NAV102 with NavMate
• Go To...: Choose your destination by searching for an address, choosing an entry from
the POI (point of interest) directory, selecting a location from the map, or by choosing a
destination from a saved list of recently visited locations or favorites (see "Selecting a
Destination" on page 7).
• Setup: Configure your navigation to suit your needs. Define general settings (e.g. time,
language, or system of measurement), configure your map (e.g. 2D or 3D mode, day or
night mode, map complexity) or load a map of a different region, set the route options
(e.g. choose to avoid or allow toll roads or ferries, or change the volume (see "Setup
Menu" on page 24).
• Office Address: Route to Office Address.
• Trip Computer: Display Speed, Trip, Odometer and Clock readings.

Navigation Screen

The map is the core component of your NAV102. During navigation, it is centered on your
current location by default, provided you have a GPS connection.
In Tracking mode, the map follows your actual position (GPS position), displaying information
about your geographic position, distance to your destination, etc. The GPS position is indicated
by a red/blue arrow.
You can also browse the map, view businesses and other Points of Interest (POI, and then
choose them for routing and navigating. The map knows two basic states: Tracking and
Browsing.
Map Tracking Screen
During navigation, the screen displays your route (in yellow) and your surroundings. A red/blue
arrow identifies your current position. The upcoming maneuver is visualized in the upper left
corner, along with the distance and approximate time before that turn. When you come up to a
turn, you will hear a voice command at the appropriate time.
Next Turn/Junction/Exit Number
Next Maneuver
Distance to Next Maneuver Time Before Next Maneuver
Zoom Out
Map Scale
Distance to Repeat
Voice Prompt
Destination
Estimated
Arrival Time
Zoom In
Press for 2D/3D/Split Screen View
5
GPS Signal Strength
Compass Heading
Current Time
Menu Button
Current Location
On the left, additional information, including the current time, GPS signal strength and
compass orientation (N, S, E, W) is displayed.
• To zoom in or out, press the + or – icons.
• To return to the Main Menu, press the
• To add a POI destination to your route, press the
• For one-way streets, the transit direction is indicated with a red arrow.
• For more information about navigation, see "Navigating" on page 16.
Map Browsing Screen
Touch (and hold) the screen to access Map Browsing Mode. Use a stylus or your finger to
browse the map. Your position is identified as the center of the crosshair.
Crosshair
Crosshair Location
• To zoom in or out, press the + or – icons.
• To return to the map tracking mode, press the
Mute Voice Prompts
Current Position Map Location
button.
button.
Business
Icons
button.
