EverFocus EQ150 Specifications

Black/White Cameras
EQ150
560 TVL Black/White Box Type Camera
1/50 (1/60) ~
1/100,000 sec
Features
1/3" Sony Interline Transfer Super HAD CCD
•
560 TVL of horizontal resolution
•
Low light sensitivity of 0.06 Lux/F=1.2
•
• Digital Signal Processing (DSP) circuitry design to
deliver excellent picture quality and performance
Wide range automatic electronic shutter:
•
1/50 (1/60) ~ 1/100,000
•
Auto line lock with external phase adjustment
• C/CS mount adjustable with easy back focus adjustment
• Dual voltage
Dimensions
140.2 mm / 5.52"
51
Box Type Cameras

Specifications

Pickup Device
Video Format
Picture Format
Horizontal Resolution
Sensitivity
Video Output
S/N Ratio
Sync. Mode
Electronic Shutter
Gamma Correction
Backlight Comp.
Auto Gain Control
Power Source
Power Consumption
Dimensions (L x W x H)
Weight
Operating Temp.
Humidity

Ordering Information

51 mm / 2" • EQ150/E: 560 TVL, B/W Box Type Camera
1/3" Sony Interline Transfer Super HAD CCD
NTSC/PAL
768 x 494 (NTSC) / 752 x 582 (PAL)
560 TVL
0.06 Lux / F=1.2
BNC 1.0 Vp-p, 75ohm
Over 48dB (AGC Off)
Line Lock/Internal Sync.
1/50 (1/60) ~ 1/100,000
0.45
On/Off Switch
On/Off Switch
12VDC/24VAC
24VAC: 7W max. / 12VDC: 4.5W max.
140.2 x 51 x 57 mm / 5.5" x 2" x 2.3"
500 g / 1.1 lbs
0°C ~ 50°C / 32°F ~ 122°F
20° ~ 80° humidity
