines are trademarks or registered trademarks of SMART Technologies ULC in the U.S. and/or other countries. All third-party product and company names may be trademarks of their respective owners. Contents are subject to change without notice.
