1
LOCATING PARTS FOR ASSEMBLY
• Locate side cross tubes (x2) and front/rear walker base.
2
ATTACHING FRONT & REAR WALKER BASE
• Place the walker on a solid flat surface with the bottom facing upwards and arrange as shown.
• Locate two side cross tubes and assemble to front walker base until you hear release pins "CLICK" into place. (Fig. 2)
• Locate the rear walker base and assemble to the cross tubes until you hear release pins "CLICK" into place. (Fig. 2A)
• After joining, secure in place with (x4) bottom base screws (Fig. 2B).
Customer Service
gcs@DeltaChildren.com
WALKER BOTTOM BASE ASSEMBLY
Side Cross
Tubes (x2)
Fig. 2
"CLICK"
Fig. 2B
REAR
Walker base
FRONT
Walker base
BottomBaseScrew|Scale1:1
Bottom Base Screw Scale 1:1
7
Fig. 2A
"CLICK"
