Completing Your Installation
Circuit Wiring Layout
Rev A: Add new URL 11/4/2011
Rev b New Layout 05/2013
PATENTED: www.voxxintl.com/company/patents
Model APS-25C
Installation Manual
Remote Control Vehicle
Security System
Page 2
Page 3
Page 3
Page 4
Page 5
Page 7
Page 7
Page 8
Page 9 - 10
Page 11
Page 11
Page 12
128-8808b
1 of 12
Advertisement
Table of Contents
Related Manuals for Prestige APS-25C
Summary of Contents for Prestige APS-25C
-
Page 1: Table Of Contents
Model APS-25C Installation Manual Remote Control Vehicle Security System Table Of Contents: Before You Begin Page 2 11 Pin Main Harness Wiring Page 3 3 Pin Door Output Harness Page 3 Installation of the Major Components Page 4 Wiring the System's Main Harness... -
Page 2: Before You Begin
Before You Begin PROFESSIONAL INSTALLATION IS STRONGLY RECOMMENDED Roll down window to avoid locking the keys in the vehicle during installation. Avoid mounting components or routing wires near hot surfaces or near moving parts like the steering wheel as it may prevent proper operation of the vehicle. Tape or loom wires under the hood and dash for protection as well appearance. -
Page 3: Pin Main Harness Wiring
11 Pin Main Wiring Harness Part # 1122916 WHITE (+) Parking Light Output 15A Max (+) 12 Volt Input Parking Lts & Module DARK BLUE Channel 3 Trunk Output (-) 300mA WHITE/BLACK + 12 Volts Siren Output RED/WHITE + 12 Volt Module Feed (See Red) BLACK Chassis Ground YELLOW... -
Page 4: Installation Of The Major Components
INSTALLATION OF MAJOR COMPONENTS: CONTROL MODULE: Part # 1362268 Select a mounting location inside the passenger compartment (up behind the dash) and secure using two screws provided. The control module can also be secured in place using cable ties. Do not mount the control module in the engine compartment, as it is not waterproof. You should also avoid mounting the unit directly onto factory installed electronic components. -
Page 5: Wiring The System's Main Harness
WIRING THE SYSTEM'S MAIN HARNESS: Part # 1122910 WHITE WIRE: + 12 VDC PULSED PARKING LIGHT OUTPUT ( 15 A MAX ) This wire is provided to flash the vehicle’s parking lights. Connect the white wire to the positive side of one of the vehicle’s parking lights. - Page 6 YELLOW WIRE: + 12 VDC IGNITION SOURCE Connect this wire to a source that supplies 12 VDC when the ignition key is in the ON and CRANK positions and off when the key is in the OFF position. DARK GREEN WIRE: (-) INSTANT TRIGGER This is an instant on ground trigger wire.
-
Page 7: To Learn The Dome Light Delay
RED and GREEN 2 PIN (white) CONNECTOR: DOOR LOCK OUTPUTS Part # 1122242 These wires will provide a pulsed ground output to the factory door lock control relay. The maximum current draw through these outputs must not exceed 300 mA. 3 Wire Ground Switched Door Locks In this application, the red wire provides a ground pulse during arming (pulsed ground lock) output. -
Page 8: Adjusting The Shock Sensor
Adjusting the Shock Sensor : The sensitivity of the pre - detect circuit, where used, is automatically set 30% less sensitive than the full trigger circuit. Using a small screwdriver, gently turn the adjustment screw fully counterclockwise. (DO NOT over turn this screw. -
Page 9: Installation Notes
INSTALLATION NOTES Page 9 128-8808b 9 of 12... - Page 10 INSTALLATION NOTES Page 10 128-8808b 10 of 12...
-
Page 11: Programming Bank1 (Transmitters)
PROGRAMMING BANK 1 (TRANSMITTERS): 1) Turn the ignition key to the on position. 2) Press and release the valet/programming switch 3 times (Siren Chirps). 3 Press the Lock Button of each transmitter you want programmed until you hear a chirp from the horn or siren. 4) Turn the ignition switch off. - Page 12 For technical support go to www.prestigecarsecurity.com or call 1 800 225 6074. © 2013 Audiovox Electronic Corporation, 150 Marcus Blvd., Hauppauge, N.Y. 11788 128-8808b Page 12 128-8808b 12 of 12...
