Delta Children First Steps 3-in-1 Sit-to-Stand Instruction Manual page 10

1
ATTACHING TOY TRAY
• To install toy tray: Place the toy tray into the recess on the top tray, front
side first then push back down
notches are engaged
Fig. 2
2
INSERTING WALKER SEAT
• Align walker seat with walker top as shown (Fig. 2)
• Attach each of the 8 clips by placing over hooks as shown (Fig. 2A).
Customer Service
gcs@DeltaChildren.com
WALKER ASSEMBLY
Toy Tray
Notches
Notches
Walker Top
Tray
until you hear a "CLICK" when
Fig. 2A
Notches
FRONT
• Pull upward on the toy tray to ensure it is in a fully locked position.
• To release toy tray: Press notches in from underneath the tray.
FRONT
Fig. 3
FRONT
3
INSERTING WALKER TOP
• Arrange walker top and bottom as shown (Fig. 3)
• Align each walker leg so that the dot and arrow are lined up together.
• Once aligned, insert each leg into walker base until they "CLICK" into place.
10
"CLICK"
www.DeltaChildren.com
